Image preview - the first page of the document
>> Download SANYO_VPC-S60 documenatation <<Text preview - extract from the document FILE NO.
SERVICE MANUAL
Digital Camera VPC-S60
(Product Code : 168 049 01)
(U.S.A.)
(Canada)
(Korea)
(Taiwan)
(General)
VPC-S60EX
(Product Code : 168 049 02)
(Europe)
(U.K.)
(South America)
(China)
(Australia)
Contents (Hong Kong)
1. OUTLINE OF CIRCUIT DESCRIPTION .................... 3 (Russia)
2. DISASSEMBLY ........................................................ 12 (Middle East)
3. ELECTRICAL ADJUSTMENT .................................. 16 (Africa)
4. USB STORAGE INFORMATION (General)
REGISTRATION ...................................................... 22
5. TROUBLESHOOTING GUIDE ................................. 23
6. PARTS LIST ............................................................. 24
CIRCUIT DIAGRAMS &
PRINTED WIRING BOARDS ...................................... C1
WARNING
This product has been manufactured using lead-free solder. Be sure to follow the warning given on page 2 when carrrying out
repair work.
PRODUCT SAFETY NOTICE
The components designated by a symbol ( ! ) in this schematic diagram designates components whose value are of
special significance to product safety. Should any component designated by a symbol need to be replaced, use only the part
designated in the Parts List. Do not deviate from the resistance, wattage, and voltage ratings shown.
CAUTION : Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the manufacturer.
Discard used batteries according to the manufacturer's instructions.
NOTE : 1. Parts order must contain model number, part number, and description.
2. Substitute parts may be supplied as the service parts.
3. N. S. P. : Not available as service parts.
Design and specification are subject to change without notice.
SX81R/U, EX REFERENCE No. SM5310663
