Image preview - the first page of the document
hfe_onkyo_a-9030_9050_en


>> Download hfe_onkyo_a-9030_9050_en documenatation <<

Text preview - extract from the document
                                                                  Contents
Integrated Amplifier                                    Introduction ...................................2




A-9050/                                                 Connections.................................12




A-9030                                                  Turning On & Basic Operations....... 21




Instruction Manual                                      Advanced Operations .................25




                                                        Others...........................................26




Thank you for purchasing an Onkyo Integrated
Amplifier. Please read this manual thoroughly before
making connections and plugging in the unit.
Following the instructions in this manual will enable
you to obtain optimum performance and listening
enjoyment from your new Integrated Amplifier.
Please retain this manual for future reference.




                                                                                                    En
     Introduction


          WARNING:                                                                  WARNING                         AVIS
                                                                                   RISK OF ELECTRIC SHOCK   RISQUE DE CHOC ELECTRIQUE
          TO REDUCE THE RISK OF FIRE OR ELECTRIC                                         DO NOT OPEN              NE PAS OUVRIR
          SHOCK, DO NOT EXPOSE THIS APPARATUS TO
                                                                                 The lightning flash with arrowhead symbol, within an
          RAIN OR MOISTURE.
                                                                                 equilateral triangle, is intended to alert the user to the
                                                                                 presence of uninsulated "dangerous voltage" within
          CAUTION:                                                               the product's enclosure that may be of sufficient
          TO REDUCE THE RISK OF ELECTRIC SHOCK,                                  magnitude to constitute a risk of electric shock to
          DO NOT REMOVE COVER (OR BACK). NO                                      persons.
          USER-SERVICEABLE PARTS INSIDE. REFER                                   The exclamation point within an equilateral triangle is
          SERVICING   TO   QUALIFIED    SERVICE                                  intended to alert the user to the presence of important
          PERSONNEL.                                                             operating and maintenance (servicing) instructions in
                                                                                 the literature accompanying the appliance.




     Important Safety Instructions
     1.    Read these instructions.                                    15. Damage Requiring Service
     2.    Keep these instructions.                                        Unplug the apparatus from the wall outlet and refer
     3.    Heed all warnings.                                              servicing to qualified service personnel under the
     4.    Follow all instructions.                                        following conditions:
     5.    Do not use this apparatus near water.                           A. When the power-supply cord or plug is damaged,
     6.    Clean only with dry cloth.                                      B. If liquid has been spilled, or objects have fallen
     7.    Do not block any ventilation openings. Install in                    into the apparatus,
           accordance with the manufacturer's instructions.                C. If the apparatus has been exposed to rain or water,
     8.    Do not install near any heat sources such as radiators,         D. If the apparatus does not operate normally by
           heat registers, stoves, or other apparatus (including                following the operating instructions. Adjust only
           amplifiers) that produce heat.                                       those controls that are covered by the operating
     9.    Do not defeat the safety purpose of the polarized or                 instructions as an improper adjustment of other
           grounding-type plug. A polarized plug has two blades                 controls may result in damage and will often
           with one wider than the other. A grounding type plug                 require extensive work by a qualified technician to
           has two blades and a third grounding prong. The wide                 restore the apparatus to its normal operation,
           blade or the third prong are provided for your safety.          E. If the apparatus has been dropped or damaged in
           If the provided plug does not fit into your outlet,                  any way, and
           consult an electrician for replacement of the obsolete          F. When the apparatus exhibits a distinct change in
           outlet.                                                              performance this indicates a need for service.
     10.   Protect the power cord from being walked on or              16. Object and Liquid Entry
           pinched particularly at plugs, convenience receptacles,         Never push objects of any kind into the apparatus
           and the point where they exit from the apparatus.               through openings as they may touch dangerous
     11.   Only use attachments/accessories specified by the               voltage points or short-out parts that could result in a
           manufacturer.                                                   fire or electric shock.
     12.   Use only with the cart, stand,      PORTABLE CART WARNING       The apparatus shall not be exposed to dripping or
           tripod, bracket, or table                                       splashing and no objects filled with liquids, such as
           specified by the manufacturer,                                  vases shall be placed on the apparatus.
           or sold with the apparatus.                                     Don't put candles or other burning objects on top of
           When a cart is used, use                                        this unit.
           caution when moving the                                     17. Batteries
           cart/apparatus combination to                                   Always consider the environmental issues and follow
                                              S3125A
           avoid injury from tip-over.                                     local regulations when disposing of batteries.
     13.   Unplug this apparatus during lightning storms or when       18. If you install the apparatus in a built-in installation,
           unused for long periods of time.                                such as a bookcase or rack, ensure that there is
     14.   Refer all servicing to qualified service personnel.             adequate ventilation.
           Servicing is required when the apparatus has been               (Leave 20 cm (8") of free space at the top and sides
           damaged in any way, such as power-supply cord or                and 10 cm (4") at the rear. When a shelf is located
           plug is damaged, liquid has been spilled or objects             above the unit, the rear edge of the shelf shall be set 10
           have fallen into the apparatus, the apparatus has been          cm (4") away from the backboard to improve
           exposed to rain or moisture, does not operate                   ventilation.)
           normally, or has been dropped.


En
2
Precautions
1. Recording Copyright--Unless it's for personal use
