Image preview - the first page of the document
>> Download hfe_onkyo_bd-sp309_service_en documenatation <<
Text preview - extract from the document
BD-SP309
Ref. No. 4289
042011
NO Repair Parts Availavility.
BLU-RAY DISC PLAYER
MODEL BD-SP309(B)/(S)
RC-825DV RC-826DV
(CDC only) (except CEC)
Black and Silver models
B CUP2BP 100~240V AC, 50/60Hz EU
B CUA4BP AUSTRALIA/NEW ZEALAND
B CUR6CP RUSSIA
B CUT3AP HONG KONG/SINGAPORE/MALAYSIA/THAILAND/KOREA
B CDC1AN 120V AC, 60Hz US/CANADA
S CUP2BP 100~240V AC, 50/60Hz EU
S CUR6CP RUSSIA
BD-SP309
SERVICE PROCEDURE - 1
This Player is classified as a CLASS 1 LASER product.
The CLASS 1 LASER PRODUCT label is located on
the rear cover.
This product contains a low power laser device. To
ensure continued safety do not remove any cover or
attempt to gain access to the inside of the product.
Refer all servicing to qualified personnel.
Precautions for using lead-free solder
Employing lead-free solder
