Image preview - the first page of the document



>> Download Samsung_UN46D6900WFXZA_fast_track_guide_[SM] documenatation <<

Text preview - extract from the document

       UN46D6900WFXZA                                  Fast Track Troubleshooting Manual

                                                                                                         Publication #: APUN46D6900W Rev. Date: 6/4/12
                                                                       Power (IP) Bd
                                                                                                         Service Bulletins:
                   Main Bd                                                                                46" LED Panel Substitution - Parts Bulletin
                                                                                                         GPC20120126001. When panel BN95-00450A is
                                                                                                         ordered and substitute panel BN07-00998A is
                                                                                                         being shipped, LVDS cable BN96-18130D**
                                                                                                         should also be ordered. Original LVDS cable is
                                                                                                         not long enough to reach the T-Con board.

                                                                                                         Quick Part List:
                                                                                                         Version       Parts No        Short Description
                                                                                                           ALL       BN44-00427B            Power PCB
                                                                                                          CN01       BN81-06343A            T-CON PCB
                                                                                                          CN01       BN94-04629C             Main PCB
                                                                                                          H302       BN94-04629G             Main PCB
                                                                                                          H302       BN96-16503A            T-CON PCB
                                           T-Con Bd
Func/IR                                                                                                   CN01       BN96-17107B       Bluetooth Module
                                                                                                          CN01       BN96-18099A           3D & IR PCB
              Speaker                                                           Speaker                    ALL       BN96-18099D               IR PCB
                                                                                                          CN01       BN96-18232B          Function PCB
HELP: 1-888-751-4086 (Tech Sup.
