Image preview - the first page of the document
nokia_446pro_chass446f_194


>> Download nokia_446pro_chass446f_194 documenatation <<

Text preview - extract from the document
                   xx




    Nokia Display Products Oy
    P.O.Box 14
    FIN---24101 Salo, Finland
                                                            Chassis 446F


           19" High Resolution Colour Monitor
           446PRO


                                                                            Contents
                                                                            Service
                                                                            Monitor Dismantling
                                                                            Part List
                                                                            PCB Part List
                                                                            PCB Layout pictures




       Level                                 1             1

       Main Board module . . . . . . SMA241E            SMA241H
       CRT module . . . . . . . . . . . . . SMY052      SMY052




When re--- ordering manuals, please quote the model name and part number.                   ZB1680A
                                                                                             02.00
446F
Service
Contents
1. Product Overview
   1.1. Technical Specifications
   1.2. Certifications
        1.2.1. Safety
        1.2.2. EMC
        1.2.3. X---ray, emissions, environmental, ergonomics
   1.3. Preset Display Modes
   1.4. S--Capacitor Table
   1.5. Monitor Connection
   1.6. User Controls
   1.7. Menu
2. Site Preparation
   2.1. Location
   2.2. Troubleshooting
   2.3. Checking the Operation of Power Saver
3. Controlling the Memory for Picture Adjustments
   3.1. Memory for User Adjustments
        3.1.1. Adjustment
        3.1.2. Resetting the User Memory
   3.2. Memory for Factory Adjustments
        3.2.1. Adjustment
4. Service Mode
   4.1. Grouping of the Adjustments
   4.2. Service Menu
        4.2.1. Access to the Service Mode
        4.2.2. Geometry
        4.2.3. Grey Scale
        4.2.4. Memory settings and Initializing the Replacement IC (IC204 on SMA)
        4.2.5. Storing Adjustments
        4.2.6. Exit from Service Menu
5. Workshop Maintenance
   5.1. Important Safety Notice
   5.2. ESD--Sensitive Parts
   5.3. Test Equipment
   5.4. Test Patterns
   5.5. Disassembly
6. Image performance
   6.1. Image stabilising time
   6.2. Colour temperature and tracking
   6.3. White uniformity
   6.4. Colour purity
   6.5. Luminance
   6.6. Image size
   6.7. Linearity
   6.8. Geometrical distortion
   6.9. Jitter
7. Adjustment Procedure
   7.1. Adjustment Flow Diagram
   7.2. Preliminary Preparations
        7.2.1. High Voltage
        7.2.2. Coarse Width
   7.3. Geometry
   7.4. Grey Scale
        7.4.1. The Most Dominant Colour
        7.4.2. Low Light
        7.4.3. High Light
   7.5. Maximum/Minimum Contrast
   7.6. Focus
   7.7. Convergence
        7.7.1. Measuring Conditions
        7.7.2. Convergence Measuring Gauge

                                             446F                                   1
        7.7.3. Static Convergence
        7.7.4. Dynamic Convergence
        7.7.5. Allowed Error Levels for Convergence
   7.8. Colour Purity
8. Screen and Faceplate Blemishes
   8.1. Definitions of inspection conditions and terms
        8.1.1. Standard observing condition
        8.1.2. Zone division
        8.1.3. Minimum distance beetween defects
        8.1.4. Average diameter of defect
   8.2. Face defect standard (black spot, stain)
   8.3. Glass blemish
        8.3.1. Scratch
        8.3.2. Bubbles/foreign materials




Revision History
Rev         Date        Prepared by              Comments
09.99       24.09.99
02.00       14.02.00    J. Paukku                SMA241H added




2                                              446F
1. Product Overview
446F is a 19 inch monitor. The maximum resolution of 1600 x 1200 makes the monitor suitable for
PC, Macintosh and workstation applications in normally heated, ventialed and controlled office/home
environment. The monitor has an own power supply with nominal input voltage requirements from
90 V to 264 V.

1.1. Technical Specifications
Cathode Ray Tube . . . . . . . . . . 19" in diagonal 86
