Image preview - the first page of the document
>> Download CR-YM4270K_CR-YM4272K documenatation <<Text preview - extract from the document ORDER No.1103
AUTOMOTIVE ELECTRONICS
MAZDA
CR-YM4270K
CR-YM4272K
AM/FM MPX ELECTRONIC TUNING
RADIO [Center Panel Module System]
VEHICLE : Mazda 6
DESTINATION : Europe
PRODUCED AFTER : Feb., 2002
Specifications*
General AM Radio
Power Supply DC 12V (11V - 16V) Frequency Range 531 - 1,602kHz
Test Voltage 14.4V Effective Sensitivity 6dB/
