>> Download Quantum Bigfoot TX jumpers documenatation <<Text preview - extract from the document Bigfoot TX
bigfoot_tx_jumper.pdf
Jumper Settings
DS CS PK Rsvd
Stand alone ON OFF OFF OFF
Master with Slave Present ON ON OFF OFF
Slave to Master OFF OFF OFF OFF
Jumper Locations
The Maxtor
