Image preview - the first page of the document
>> Download Nokia_Lumia_530_RM-1017_RM-1018_Service_schematics documenatation <<
Text preview - extract from the document
Service schematics
IMPORTANT Version information
Nokia Lumia 530 This document is intended for use by authorized
Nokia service centers only. Please use the document
together with other documents such as the Service
While every effort has been made to ensure that the document is
accurate, some errors may exist. Please always check for the latest
published version for this document.
RM-1017 / RM-1018
Manual and Service Bulletins.
v1.0 - 25.07.2014
-First approved version.
Nokia Lumia 530 Version differences Contents
Dual SIM This document will cover following releases: 1
2
Front page
PM8110, MSM8212, Power, Side keys, USB
Nokia Lumia 530, RM-1017, Board: 4KT_SR (RoW) 3 MSM8212, Memory, Accelerometer, SIM(s), Display, Camera
RM-1019 / RM-1020 Nokia Lumia 530, RM-1018, Board: 4LT_SA (America)
Nokia Lumia 530 Dual SIM, RM-1019, Board: 4LU_DR (RoW)
4
5
Audio, BT/WLAN/FM
RF Transceiver, GPS
Nokia Lumia 530 Dual SIM, RM-1020, Board: 4LV_DB (Brazil) 6 Component finder Top (RM-1017)
7 Component finder Bottom (RM-1017)
8 Component finder Top (RM-1018)
9 Component finder Bottom (RM-1018)
10 Component finder Top (RM-1019)
11 Component finder Bottom (RM-1019)
12 Component finder Top (RM-1020)
13 Component finder Bottom (RM-1020)
