Image preview - the first page of the document
toshiba lcd SL738 series Hotel Mode


>> Download toshiba lcd SL738 series Hotel Mode documenatation <<

Text preview - extract from the document
                         738 series Hotel Mode

HOW TO ENTER HOTEL MODE
1) Push MUTE button on the remote control (MUTE will appear on the screen)
2) Within 2 seconds push MUTE button on the remote control again for about 7
   seconds
3) Whilst holding mute push the INPUT button on the side of the TV
4) Hotel mode will then appear.


*To exit hotel mode turn the TVs power off.
Setting item            Setting Value                  Initial Value   Function
Hotel Mode              On / Off                       Off             Enable Hotel mode
Panel Lock              On / Off                       Off             Inhibit all buttons which are on the TV
Side Key W/O input SW   On / Off                       Off             Inhibit all buttons which are on the TV
                                                                       Only disable input key

Remote Control          On / Off                       Off             Inhibit the remote control
Setup Menu Inhibit      On / Off                       Off             Inhibit set up menu
Setup Menu W/O          On / Off                       Off             Inhibit display set up menu except for language.
Language                                                               *there is only language setting at the setup menu.

Max Volume Setting      00-100                         100             Max volume control
Fixed Pos / Video       On / Off TV / Component /      Off             When the TV is turned on via the power button on the remote
                        AV / PC / HDMI / Off / TV 1-                   control or the TVs power switch the display goes to a fixed Pos /
                        255                                            Video.

Fixed Volume            On / Off / Value 0-100         Off             When the TV is turned on via the power button on the remote
                                                                       control or the TVs power switch the volume goes to a fixed setting.

Fixed Picture Mode      On / Off / Value               Off             When the TV is turned on via the power button on the remote
