Image preview - the first page of the document
Onkyo-C-707-Schematic


>> Download Onkyo-C-707-Schematic documenatation <<

Text preview - extract from the document
                                                                                       C-707CH
MECHANISM-EXPLODED VIEW & PARTS LIST        REF. NO.   PART NO.        DESCRIPTION
                                            1          45-093-4160     Chassis AS
                                            2          45-264-4159     Drawer
                                            3          45-093-4088     Holder L AS
                                            4          45-093-3249     Holder R AS
                                            11         45-093-4075     Gear Drive AS
                                            12         45-264-1109F    Carriage 10
                                            17         45-222-4022     Gear,Idler 2
                                            18         45-222-4060     Bevel,Gear 2
                                            19         45-093-4084     Gear Star AS
                                            23         45-112-3154     Cover 2
                                            24         45-300-4018     Shaft
                                            25         45-262-4019     Cap
                                            26         45-222-4021     Gear Spline
                                            27         45-222-4059     Bevel Gear 1
                                            28         45-222-4026     Gear Idler 1
                                            31         45-222-4058     Pulley C
                                            33         45-219-4062     Holder 2
                                            34         45-093-4076     Holder 1 AS
                                            35         45-259-2031     Slider 1
                                            36         45-093-4091     Slider 2 AS
                                            37         45-239-4064     Arm Stopper A
                                            38         45-239-4065     Arm Stopper B
                                            39         45-222-4128     Gear Idler A
                                            40         45-222-4051     Gear Idler C
                                            41         45-259-3008     Lever
                                            42         45-229-3024     Clamper A
                                            43         45-259-3025     Lifter
                                            44         45-239-1037     A rm
                                            45         36-067-4928     Magnet
                                            46         45-229-3069     Clamper B
                                            47         45-222-4052     Pulley A
                                            48         45-093-4162     Carriage Motor AS
                                            49         45-093-4163     Tray Motor AS
                                            50         01-000-4541     Spring C
                                            51         01-082-4558     Spring
                                            52         01-082-4559     Spring
                                            54         02-083-4167     Belt
                                            55         02-083-4174     Belt
                                            56         45-063-4136     Cushion
                                            57         45-211-3072     Frame
                                            58         45-063-4072     Rubber Cushion
                                            59         KSM213CCM       Pick-Up Drive
                                            60         01-081-4561     Spring
                                            61         01-081-4562     Spring
                                            62         45-264-1110F    Carriage 20
                                            63         45-264-1111F    Carriage 30
                                            67         45-219-4107     Plate E
                                            68         45-219-4127     Spacer
                                            70         45-070-3151     Pc Board       (Body)
                                            71         MPU10101MMB0    Switch
                                            72         MPU20273BLB0    Switch
                                            74         S4BEH           Connector
                                            75         45-072-4156     Wire
                                            76         45-070-4080     Wire
                                            77         45-072-4078     Wire
                                            78         45-070-4081     Wire
                                            79         45-072-4079     Wire
                                            80         S9BEH           Connector
                                            82         45-070-4155     Pc Board       (Body)
                                            83         16FMNSTRK       Connector
                                            84         45-072-4083     Card Wire
                                            86         PWNC00100XVV    Wire
                                            105        01-082-4577     Spring
                                            112        GWP23X055025    Washer P
                                            113        GWP15X045025S   Washer
                                            114        GSL20A2010      Screw
                                            115        GSL20A2606      Screw
                                            119        GSL10B2006      Screw
                                            120        GSN31X120050    Washer P
                                            121        03-300-4366     Screw
                                            123        GSP14A2604      Screw
                                            124        GSL20A2610      Screw
                                            125        GSL20A2006      Screw
                                            126        03-000-4427     Washer P
                                            127        GST15A2005      Screw




                             21        22
