Image preview - the first page of the document

>> Download 599510856 documenatation <<

Text preview - extract from the document

Washing appliances                                                      599 51 08 56   EN

Complaint about the washing result in the upper basket

The reason for above-mentioned complaint may be a pressed
connection seal pos. 130 B.

                                                   cut two notches here

As it can be seen on the picture, cut two notches into the connection

We recommend to turn the connection seal inside out and rework with
side-cutting pliers.
