Image preview - the first page of the document
hfe_aiwa_cx-jn77_service_en


>> Download hfe_aiwa_cx-jn77_service_en documenatation <<

Text preview - extract from the document
                                                                                                         CX-JN77
SERVICE MANUAL                                                                                                                           AEP Model
                                                                                                                                          UK Model
Ver 1.1 2004.08
                                                                                                                                           E Model




CX-JN77 is the amplifier, CD player, tape deck
and tuner section in JAX-N77/PK77.



                                                                                        Model Name Using Similar Mechanism               NEW
                                                                        CD              CD Mechanism Type                                CDM74-F1BD81
                                                                        Section         Base Unit Name                                   BU-F1BD81A
                                                                                        Optical Pick-up Block Name                       KSM-215DCP
                                                                        Tape deck       Model Name Using Similar Mechanism               NEW
                                                                        Section         Tape Transport Mechanism Type                    CWM43FR34


                                                                   SPECIFICATIONS
Amplifier section                                      CD player section                                        Other models             87.5
