Washing machines                                                        599 50 86 52         EN

Poor Drain Behavior, BR 1995, Manufacturing Nuremberg
replaces Service Bulletin 599 50 86 52 from 12.07.00

The pumping behavior is basically dependent on a well vented drain pump. An included air bubble in the
pump casing worsens the pump capacity. The after-sales service can apply following measures:

1.    Build in a drain pump with a check valve in the suction connection (however, it is already existing in
      most dishwashers)., no. 899 646 403 658/2.

2.    Use the one-part drain hose, no. 111 827 000/6.

3.    Like shown in the picture below you have to fix the drain hose upwards from the pump an fit it with a
      cable holder, no. 899 669 915 713/8.

                                                                                         cable holder

4.    In some cases is the drain hose too short and must be extended, no. 899 646 403 270/6.
