Image preview - the first page of the document
technical_tip_htr330_ti_ta_ti_ta_115


>> Download technical_tip_htr330_ti_ta_ti_ta_115 documenatation <<

Text preview - extract from the document
                                         CONFIDENTIAL

                                                                                        Technical Tip
18 Park Way, Upper Saddle River, NJ 07458
                                          Date: May 25, 2006
 _____________________________________________________________

 Model: HT-R330


 Subject: Relay constantly clicks, won't power ON Only sound TiTa TiTa


 Symptom: The relays click but the set will not power ON. Tip Ta Tod only

 Solution: Check Fuse resistor R9532 0.22 ohm 1/2 W for an open condition
                 Lost +12 V to Reg IC Q5640 Unit will not turn on.




 Check from pin 11 S3GND to pin 14 and 13 About 10V AC Same as
 SEC2-1 and SEC2-2 on JL9501A or JL9501B also P9502A and P9502
 AC input to D9005 on U05 NAAF-8523 Board. When you lost any AC
 SEC2-1 or SEC2-2 lost +12V to Reg IC Q5640.
 Unit will have Tip Ta Tod relay sound . Power will not turn on.
