Image preview - the first page of the document
>> Download hfe_onkyo_tx-nr3010_service_en documenatation <<
Text preview - extract from the document
TX-NR3010
Ref. No. 4402
072012
AV RECEIVER
MODEL TX-NR3010(B)/(S)
European, Australian and Asian models ---> "RT/PTY/TP"
North American and Taiwanese models only North American and Taiwanese models ---> "DIMMER"
RC-840M
Black and Silver models
B MDC 120V AC, 60Hz
B MMP, S MMP 220-240V AC, 50/60Hz
B MMR 220-240V AC, 50/60Hz
TX-NR3010
SERVICE PROCEDURE-1
1. Replacing the fuses
This symbol located near the fuse indicates that the
fuse used is slow operating type, For continued protection against
fire hazard, replace with same type fuse, For fuse rating, refer to
the marking adjacent to the symbol.
Ce symbole indique que le fusible utilise est e lent.
Pour une protection permanente, n'utiliser que des fusibles de meme
type. Ce demier est indique la qu le present symbol est apposre. : 120V,Canadian model
: 230V,CE(European) country model
REF NO. PART DESCRIPTION PART NO. REMARKS : 220/230-240V,Chinese model
NAME
F2001, F2002 FUSE 4A-UL/T-233 252325GR !
F2001, F2002 or FUSE 4A-T/UL-ST2 252257GR !
F6601 FUSE 20A-UL-250V 252304GR !
F6602 FUSE 20A-UL-250V 252304GR !
F6603 FUSE 20A-UL-250V 252304GR !
F6604 FUSE 20A-UL-250V 252304GR !
F9100 FUSE 12A-TUL-250V 252301GR !
F9100 or FUSE 12A-UL/T-314 252196GR !
F9100 FUSE 6.3A-SE-EAK 252079GR !
F9100 or FUSE 6.3A-SE-TL250V 252279GR !
F9301, F9401, F9402 FUSE 3.15A-UL/T-233 252323GR !
F9301, F9401, F9402 or FUSE 3.15A-T/UL-ST2 252256GR !
F9001 FUSE 1A-SEUL-TL250V 252397T !
2. Safety check out
(U.S.A. model only)
After correcting the original service problem, perform the following safety check before releasing the unit to the customer.
Leakage current Check
Measure the leakage current to a known earth ground (water pipe or conduct etc.) by connecting a leakage current
tester between the earth ground and exposed metal parts of the unit (input/output ground terminals, screw heads or metal overlays etc.).
Plug the power supply cord directly into a 120Vac 60Hz wall socket and turn ON/STANDBY button on.
Any current measured must not exceed 0.5mA.
3. To initialize the unit
1. Press ON/STANDBY button while pressing down CBL/SAT button when the unit is POWER ON, then the FL displays
"CLEAR", and turn to STAND-BY.
Preset memory and each mode stored in the memory, are initialized and will return to the factory settings.
Clear Stand-by
2. Remove power cord from wall outlet.
ON/STANDBY CBL/SAT
TX-NR3010
SERVICE PROCEDURE-2
4. To check version of each Firmware
ON/STANDBY (TONE) (TONE) DISPLAY
1. During the POWER ON, please push ON/STANDBY button while pushing down DISPLAY button.
2. The version of main multiprocessor is displayed at FL tube (only 3 seconds).
1.04/12712AH
3. While the version of main microprocessor is displaying, please push (TONE) + button.
4. FL tube displays by rotation as follows.
Version displayed
(TONE)
only for 3 seconds.
1.04/1271 2 A H Main Microprocessor
(TONE)
(TONE)
1.03/1270 9 A H A 1st DSP/ NET
(TONE)
(TONE)
1.00/1253 1 a H A 2nd DSP
(TONE)
(TONE)
1.02/1271 8 A H HDMI/Video Microprocessor
(TONE)
(TONE)
1.01/1252 8 A E O VSP (Video Signal Processor)
(TONE)
(TONE)
1.00/122 0 7 A OSD (On Screen Display)
(TONE)
5. Push ON/STANDBY (Power Off).
TX-NR3010
SERVICE PROCEDURE-3
5. Notes on repairs (Power supply board)
Some parts on BAPS-0890 may remain high voltages
even after the power cord is disconnected from AC power source.
Before starting repair and any other work , please discharge C9002 by connecting resistors between its terminals. See the figure below
(recommended resistor spec: 5 k ohms/ 10W)
It is dangerous to touch the "PRIMARY" area surrounded by white lines without discharging.
U0063
POWER SUPPLY(PRI) PC BOARD ASS'Y
BAPS-0890
--- Side-B ---
PRIMARY
Top
Resistor
TX-NR717/818/1010/3010/5010
DEBUG MODE-1
AUDIO DEBUG MODE-1/4
AUDIO DEBUG MODE (Display mode of the audio information)
The operations of DSP and DIR etc are able to checked by the information displayed on FL in this debug mode.
This information will help to analysing digital audio no sound trouble.
To set in Debug mode
1. Press and hold down DISPLAY button, then press ON/STANDBY button.
e.g.
Main: The version number of microprocessor is displayed
1.02/12611AH only for 3 seconds.
2. Press + (TONE) button while the version number of microprocessor is displayed.
e.g.
DSP 1st/NET: The version number of DSP is displayed
1.02/12608AHA only for 3 seconds.
3. Press DISPLAY button while the version number of DSP is displayed.
e.g. Audio dubug mode
0A0002: : 00
ANA: o: NON: : Step-1
4. Press DISPLAY button. 10. Press DISPLAY button.
e.g. e.g. Step-8
1: ANA 048k048k Step-2 LB : 0 0
2/ 0. 0: 2. 0: 3/4 RB : 0 0
11. Press DISPLAY button.
5. Press DISPLAY button. e.g.
LH : 0 0 Step-9
e.g.
2: o: PCM : PCM Step-3
RH : 0 0
00: x: F: OFF
12. Press DISPLAY button.
6. Press DISPLAY button. e.g.
e.g. LW : 0 0 Step-10
SP00F * 00F00409 Step-4
RW : 0 0
48 48256STB
13. Press DISPLAY button.
7. Press DISPLAY button.
e.g. Step-11
e.g.
L : 0 0 Step-5
SW : 0 0
R : 0 0 SW2 : 0 0
8. Press DISPLAY button. 14. Press DISPLAY button.
e.g.
C : 0 0 Step-6 Exit
9. Press DISPLAY button.
e.g. LS : 0 0 Step-7
RS : 0 0
TX-NR717 TX-NR818/1010/3010/5010
ON/STANDBY + (TONE) DISPLAY
ON/STANDBY + (TONE) DISPLAY
TX-NR717/818/1010/3010/5010
DEBUG MODE-2
AUDIO DEBUG MODE-2/4
Contents of Display
FL Display
Display area
Step-1 e.g.
0A0002: : 00
ANA: o: NON: :
1 2 3 A B
C D E F G
1. st_srd.lmd 2. st_srd.extdec B. Factor of muting
C_LM_LAST : 01 C_EXTDEC_OFF : 00 bit_1 : SEL MUTE
C_LM_PURE : 02 C_EXTDEC_20_PLII : 01 bit_2 : POW MUTE
C_LM_DIRECT : 03 C_EXTDEC_20_PLIIX : 02 bit_3 : PROTECT MUTE
C_LM_STEREO : 04 C_EXTDEC_20_PLIIZ : 03 bit_4 : AUDIO OUT MUTE
C_LM_MONO : 05 C_EXTDEC_20_NEO6 : 04 bit_5 : AUDIO MUTE
C_LM_SURR : 20 C_EXTDEC_51_MTR : 05
C_LM_THX_MUSIC : 50 C_EXTDEC_51_DSC : 06 C. Input terminal
C_LM_THX_GAME : 70 C_EXTDEC_51_NEO6 : 07 ANA : Analog
C_LM_THX_CINEMA : 90 C_EXTDEC_51_EX : 08 COX : Caxal
C_LM_THX_U2GAME : A0 C_EXTDEC_51_PLIIX : 09 OPT : Optical
C_LM_THX_U2MUSIC : A8 C_EXTDEC_51_PLIIZ : 0A HDM : HDMI
C_LM_THX_U2CINEMA : B0 C_EXTDEC_9624 : 0B ARC : ARC
C_LM_AUDYSSEY : D0 C_EXTDEC_9624_MTR : 0C
C_LM_DTSSS : 48 C_EXTDEC_71MULTI : 0E
C_LM_ORCHESTRA : 06
D. DSP Detect
C_EXTDEC_20_NEURAL : 0F
C_LM_UNPLUGGED : 07 o : DSP Detect OK
C_EXTDEC_51_NEURAL : 10
C_LM_STUDIOMIX : 08 x : DSP No detect
C_LM_TVLOGIC : 09
C_LM_ALLCHST : 0A 3. st_srd.extdecmd
E. Sound state
C_LM_FULLMONO : 0B C_EXTDECMD_OFF : 00 STB : SOUND STATE FIX
C_LM_TD : 0C C_EXTDECMD_10 : 01 TRS : SOUND STATE UNFIX
C_LM_TESTTONE : F1 C_EXTDECMD_20 : 02 NON : SOUND STATE NONE
C_LM_TESTTHR : F2 C_EXTDECMD_MOVIE : 03
C_LM_TESTAUTO : F3 C_EXTDECMD_MUSIC : 04
C_LM_ASC : F4 C_EXTDECMD_GAME : 05 F. Display inhibit
C_LM_FLASH : F5 C_EXTDECMD_HEIGHT : 06 S : display_inhibit SET
C_LM_DEBUGMODE : F6 C_EXTDECMD_WIDE : 07 C : display_inhibit CLR
C_LM_FLASH2 : F7
C_LM_FLASH3 : F8 4. Muting port
C_LM_FLASH4 : F9 G. HDMI mute
D : DIGMUTE port
C_LM_FLASH_CHECK : FA V : HDMI MUTE
A : AMUTE port
C_LM_RPG : 0D
C_LM_ACTION : 0E
C_LM_ROCKBAND : 0F
C_LM_SPORTS : 10
TX-NR717/818/1010/3010/5010
DEBUG MODE-3
AUDIO DEBUG MODE-3/4
Step-2 e.g.
1: ANA 048k048k
2/ 0. 0: 2. 0: 3/4
1 2 3
4 5 6 7
1. Type of input format 4. Number of input channels
(source_format) for listening mode transition
UNLK : DDR_UNLOCK
ANA : DDR_ANALOG 5. Input channel
PCM : DDR_PCM
AC3 : DDR_AC3 (st_srd.lfe, st_srd.lfe2)
DTS : DDR_DTS 0 : SW 0ch
MPEG : DDR_MPEG 1 : SW 1ch
DATA : DDR_DATA 2 : SW 2ch
UNKW : DDR_UNKNOWN
NORD : DDR_NOT_READY
NPCM : DDR_NOT_PCM 6. Number of channels for display
FS96 : DDR_FS96 "10.2" "5.1" "1 +1" four-digit string
NODT : DDR_NOT_DETECT
DTSC : DDR_DTSCD
AAC : DDR_AAC 7. Number of channels after
MPCM : DDR_MCHPCM the decoding process
MCH : DDR_MCH (hd_dec_prgfmt)
TRUE : DDR_TRUE ??? : C_FMT_UNKNOWN
MSTR : DDR_MSTR 10 : C_FMT_10
DSD : DDR_DSD 20 : C_FMT_20
PLUS : DDR_DDPLUS 30 : C_FMT_30
EXPR : DDR_DTSEXP 21 : C_FMT_21
DTSH : DDR_DTSHD 31 : C_FMT_31
22 : C_FMT_22
32 : C_FMT_32
2. Sampling frequency 23 : C_FMT_23
(st_srd.fs) 33 : C_FMT_33
24 : C_FMT_24
3. Sampling frequency for display 34 : C_FMT_34
(st_srd.fs) 4H2 : C_FMT_42H
5H2 : C_FMT_52H
??? : unknown 4W2 : C_FMT_42W
008 : 8kHz 5W2 : C_FMT_52W
011 : 11kHz 4H4 : C_FMT_44H
012 : 12kHz 4H3 : C_FMT_43H
016 : 16kHz 5H4 : C_FMT_54H
022 : 22kHz 5H3 : C_FMT_53H
024 : 24kHz 4W4 : C_FMT_44W
032 : 32kHz 4W3 : C_FMT_43W
044 : 44.1kHz 5W4 : C_FMT_54W
048 : 48kHz 5W3 : C_FMT_53W
064 : 64Hz 11 : C_FMT_11
088 : 88.2kHz
096 : 96kHz
176 : 176.4kHz
192 : 192kHz
TX-NR717/818/1010/3010/5010
DEBUG MODE-4
AUDIO DEBUG MODE-4/4
Step-3 e.g.
2: o: PCM : PCM
00: x: F: OFF
8 9 10
11 12 13 14 15
8. Audio output OK? 10. Details of input format for display 11. Dialog Norm
(f_dsp_detect_ok) (st_hd_display.source) (st_srd.dnorm)
o : Decode OK ANA : C_SRC_ANA Dialog Norm value of 0 to 31
x : Decode NG PCM : C_SRC_PCM
DLB : C_SRC_DD 12. DIRINT
DEX : C_SRC_DD_EX
9. Details of input format The return value of ddr
DTS : C_SRC_DTS Request_dir (DDC_STATUS)
(st_srd.source) MTR : C_SRC_DTS_MTR
DSC : C_SRC_DTS_DSC o : LOCK
D96 : C_SRC_DTS_96 x : UNLOCK
96M : C_SRC_DTS_96M
AAC : C_SRC_AAC 13. DIR busy or free
MCH : C_SRC_MCH The return value of ddr Request_dir
DSP : C_SRC_DSP (DDC_BUSY)
MPCM : C_SRC_MCHPCM
F : Free
DSD : C_SRC_DSD
B : Busy
TRUE : C_SRC_TRUE
TREX : C_SRC_TRUE_EX 14. Emphasis information
MSTR : C_SRC_MSTR (f_dir_empha_mode)
PLUS : C_SRC_DDPLUS ON : ON
PLEX : C_SRC_DDPLUS_EX OFF : OFF
EXP : C_SRC_DTSEXP
DTSH : C_SRC_DTSHD 15. HDDVD/BLUE(Only DDPLUS)
DSUR : C_SRC_DD_SUR
DPSR : C_SRC_DDPLUS_SUR BD : Blu-ray
TRSR : C_SRC_TRUE_SUR HD : HDDVD
Step-5 to Step-11
e.g. L : 0 0
A B
R : 0 0
C : 0 0
LS : 0 0
RS : 0 0
LB : 0 0
A. The sum of the values of Volume correction related to the DSP.
RB : 0 0
B: The sum of the values of Volume correction, including correction
LH : 0 0 of the Analog stage.
RH : 0 0
LW : 0 0
RW : 0 0
SW : 0 0
SW2 : 0 0
TX-NR717/818/1010/3010/5010
DEBUG MODE-5
HDMI DEBUG MODE-1/7
HDMI-related operations can be checked to some extent by displaying HDMI debug mode.
To enter this mode
Hold down DISPLAY button for 3 seconds. Information display will last for about 8 seconds.
Content of Display
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Resolution display
1 2 3 4 5 6 7 8 9 10 11 12 13 14
The first line : Input resolution
10 80 i / 6 0
10 80 i / 6 0 Second line : Output resolution
List of standard resolution
4 8 0 i / 6 0 # 5 7 6 i / 5 0 5 7 6 p 2 0 0
4 8 0 p / 6 0 # 5 7 6 p / 5 0 5 7 6 i 2 0 0
1 0 8 0 i / 6 0 # 2 8 8 p / 5 0 4 8 0 p / 6 0
7 2 0 p / 6 0 1 0 8 0 p / 2 4 4 8 0 p 2 4 0
1 0 8 0 p / 6 0 1 0 8 0 p / 2 5 4 8 0 i 2 4 0
2 4 0 p / 6 0 1 0 8 0 p / 3 0 * 4 8 0 p / 6 0
# 4 8 0 i / 6 0 VGA * 5 7 6 p / 5 0
# 4 8 0 p / 6 0 1 0 8 0 i 1 0 0 7 2 0 p / 2 4
# 2 4 0 p / 6 0 7 2 0 p 1 0 0 7 2 0 p / 2 5
5 7 6 i / 5 0 5 7 6 p 1 0 0 7 2 0 p / 3 0
5 7 6 p / 5 0 5 7 6 i 1 0 0 U N K N OWN
1 0 8 0 i / 5 0 1 0 8 0 i 1 2 0
7 2 0 p / 5 0 7 2 0 p 1 2 0
1 0 8 0 p / 5 0 4 8 0 p 1 2 0
2 8 8 p / 5 0 4 8 0 i 1 2 0
TX-NR717/818/1010/3010/5010
DEBUG MODE-6
HDMI DEBUG MODE-2/7
Display of Input resolution
1 2 3 4 5 6 7 8 9 10 11 12 13 14
first line ---> 10 80 i / 6 0
10 80 i / 6 0
DVI input signal 1 2 3 4 5 6 7 8 9 10 11 12 13 14
i / p will be capitalized.
4 80 I / 6 0
1 2 3 4 5 6 7 8 9 10 11 12 13 14
4 80 P / 6 0
VGA input signal 14
1 2 3 4 5 6 7 8 9 10 11 12 13
Display the " " in column 1
VGA
No input 1 2 3 4 5 6 7 8 9 10 11 12 13 14
U n k n own
TX-NR717/818/1010/3010/5010
DEBUG MODE-7
HDMI DEBUG MODE-3/7
Display of Output resolution
1 2 3 4 5 6 7 8 9 10 11 12 13 14
10 80 p / 6 0
Second line ---> 10 80 i / 6 0
For a video processor Via VSP
Display the " " 1 0 8 0 i / 6 0
in column 5 1 2 3 4 5 6 7 8 9 10 11 12 13 14
VSP skip
1 0 8 0 i / 6 0
1 2 3 4 5 6 7 8 9 10 11 12 13 14
DVI input signal
i / p will be capitalized.
4 80 I / 6 0
1 2 3 4 5 6 7 8 9 10 11 12 13 14
4 80 P/ 6 0
1 2 3 4 5 6 7 8 9 10 11 12 13 14
VGA input signal Display the " "
in column 5 4 80 p/ 6 0
1 2 3 4 5 6 7 8 9 10 11 12 13 14
RSEN is OFF
Display the " "
in column 14 4 80 p/ 6 0
1 2 3 4 5 6 7 8 9 10 11 12 13 14
EDID_READ is NG
Display the " # "
in column 14 4 80 p/ 6 0#
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Resolution Error Display the " x "
in column 14 4 80 p/ 6 0x
1 2 3 4 5 6 7 8 9 10 11 12 13 14
No output
(Signal output destination
can not be found.) - - - - - -
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Hot-plug of Sink equipment
can not be detected. OFF
1 2 3 4 5 6 7 8 9 10 11 12 13 14
TX-NR717/818/1010/3010/5010
DEBUG MODE-8
HDMI DEBUG MODE-4/7
4K Upscaling
Display of input resolution
First line ---> 1 0 8 0 i / 6 0
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Display of Output resolution
Second line ---> x p /
1 2 3 4 5 6 7 8 9 10 11 12 13 14
If the three-digit numbers are refrate
11 12 13 14
List of resolution
3 8 40 x 2 1 60 p / 30
1 2 3 4 5 6 7 8 9 10 11 12 13 14
3 8 40 x 2 1 60 p / 25
1 2 3 4 5 6 7 8 9 10 11 12 13 14
3 8 40 x 2 1 60 p / 24
1 2 3 4 5 6 7 8 9 10 11 12 13 14
4 0 96 x 2 1 60 p / 24
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Resolution Error 3 8 40 x 2 1 60 p / 30x
1 2 3 4 5 6 7 8 9 10 11 12 13 14
EDID_READ_NG 3 8 40 x 2 1 60 p / 30#
1 2 3 4 5 6 7 8 9 10 11 12 13 14
TX-NR717/818/1010/3010/5010
DEBUG MODE-9
HDMI DEBUG MODE-5/7
Display of 3D resolution
1 2 3 4 5 6 7 8 9 10 11 12 13 14
First line --->
Resolution 10 80 p / 2 4 (3D)
Second line --->
Status
H DM I 4 4 4 36b i t
Display of Input resolution
RSEN OFF
First line --->
Display the " " 1 0 80 p / 24 ( 3 D)
in column 14 1 2 3 4 5 6 7 8 9 10 11 12 13 14
EDID READ NG
Second line --->
Display the " # "
in column 9
H DM I 44 4# 3 6 b i t
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Resolution Error
First line --->
Display the " x " 1 0 80 p / 24 ( 3 D) x
in column 13
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Status
Input Mode HDMI input
Second line ---> H DM I 44 4 3 6 b i t
1 2 3 4 5 6 7 8 9 10 11 12 13 14
DVI input
Second line --->
DV I 44 4 3 6 b i t
1 2 3 4 5 6 7 8 9 10 11 12 13 14
No input
Second line ---> - - - 44 4 3 6 b i t
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Input Color RGB H DM I RGB 3 6 b i t
Second line ---> 1 2 3 4 5 6 7 8 9 10 11 12 13 14
422
Second line --->
H DM I 42 2 3 6 b i t
1 2 3 4 5 6 7 8 9 10 11 12 13 14
444
Second line ---> H DM I 44 4 3 6 b i t
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Deep Color
24bit H DM I RGB 2 6 b i t
Second line ---> 1 2 3 4 5 6 7 8 9 10 11 12 13 14
30bit H DM I RGB 3 0 b i t
Second line ---> 1 2 3 4 5 6 7 8 9 10 11 12 13 14
36bit
Second line --->
H DM I RGB 3 6 b i t
1 2 3 4 5 6 7 8 9 10 11 12 13 14
TX-NR717/818/1010/3010/5010
DEBUG MODE-10
HDMI DEBUG MODE-6/7
3D format
Frame Packing
First line ---> F r a me Pac k i ng
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Field alternative
F i e l d
a l t e r n a t i v e
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Line alternative
L i n e
a l t e r n a t i v e
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Side-by-Side(Full)
S i d e - by - S i d e
( F u l l )
1 2 3 4 5 6 7 8 9 10 11 12 13 14
L+depth
First line ---> L d ep t h
1 2 3 4 5 6 7 8 9 10 11 12 13 14
L+depth + graphics
L d ep t h
g r a ph i c
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Side by Side(Harf)
S i d e - by - S i d e
( Ha r f )
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Top and Bottom
T o p - a n d - B o t t om
First line ---> 1 2 3 4 5 6 7 8 9 10 11 12 13 14
unknown
First line ---> UN K N OWN
1 2 3 4 5 6 7 8 9 10 11 12 13 14
INPUT/ OUTPUT
I NPUT :
OU T PU T :
1 2 3 4 5 6 7 8 9 10 11 12 13 14
TX-NR717/818/1010/3010/5010
DEBUG MODE-11
HDMI DEBUG MODE-7/7
PC resolution
First line --->
Input Resolution 1 0 2 4x 76 8 p/ 6 0
Second line --->
Output Resolution 1 0 2 4x 76 8 p/ 6 0
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Display of Input resolution
First line ---> x p /
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Horizontal resolution Vertical resolution Referat
DVI input Display uppercase P/I
1 0 24 x 768P/ 6 0
1 2 3 4 5 6 7 8 9 10 11 12 13 14
HDMI input Display lowercase p/i
1 0 24 x 768p / 6 0
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Three-digit numbers
are Referat 1 0 24 x 768P12 0
1 2 3 4 5 6 7 8 9 10 11 12 13 14
No input
U N K N OW N
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Display of Output resolution
Second line ---> x p /
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Horizontal resolution Vertical resolution Referat
DVI output Display uppercase P/I
1 0 24 x 768P/ 6 0
1 2 3 4 5 6 7 8 9 10 11 12 13 14
HDMI output Display lowercase p/i 1 0 24 x 768p / 6 0
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Display"-----"
- - - - -
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Three-digit numbers
are Referat
1 0 24 x 768P12 0
1 2 3 4 5 6 7 8 9 10 11 12 13 14
EDID READ NG Display the " # " in
column 13 1 0 24 x 768P/ 6 0 #
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Resolution through Display the " x " in
column 13 1 0 24 x 768P/ 6 0x
1 2 3 4 5 6 7 8 9 10 11 12 13 14
INPUT/ OUTPUT
IN :
OU T :
1 2 3 4 5 6 7 8 9 10 11 12 13 14
TX-NR1010/3010/5010/ DTR-70.4
OPERATION CHECK-1
1.OPERATION CHECK(1/3)
1-1. OPERATIONS OF SPEAKER RELAYS
The relay shall be ON about 10 seconds after POWER is ON and shall be OFF immediately after POWER is OFF.
1-2. OPERATIONS OF VOLTAGE-DETECTION PROTECTORS.
See "OPERATION CHECK-4, -6" for TEST MODE operation.
NOTE: Don't connect load nor short speaker terminals.
(How to check in test mode)
a. Change the state to "TEST-4-24".
b. It tests by being automatic in order of TEST4-24(FL+) 25(FR-) 26(C+) 27(SL-) 28(SR+) 29(SBL-)
30(SBR+) 31(FHL-) 32(FHR+). If TEST-4-32 is ok, it becomes the display of "TEST-4-42."
c. It will complete, if displayed on FL TUBE as "TEST-4-42."
1-3. OPERATIONS OF CURRENT-DETECTION PROTECTORS
See "OPERATION CHECK-4, -6" for TEST MODE operation.
a. Change the state to "TEST 4-42".
Even if you connect 3-ohm load for every channel of L, R, C, SL, SR, SBL,SBR,FHL and FHRch, a relay should not cut off.
b. If 1-ohm load is connected for every channel of L,R,C,SL,SR,SBL,SBR,FHL and FHRch, a relay should hold the state of ON.
1-4. CONFIRMATION OF RDS (RADIO DATA SYSTEM) OPERATION
(applies to MMA/MMP/MMQ/MMR Type. )
a. Input 98MHz,30dB signal modurated with RDS data.
b. When a PS information is received, the name of the station "RDS TEST" shall be displayed within 2 seconds instead of the frequency.
1-5. CONFIRMATION OF HEAD PHONE OPERATION.
Confirm the Listening Mode is automatically switched to "STEREO" mode when headphones plug is inserted into the PHONES jack.
1-6. CONFIRMATION OF 12V TRIGGER OPERATIONS .
See "OPERATION CHECK-4, -5" for TEST MODE operation.
a. After checking that there is no output from 12V TRIGGER Z2 terminal,it checks that there is an output
of 12V ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
