Image preview - the first page of the document
599518332


>> Download 599518332 documenatation <<

Text preview - extract from the document
                                                                                      Service-Bulletin



Washing machines, Frontloader                                                         599 51 83-32            EN

Carrying out Repairs to Cable Harnesses

As not all of the cable harnesses are available as a spare part, it is possible to produce individual connections
yourself. The various possibilities are described below.

Carrying out repairs to wirings with Rast5 connectors (connector with 5 mm raster)

Components with Rast5 connector systems (e.g. pressure monitors) are fitted with 6.3 mm AMP connector
lugs, positioned in row with 5 mm space in between. The offered 2 and 3 pol Rast5 connector housings are not
coded so that they fit onto all connecting troughs. Multipol Rast5 connectors can be produces by combining 2
pol and 3 pol connector housings.




Rast5 plug-in connections can be produced from the following spare parts:



Rast5 receptacle                               400603852/7


Cable with Rast5 receptacles                   899646111526/4
attached to both sides, 700mm

Cable with Rast5 receptacles                   899646111525/6
attached to both sides, 1540mm

Rast5 receptacle, 2 pol                        899669807911/9


Rast5 receptacle Rast5, 3-pol                  899669807938/2


1.5mm
