Service-Bulletin



Dishwashers                                                             599 516 223          EN

Connecting hose, PN 899 646 130 840/6 no longer available

The connecting hose between drain pump and drain hose is no longer available in stock.




                                                   Figure 1

In case of complaints, you should install a long drain hose line, PN 111 827 003/0, as shown in Fig. 2.




                                                  Figure 2
Cut off cable clamp




                                                   Figure 3
HV 844-N
03.02.03
                                                   2                                 599 516 223   EN

Pull off connecting hose at drain pump and remove the entire drain hose from base.




                                                 Figure 4
Unclick hose clamp.




                                                   Figure 5

Insert new drain hose into base.




                                                  Figure 6
HV 844-N
03.02.03
                                                      3                             599 516 223   EN

Mount winding socket directly to drain pump.




                                                    Figure 7
Mount hose clamp and insert into base.




                                                    Figure 8

Bind up drain hose at its rear part so that it cannot touch the circulating pump.




                                                    Figure 9


HV 844-N
03.02.03
