Image preview - the first page of the document
>> Download panasonic_chassiseuro-4_txw28r4 documenatation <<Text preview - extract from the document ORDER No. SM-98058
Colour Television
TX-W28R4
EURO4 Chassis
SPECIFICATIONS
AV3 IN S-Video IN Y: 1V p-p 75
Power Source: 220-240V AC, 50Hz (4-pin) C: 0,3V p-p 75
Audio (RCAx2) 500mV rms10k
Power Consumption: 100W Video (RCAx1) 1V p-p 75
Aerial Impedance: 75 unbalanced, Coaxial Type
High Voltage: 30,5kV
