Image preview - the first page of the document
>> Download hfe_onkyo_integra_dtr-10-5_service documenatation <<
Text preview - extract from the document
DTR-10.5
Ref. No. 3860
SERVICE MANUAL Dec, 2004
AV RECEIVER
MODEL DTR-10.5
On Standby
TV
I Input
1 2 3 +
@.-'/ ABC DEF TV CH
4 5 6 -
GHI JKL MNO
7 8 9
PQRS TUV WXYZ TV VOL
+10 0 Clear
#
--/ --- Direct Tuning
Master Volume
Custom
Zone 3
Standby/On
Macro Zone 2
Mode Input
Dimmer Sleep
Standby u Men
TV Men u
Input Top
Display Tape 1 Tape 2 Tuner Phono CD Net Audio rv er Aud
io
Se A
Rec/ Zone 3 ( Red )
+
DJ
Main ( Blue)
Zone 2 ( Green ) CH Enter VOL
Disc
DVD Video 1 Video 2 Video 3 Video 4 Video 5 Video 6 Video 7 Open
Pure Audio -
Exi id e
t Gu
Prev Re
tu p
CH rn Se t u
Display Muting
Rec Main A Main B Random
Audio Subtitle Angle Last Memory
Surr und
o THX AllCH ST Stereo
Repeat A-B Search Memory
Pure A Direct DSP DSP
Repeat Video Music Photo
Test Tone CH SEL Level - Level +
Playlist Album Artist Genre
Audio SEL L Night Re-EQ
Caps Delete Language Loca t ion
Black model
RC-556M
BUDD 120V AC, 60Hz
BUPA 230V-240V AC, 50Hz
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK ON THE
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
DTR-10.5
SPECIFICATIONS
General Miscellaneous
Power Supply Rating 12V Trigger out (1/8-inch
USA and Canadian models: AC 120V, 60 Hz mini-jack): 5 (for A, B, C, D, E)
Australian models: AC 230-240V , 50 Hz Inputs/Outputs:
Miscellaneous
Consumption Power i. LINK(A UDIO) (4 pin): 2
USA & Canadian models: 13.8A Ethernet (Net-Tune):
Australian models: 1,200 W (option) 1
Standby Power Consumption: 3.9 W (1/8-inch mini-jack): 1
Dimensions (W H D): 435 220 480.5 mm RS232 (9 pin D-SUB
(17-1/8" 8-11/16" 18-15/16") Female connector): 1
Weight: 33 kg (72.8 lbs) Antennas:
Inputs: FM: 75 ohms unbalanced
Audio AM: Included loop antenna and external
Multichannel (7.1ch) Inputs: 2 terminal
Phono (MM): 1 AC Inlet: 1 (IEC type)
Line inputs: 9 (assignable), 1 (Fixed) (Video 7 AC Outlets:
on the front panel) USA & Canadian models: 1 (Switched, 120 W 1A max.)
Digital inputs Coaxial: 6 Australian models: 1 (Switched, 100 W max.)
Digital inputs Optical: 6 (assignable), 1 (Fixed) (Video 7
on the front panel)
Video Amplifier Section
Composite Video inputs: 6 (assignable),
1 (fixed, on the front panel) Power Output (All channels):
S Video inputs: 6 (assignable), USA & Canada (FTC): 150 Watts per channel min. RMS
1 (fixed, on the front panel) into 8 ohms 2 channel driven,
Component Video RCA fr om 20 to 20,000 Hz with no
inputs: 3 more than 0.05% total harmonic
Component Video BNC distortion.
input: 1 (Australian models) 200 Watts per channel min. RMS
Audio and Video into 6 ohms 2 channel driven, 1,000
HDMI inputs (19-pin): Hz with no more than 0.1% total
(option) 2 harmonic distortion.
Miscellaneous 3-IR in (Phoenix connector) for 260 Watts per channel min. RMS
Main, Zone 2 and Zone 3 into 8 ohms 2 channel driven,
Outputs: 1,000 Hz with no more than 0.1%
Audio total harmonic distortion. [BTL]
Speakers A: Front L/R, Center, Surround L/R, Australian model (DIN): 200 Watts per channel min. RMS
Surround Back L/R into 6 ohms 2 channel driven, 1,000
Speakers B: Front L/R, Center, Surround L/R, Hz DIN
Surround Back L/R or Po wered 280 Watts per channel min. RMS
Zone 2 L/R into 8 ohms 2 channel driven, 1,000
Pre out A: Front L/R, Center, Surround L/R,
Hz DIN [BTL]
Surround Back L/R, Subwoofer
Pre out B: Subwoofer
Headphones: 1
Line outputs: 5 (assignable to Recout, Zone 2 out
and Zone 3 out)
Digital outputs Coaxial: 2 (assignable to Recout, Zone 2 out Dynamic Power:
2 340W (3 , 2 channel driv en)
and Zone 3 out)
2 260W (4 , 2 channel driven)
Digital outputs Optical: 2 (assignable to Recout, Zone 2 out
2 175W (8 , 2 channel driven)
and Zone 3 out) THD (Total Harmonic Distor-
Video
tion): 0.05% (rated po wer)
Composite Video outputs: 3 (assignable to Monitor out A/B,
0.05% (1 watt output)
Recout, Zone 2 out and Zone 3 out)
Damping Factor: 60 at 8 ohms
1 (fixed, Monitor out A) IM Distortion: 0.05% (rated power)
S Video outputs: 3 (assignable to Monitor out A/B
0.05% (1 watt output)
and Recout) Input Sensitivity and Impedance:
1 (fixed, Monitor out A) Audio 200 mV, 50 k (AUDIO IN 1-9/
Component Video RCA FRONT)
outputs: 1 2.5 mV , 50 k (PHONO MM)
Component Video BNC
200 mV, 50 k (MULTI IN FR/FL/
output: 1 (Australian models)
C/SR/SL/SBR/SBL)
Audio and Video 36 mV 50 k (MULTI IN SUB)
,
HDMI output (19-pin):
0.5 Vp-p,75 (DIGITAL IN
(option) 1
COAXIAL 1-6)
Video (DVD, VIDEO 1-5) 1 Vp-p, 75 (Composite Video)
1 Vp-p, 75 (S Video,Y signal)
0.28 Vp-p,75 (S Video, C signal)
Component 1 Vp-p, 75 (Y)
0.7 Vp-p,75 (PB/CB, PR/CR)
DTR-10.5
SPECIFICATIONS
Output Level and Impedance: AM
Audio Tuning frequency Range:
AUDIO 1-5: 200 mV, 470 (Tape 1/2/ Video USA & Canadian models: 530 to 1710 kHz, 10 kHz steps
1/2/3 Rec Out) Australian models: 522 to 1611 kHz, 9 kHz steps
