Image preview - the first page of the document



>> Download Samsung_PN58C680G5FXZA_fast_track_guide_[SM] documenatation <<

Text preview - extract from the document

        PN58C680G5FXZA                    Fast Track Troubleshooting Manual - Rev 1/10/12

                            Vs Va Vsc Ve                                                             SERVICE BULLETINS
    Buffer Y
                            Voltages


                                                                               X Main
                                 SMPS
                                                                                            Please check GSPN for parts update!

                                                        Logic PCB
                Y Main


                                                                          Main PCB


                Buffer E                             Buffer F       Buffer G



                                                                  FIRMWARE
                                                        Please check Samsung.com for
HELP : 1-888-751-4086 (Tech Support)                            latest update!
          1-866-894-0637 (FE)
GSPN
http://gspn3.samsungcsportal.com                        10/17/2010, Ver. 1002.0
PLUS ONE                                                No sound from SPDIF on PC-DTV PIP
http://my.plus1solutions.net/clientPortals/samsung

HOT TIPS
-Power On Problems: (pg. 3)
-Video Problems: (pg. 4)                                                                                                   1
PN58C680G5FXZA          Fast Track Troubleshooting Manual




                 Power On Sequence
                 -STBY 5V (Pin 2 CN801)
                 -PS_ON (approx 3.3V
