Image preview - the first page of the document
599512547


>> Download 599512547 documenatation <<

Text preview - extract from the document
Service-Bulletin



Dishwashers                                                              599 512 547          EN

Dishwashers for installation in height


As of 2004, DGN has manufactured some dishwasher models which can be installed in height. These
dishwashers have standard equipment of discharge hose ventilation.
Dishwashers for height installation which are not yet equipped with discharge hose ventilation, can be
reequipped by customer service if any problems should arise.
The kit has PN 407133490/0 and is installed as shown on the image.




                                                             Cable fasteners




                                                                If necessary, you should reuse the angular
                                                                bush from the old discharge hose.




As all the regenerating distributors do not have connection pieces for the ventilation hose, customer service
may install the ventilation hose in other than standard ways. As the figure shows, the ventilation hose is
installed, on the one hand, up to upper edge of the machine and then into the base trough. Although the ball
valve at the beginning of the ventiation hose might not close perfectly, no water will penetrate into the base
trough, even if the machine is installed in height.




DGS-TDS-N
01.12.03
