Image preview - the first page of the document
PA-1067(C-Mar2014)(HV-CA-571-3)


>> Download PA-1067(C-Mar2014)(HV-CA-571-3) documenatation <<

Text preview - extract from the document
                                                                               Model HV-CA-571-3
Keithley Instruments, Inc.
28775 Aurora Road
                                              High-Voltage Triaxial Panel-Mount Cable
Cleveland, Ohio 44139
1-888-KEITHLEY
http://www.keithley.com



Description
   The Model HV-CA-571-3 is a 3.1 m (10 ft.) long triaxial cable that is terminated with a high-voltage triaxial
   panel-mount connector on one end. The other end is unterminated. The cable is intended for use in a safe
   enclosure, such as a test fixture. Refer to the manuals for the Model 2657A High Power System
   SourceMeternstrument for examples that show how to use this cable.
                                            Figure 1: Model HV-CA-571-3




Mechanical characteristics (connector only)
                                         Figure 2: Feedthrough Connector




PA-1067 Rev. C / March 2014             *PPA1067C*                                                                 1
Model HV-CA-571-3


Electrical characteristics
     Leakage current:
             Center to guard: <100 x 10-12 A at 3000 V (see NOTE below)
             Guard to shield: <100 x 10-9 A at 3000 V
     Working voltage: 3300 V
     Dielectric breakdown voltage:
             Center/guard to shield: 5250 V
     Mates with HV-CA-554 or SHV-CA-553


             For the Model 2657A System SourceMeter
