CONFIDENTIAL 1 (2)
Nokia Mobile Phones Service Bulletin No. SB-028/27.10.00
Technical Support, Europe & Africa
NSE-5
BLANKING DISPLAYS
If the contact between the connector spring and the PCB is poor, it might
cause intermittently blanking display. These cases can be solved by
changing the A-cover with connector spring to new one (version 7).
The code for the A-cover remains same (9456582), but the new spring is
marked with "ESD&Conn. Spring vers. 7" (see pictures below)
Old spring vers. 6:
The spring itself separately (not available as a spare part):
NSE-5 SB-028
CONFIDENTIAL 2 (2)
New spring vers. 7:
The spring itself separately (not available as a spare part):
Note! On version 7 the 3 contact points are situated closer to the center hole
than on version 6
NSE-5 SB-028
