Image preview - the first page of the document
>> Download hfe_aiwa_av-nw30_service_simple documenatation <<
Text preview - extract from the document
AV-NW30 U (B)
SERVICE MANUAL
STEREO RECEIVER
Replace this Service Manual with "Revision Publishing" when it is issued.
P LE
SIM
TA
DA
S/M Code No. 09-026-358-2T1
ACCESSORIES PARTS LIST-1/1
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
AV-NW30
UBC
ACCESSORY O AS1001 87-006-226-010 ANT,LOOP AM X a
ACCESSORY O AS1002 87-A92-346-010 ANT,WIRE FM(FASTEN) X a
ACCESSORY O AS1003 8C-AR6-701-010 RC UNIT,RC-CAR01 X a
LBL,POP X AS1004 87-B40-034-010 LBL,USA 1-800 a
LBL,POP X AS1005 8A-NF8-972-010 LBL,POP ENG a
PACKING DU X AS1006 87-B40-098-010 BAG,PV 0.025-650-750 PL a
PACKING DU X AS1007 8C-AR6-851-010 CUSHION,LEFT C a
PACKING DU X AS1008 8C-AR6-852-010 CUSHION,RIGHT C a
PACKING DU X AS1009 8C-AR6-853-010 CTN,PRINTED UBC a
PACKING DU X AS1010 8C-AR6-857-010 PAD,FRONT TOP a
PACKING DU X AS1011 92-370-716-010 SH,FOAMED-MAT 0.31-700-500 a
PRINTED DU X AS1012 87-B40-086-010 BAG,PV 0.04-230-400 PL a
PRINTED DU X AS1013 87-B50-053-010 WARR-CARD,USA CUST/AV,VISUAL a
PRINTED DU O AS1014 8C-AR6-903-110 IB,U(ESF)S AV-NW30/31 a
PRINTED DU X AS1015 8C-AR6-918-010 SH,ADDITIONAL HP(ESF) a
-2-
ELECTRICAL PARTS LIST -1/28
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
AV-NW30
UBC
AC1 X JW 0011 88-100-000-010 PLATING-JW, 0.58 SN95 a
AC1 ! O W 0002 8C-AR6-627-010 CONN ASSY,1P BLACK a
AC1 ! O W 0003 8C-AR6-628-010 CONN ASSY,1P WHITE a
AC2 ! O CNA0002 8C-AR6-626-010 CONN ASSY,9P VH a
AC2 X JW 0005 88-100-000-010 PLATING-JW, 0.58 SN95 a
AC2 X JW 0006 88-100-000-010 PLATING-JW, 0.58 SN95 a
AC2 ! S JW 0009 87-A91-970-080 FUSE,5A 125V F 20N a
AC2 ! S JW 0010 87-A91-970-080 FUSE,5A 125V F 20N a
AC2 ! O WH 0001 87-A90-510-010 HLDR,WIRE 2.5-9P a
AV SEL O C 0701 87-010-407-080 CAP,E 33-50 M 11L SME a
AV SEL O C 0702 87-010-407-080 CAP,E 33-50 M 11L SME a
AV SEL O C 0703 87-010-407-080 CAP,E 33-50 M 11L SME a
AV SEL O C 0717 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
AV SEL O C 0731 87-012-188-080 C-CAP,U 47P-50 J CH GRM a
AV SEL O C 0732 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
AV SEL O C 0733 87-012-188-080 C-CAP,U 47P-50 J CH GRM a
AV SEL O C 0735 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
AV SEL O C 0761 87-010-407-080 CAP,E 33-50 M 11L SME a
AV SEL O C 0762 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
AV SEL O C 0763 87-010-383-080 CAP,E 33-25 M 11L SME a
AV-NW30
UBC
AV SEL O C 0764 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
AV SEL O C 0781 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
AV SEL S D 0761 87-A40-754-080 ZENER,UZ6.8BSC a
AV SEL S D 0762 87-A40-754-080 ZENER,UZ6.8BSC a
AV SEL S IC 0701 87-A22-287-040 C-IC,NJM2279M a
AV SEL ! O J 0701 87-A61-865-010 JACK,PIN 6P YWR/YWR W/E a
AV SEL ! O J 0702 87-A61-865-010 JACK,PIN 6P YWR/YWR W/E a
AV SEL ! O J 0731 87-A61-862-010 JACK,PIN 3P Y/W/R W/E a
AV SEL X JW 0711 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0712 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0713 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0714 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0715 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0716 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0717 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0718 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0719 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0720 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0721 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0722 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV-NW30
UBC
AV SEL X JW 0723 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0724 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0725 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0726 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0727 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0728 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0729 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0730 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0731 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0732 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0733 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0734 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0735 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0736 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0737 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0738 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0739 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0740 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0741 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0742 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV-NW30
UBC
AV SEL X JW 0743 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0744 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0745 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0746 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0747 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0748 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0749 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X JW 0750 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL O L 0761 87-005-239-080 COIL,100UH K LAL03 a
AV SEL O L 0762 87-005-239-080 COIL,100UH K LAL03 a
AV SEL X R 0641 88-108-000-080 C-JUMPER,U a
AV SEL X R 0642 88-108-000-080 C-JUMPER,U a
AV SEL X R 0643 88-108-000-080 C-JUMPER,U a
AV SEL X R 0644 88-108-000-080 C-JUMPER,U a
AV SEL X R 0645 88-108-000-080 C-JUMPER,U a
AV SEL X R 0646 88-108-000-080 C-JUMPER,U a
AV SEL X R 0647 88-108-000-080 C-JUMPER,U a
AV SEL X R 0648 88-108-000-080 C-JUMPER,U a
AV SEL X R 0649 88-108-000-080 C-JUMPER,U a
AV SEL X R 0650 88-108-000-080 C-JUMPER,U a
-3-
ELECTRICALPARTSLIST-2/28
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
AV-NW30
UBC
AV SEL X R 0651 88-108-000-080 C-JUMPER,U a
AV SEL X R 0652 88-108-000-080 C-JUMPER,U a
AV SEL X R 0653 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X R 0654 88-108-000-080 C-JUMPER,U a
AV SEL X R 0655 88-108-000-080 C-JUMPER,U a
AV SEL X R 0656 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X R 0657 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X R 0658 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV SEL X R 0659 88-108-000-080 C-JUMPER,U a
AV SEL X R 0660 88-108-000-080 C-JUMPER,U a
AV SEL X R 0701 88-118-750-080 C-RES,S 75-1/10W J a
AV SEL X R 0702 88-118-750-080 C-RES,S 75-1/10W J a
AV SEL X R 0703 88-118-750-080 C-RES,S 75-1/10W J a
AV SEL O R 0711 88-108-101-080 C-RES,U 100-1/16W J a
AV SEL O R 0712 88-108-101-080 C-RES,U 100-1/16W J a
AV SEL O R 0713 88-108-101-080 C-RES,U 100-1/16W J a
AV SEL O R 0714 88-108-101-080 C-RES,U 100-1/16W J a
AV SEL O R 0715 88-108-101-080 C-RES,U 100-1/16W J a
AV SEL O R 0716 88-108-101-080 C-RES,U 100-1/16W J a
AV SEL O R 0721 88-108-473-080 C-RES,U 47K-1/16W J a
AV-NW30
UBC
AV SEL O R 0722 88-108-473-080 C-RES,U 47K-1/16W J a
AV SEL O R 0723 88-108-473-080 C-RES,U 47K-1/16W J a
AV SEL O R 0724 88-108-473-080 C-RES,U 47K-1/16W J a
AV SEL O R 0725 88-108-473-080 C-RES,U 47K-1/16W J a
AV SEL O R 0726 88-108-473-080 C-RES,U 47K-1/16W J a
AV SEL X R 0731 88-121-750-080 RES,75-1/8W J a
AV SEL X R 0732 88-121-750-080 RES,75-1/8W J a
AV SEL X R 0761 88-128-181-080 C-RES, 180-1/8W J a
AV SEL X R 0762 88-128-181-080 C-RES, 180-1/8W J a
AV SEL X R 0763 88-128-181-080 C-RES, 180-1/8W J a
AV SEL O R 0764 88-108-102-080 C-RES,U 1K-1/16W J a
AV SEL O R 0766 88-108-102-080 C-RES,U 1K-1/16W J a
AV SEL O R 0771 88-108-102-080 C-RES,U 1K-1/16W J a
AV SEL O R 0772 88-108-102-080 C-RES,U 1K-1/16W J a
AV SEL O R 0773 88-108-102-080 C-RES,U 1K-1/16W J a
AV SEL O R 0774 88-108-102-080 C-RES,U 1K-1/16W J a
AV SEL X R 0775 88-121-472-080 RES,4.7K-1/8W J a
AV SEL X R 0776 88-108-182-080 C-RES,U 1.8K-1/16W J a
AV SEL O R 0781 88-108-473-080 C-RES,U 47K-1/16W J a
AV SEL O R 0782 88-108-473-080 C-RES,U 47K-1/16W J a
AV-NW30
UBC
AV SEL O R 0783 88-108-473-080 C-RES,U 47K-1/16W J a
AV SEL O R 0784 88-108-473-080 C-RES,U 47K-1/16W J a
AV SEL X R 0791 88-128-820-080 C-RES, 82-1/8W J a
AV SEL X R 0792 88-128-820-080 C-RES, 82-1/8W J a
AV SEL X R 0793 88-129-000-080 C-JUMPER, 3216 a
CODEC X * 8C-AR6-645-010 PWB,DSP 4M CAR-6 a
CODEC O C 0001 87-010-101-080 CAP,E 220-16 M SME a
CODEC O C 0002 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
CODEC O C 0003 87-010-401-010 CAP,E 1-50 M SME a
CODEC O C 0004 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
CODEC O C 0005 87-010-401-010 CAP,E 1-50 M SME a
CODEC O C 0006 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
CODEC O C 0013 87-010-248-080 CAP,E 220-10 M 11L SME a
CODEC O C 0014 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
CODEC O C 0401 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
CODEC O C 0402 87-010-405-080 CAP,E 10-50 M 11L SME a
CODEC O C 0403 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
CODEC O C 0404 87-010-405-080 CAP,E 10-50 M 11L SME a
CODEC O C 0405 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
CODEC O C 0406 87-010-405-080 CAP,E 10-50 M 11L SME a
AV-NW30
UBC
CODEC O C 0407 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
CODEC O C 0408 87-010-402-080 CAP,E 2.2-50 M 11L SME a
CODEC O C 0409 87-010-405-080 CAP,E 10-50 M 11L SME a
CODEC O C 0410 87-010-405-080 CAP,E 10-50 M 11L SME a
CODEC O C 0411 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
CODEC O C 0412 87-010-405-080 CAP,E 10-50 M 11L SME a
CODEC O C 0413 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
CODEC ! O CN 0101 87-099-014-010 CONN,12P V BLK 6216 a
CODEC ! O CN 0102 87-A61-013-010 CONN,15P H BLK TAC-L15P-A3 a
CODEC O FB 0011 87-008-372-080 FLTR,EMI BL01 RN1 a
CODEC X FB 0401 88-108-000-080 C-JUMPER,U a
CODEC O FB 0402 87-005-512-080 C-COIL,2125 80H BLM21 a
CODEC O FB 0403 87-005-512-080 C-COIL,2125 80H BLM21 a
CODEC O FB 0405 87-005-512-080 C-COIL,2125 80H BLM21 a
CODEC O FB 0406 87-005-512-080 C-COIL,2125 80H BLM21 a
CODEC X FB 0408 88-108-000-080 C-JUMPER,U a
CODEC S IC 0001 87-A21-363-010 IC,NJM7805FA(A) a
CODEC S IC 0011 87-A20-736-010 IC,BA033ST a
CODEC S IC 0401 87-A22-266-030 C-IC,AK4586 a
CODEC X JR 0401 88-108-000-080 C-JUMPER,U a
-4-
ELECTRICALPARTSLIST-3/28
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
AV-NW30
UBC
CODEC O JR 0402 87-005-512-080 C-COIL,2125 80H BLM21 a
CODEC X R 0011 88-130-479-080 RES,4.7-1/4W J a
CODEC X R 0141 88-108-000-080 C-JUMPER,U a
CODEC X R 0142 88-108-000-080 C-JUMPER,U a
CODEC X R 0143 88-108-000-080 C-JUMPER,U a
CODEC X R 0144 88-108-000-080 C-JUMPER,U a
CODEC X R 0145 88-108-000-080 C-JUMPER,U a
CODEC X R 0146 88-108-000-080 C-JUMPER,U a
CODEC X R 0147 88-108-000-080 C-JUMPER,U a
CODEC X R 0148 88-108-000-080 C-JUMPER,U a
CODEC X R 0149 88-108-000-080 C-JUMPER,U a
CODEC X R 0150 88-108-331-080 C-RES,U 330-1/16W J a
CODEC O R 0401 88-108-101-080 C-RES,U 100-1/16W J a
CODEC O R 0402 88-108-101-080 C-RES,U 100-1/16W J a
CODEC O R 0403 88-108-101-080 C-RES,U 100-1/16W J a
CODEC O R 0404 88-108-101-080 C-RES,U 100-1/16W J a
CODEC O R 0405 88-108-101-080 C-RES,U 100-1/16W J a
CODEC O R 0406 88-108-101-080 C-RES,U 100-1/16W J a
CODEC O R 0407 88-108-102-080 C-RES,U 1K-1/16W J a
CODEC O R 0408 88-108-102-080 C-RES,U 1K-1/16W J a
AV-NW30
UBC
CODEC O R 0409 88-108-102-080 C-RES,U 1K-1/16W J a
CODEC O R 0410 88-108-102-080 C-RES,U 1K-1/16W J a
CODEC X R 0411 88-108-183-080 C-RES,U 18K-1/16W J a
CODEC X R 0412 88-108-104-080 C-RES,U 100K-1/16W J a
CODEC X R 0413 88-108-104-080 C-RES,U 100K-1/16W J a
CODEC X R 0415 88-108-331-080 C-RES,U 330-1/16W J a
CODEC X R 0416 88-108-331-080 C-RES,U 330-1/16W J a
CODEC X R 0417 88-108-331-080 C-RES,U 330-1/16W J a
CODEC X R 0418 88-108-331-080 C-RES,U 330-1/16W J a
CODEC X R 0419 88-108-331-080 C-RES,U 330-1/16W J a
CODEC X R 0420 88-108-331-080 C-RES,U 330-1/16W J a
DIGITAL IN O C 0451 87-012-180-080 C-CAP,U 22P-50 J CH GRM a
DIGITAL IN O C 0452 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
DIGITAL IN O C 0461 87-012-278-080 C-CAP,U 2200P-50 K B GRM a
DIGITAL IN O C 0471 87-012-278-080 C-CAP,U 2200P-50 K B GRM a
DIGITAL IN S IC 0461 87-A21-974-010 IC,GP1FA551RZ a
DIGITAL IN S IC 0471 87-A21-974-010 IC,GP1FA551RZ a
DIGITAL IN ! O J 0451 87-A61-861-010 JACK,PIN 1P ORN W/E a
DIGITAL IN X JR 0501 88-108-000-080 C-JUMPER,U a
DIGITAL IN X R 0451 88-118-820-080 C-RES,S 82-1/10W J a
AV-NW30
UBC
DIGITAL IN X R 0460 88-128-100-010 C-RES, 10-1/8W J a
DIGITAL IN X R 0461 88-118-471-080 C-RES,S 470-1/10W J a
DIGITAL IN X R 0471 88-118-471-080 C-RES,S 470-1/10W J a
DIGITAL IN X R 0563 88-108-104-080 C-RES,U 100K-1/16W J a
DSP O C 0501 87-010-405-080 CAP,E 10-50 M 11L SME a
DSP O C 0502 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
DSP O C 0503 87-012-170-080 C-CAP,U 8P-50 D CH GRM a
DSP O C 0504 87-012-176-080 C-CAP,U 15P-50 J CH GRM a
DSP O C 0505 87-010-263-080 CAP,E 100-10 M 11L SME a
DSP O C 0506 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
DSP O C 0507 87-A10-039-080 C-CAP,U 470P-50 J CH a
DSP O C 0508 87-010-374-080 CAP,E 47-10 M 11L SME a
DSP O C 0509 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
DSP O C 0510 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
DSP O C 0511 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
DSP O C 0512 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
DSP O C 0513 87-010-404-080 CAP,E 4.7-50 M 11L SME a
DSP O C 0514 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
DSP O C 0515 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
DSP O C 0516 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
AV-NW30
UBC
DSP O C 0517 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
DSP O C 0518 87-012-195-080 C-CAP,U 100P-50 J CH GRM a
DSP O C 0519 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
DSP O C 0520 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
DSP O C 0521 87-010-401-080 CAP,E 1-50 M 11L SME a
DSP O C 0522 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
DSP O C 0523 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
DSP S D 0501 87-020-465-080 DIODE,1SS133 a
DSP S D 0502 87-A40-740-080 ZENER,UZ3.3BSA a
DSP S D 0503 87-020-465-080 DIODE,1SS133 a
DSP O FB 0501 87-005-512-080 C-COIL,2125 80H BLM21 a
DSP O FB 0502 87-005-512-080 C-COIL,2125 80H BLM21 a
DSP O FB 0503 87-005-512-080 C-COIL,2125 80H BLM21 a
DSP O FB 0504 87-005-512-080 C-COIL,2125 80H BLM21 a
DSP O FB 0505 87-005-512-080 C-COIL,2125 80H BLM21 a
DSP O FB 0506 87-005-512-080 C-COIL,2125 80H BLM21 a
DSP O FB 0507 87-005-512-080 C-COIL,2125 80H BLM21 a
DSP O FB 0508 87-005-512-080 C-COIL,2125 80H BLM21 a
DSP S IC 0501 87-A21-500-010 C-IC,YSS912 a
DSP X JR 0502 88-108-000-080 C-JUMPER,U a
-5-
ELECTRICALPARTSLIST-4/28
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
AV-NW30
UBC
DSP X JR 0503 88-108-000-080 C-JUMPER,U a
DSP S Q 0501 87-A30-076-080 C-TR,2SC3052F a
DSP S Q 0502 87-A30-429-040 C-TR,DTC123JKA a
DSP X R 0501 88-108-391-080 C-RES,U 390-1/16W J a
DSP X R 0502 88-108-105-080 C-RES,U 1M-1/16W J a
DSP X R 0503 88-108-271-080 C-RES,U 270-1/16W J a
DSP O R 0504 88-108-103-080 C-RES,U 10K-1/16W J a
DSP O R 0505 88-108-101-080 C-RES,U 100-1/16W J a
DSP O R 0506 88-108-101-080 C-RES,U 100-1/16W J a
DSP O R 0507 88-108-101-080 C-RES,U 100-1/16W J a
DSP X R 0508 88-108-104-080 C-RES,U 100K-1/16W J a
DSP O R 0509 88-108-101-080 C-RES,U 100-1/16W J a
DSP O R 0510 88-108-101-080 C-RES,U 100-1/16W J a
DSP O R 0511 88-108-101-080 C-RES,U 100-1/16W J a
DSP O R 0512 88-108-101-080 C-RES,U 100-1/16W J a
DSP O R 0513 88-108-101-080 C-RES,U 100-1/16W J a
DSP X R 0514 88-108-100-080 C-RES,U 10-1/16W J a
DSP X R 0515 88-108-472-080 C-RES,U 4.7K-1/16W J a
DSP O R 0516 88-108-102-080 C-RES,U 1K-1/16W J a
DSP O R 0517 88-108-101-080 C-RES,U 100-1/16W J a
AV-NW30
UBC
DSP O R 0518 88-108-101-080 C-RES,U 100-1/16W J a
DSP O R 0519 88-108-101-080 C-RES,U 100-1/16W J a
DSP O X 0501 87-A70-115-010 VIB,XTAL 12.288MHZ a
FUNCTION O C 0631 87-010-404-080 CAP,E 4.7-50 M 11L SME a
FUNCTION O C 0632 87-010-404-080 CAP,E 4.7-50 M 11L SME a
FUNCTION O C 0633 87-010-404-080 CAP,E 4.7-50 M 11L SME a
FUNCTION O C 0634 87-010-404-080 CAP,E 4.7-50 M 11L SME a
FUNCTION O C 0635 87-010-404-080 CAP,E 4.7-50 M 11L SME a
FUNCTION O C 0636 87-010-404-080 CAP,E 4.7-50 M 11L SME a
FUNCTION O C 0641 87-010-405-080 CAP,E 10-50 M 11L SME a
FUNCTION O C 0642 87-010-405-080 CAP,E 10-50 M 11L SME a
FUNCTION O C 0643 87-010-405-080 CAP,E 10-50 M 11L SME a
FUNCTION O C 0644 87-010-405-080 CAP,E 10-50 M 11L SME a
FUNCTION O C 0645 87-010-405-080 CAP,E 10-50 M 11L SME a
FUNCTION O C 0646 87-010-405-080 CAP,E 10-50 M 11L SME a
FUNCTION O C 0651 87-A11-014-080 CAP,M 0.22-50 J DE a
FUNCTION O C 0652 87-A11-014-080 CAP,M 0.22-50 J DE a
FUNCTION O C 0653 87-A11-014-080 CAP,M 0.22-50 J DE a
FUNCTION O C 0654 87-A11-014-080 CAP,M 0.22-50 J DE a
FUNCTION O C 0655 87-A10-307-080 CAP,M 0.1-50 J a
AV-NW30
UBC
FUNCTION O C 0656 87-A10-307-080 CAP,M 0.1-50 J a
FUNCTION O C 0657 87-A10-307-080 CAP,M 0.1-50 J a
FUNCTION O C 0658 87-A10-307-080 CAP,M 0.1-50 J a
FUNCTION O C 0659 87-A10-291-080 CAP,M 4700P-50 J a
FUNCTION O C 0660 87-A10-291-080 CAP,M 4700P-50 J a
FUNCTION O C 0661 87-010-404-080 CAP,E 4.7-50 M 11L SME a
FUNCTION O C 0662 87-010-404-080 CAP,E 4.7-50 M 11L SME a
FUNCTION O C 0663 87-010-404-080 CAP,E 4.7-50 M 11L SME a
FUNCTION O C 0665 87-010-404-080 CAP,E 4.7-50 M 11L SME a
FUNCTION O C 0666 87-010-404-080 CAP,E 4.7-50 M 11L SME a
FUNCTION O C 0681 87-010-263-080 CAP,E 100-10 M 11L SME a
FUNCTION O C 0682 87-010-383-080 CAP,E 33-25 M 11L SME a
FUNCTION O C 0683 87-012-274-080 C-CAP,U 1000P-50 K B GRM a
FUNCTION O C 0692 87-A12-317-080 C-CAP,U 0.1-50 Z F a
FUNCTION O C 0693 87-A12-317-080 C-CAP,U 0.1-50 Z F a
FUNCTION ! O CN 0602 87-A60-625-010 CONN,8P V 2MM JMT a
FUNCTION ! O CN 0604 87-A60-998-010 CONN,15P V BLK TAC-L15X-A3 a
FUNCTION ! O CN 0605 87-099-015-010 CONN,13P V BLK 6216 a
FUNCTION ! O CN 0608 87-099-018-010 CONN,16P V BLK 6216 a
FUNCTION ! O CN 0691 87-099-014-010 CONN,12P V BLK 6216 a
AV-NW30
UBC
FUNCTION ! O CN 0692 87-099-014-010 CONN,12P V BLK 6216 a
FUNCTION S D 0681 87-A40-754-080 ZENER,UZ6.8BSC a
FUNCTION S IC 0501 87-A22-267-030 C-IC,BD3811K1 a
FUNCTION X JR 0603 88-108-000-080 C-JUMPER,U a
FUNCTION X JR 0606 88-108-000-080 C-JUMPER,U a
FUNCTION X JR 0608 88-108-000-080 C-JUMPER,U a
FUNCTION X JR 0611 88-108-000-080 C-JUMPER,U a
FUNCTION X JR 0612 88-129-000-080 C-JUMPER, 3216 a
FUNCTION X JR 0615 88-118-000-080 C-JUMPER,S a
FUNCTION X JR 0616 88-118-000-080 C-JUMPER,S a
FUNCTION X JW 0603 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0605 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0611 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0612 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0613 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0614 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0615 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0616 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0617 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0618 88-100-000-010 PLATING-JW, 0.58 SN95 a
-6-
ELECTRICALPARTSLIST-5/28
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
AV-NW30
UBC
FUNCTION X JW 0619 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0620 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0621 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0622 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0623 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0624 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0625 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0627 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0628 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0629 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0630 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0631 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0632 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0633 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0634 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0635 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0636 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0637 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0638 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0639 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV-NW30
UBC
FUNCTION X JW 0640 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0641 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0642 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0643 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0644 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0647 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0648 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0649 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0650 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0651 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0652 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0653 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0655 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0656 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0657 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0658 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0659 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0660 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0661 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0662 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV-NW30
UBC
FUNCTION X JW 0664 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0665 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0666 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0667 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0668 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0669 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0670 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0671 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0672 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0674 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0675 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0676 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0677 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0678 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0679 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0680 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0681 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0682 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0683 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION X JW 0698 88-100-000-010 PLATING-JW, 0.58 SN95 a
AV-NW30
UBC
FUNCTION S Q 0681 87-A30-075-080 C-TR,2SA1235F a
FUNCTION S Q 0682 87-A30-612-080 TR,2SC5343Y a
FUNCTION S Q 0683 87-A30-075-080 C-TR,2SA1235F a
FUNCTION S Q 0684 87-A30-075-080 C-TR,2SA1235F a
FUNCTION O R 0601 88-108-101-080 C-RES,U 100-1/16W J a
FUNCTION O R 0602 88-108-101-080 C-RES,U 100-1/16W J a
FUNCTION O R 0603 88-108-101-080 C-RES,U 100-1/16W J a
FUNCTION O R 0604 88-108-101-080 C-RES,U 100-1/16W J a
FUNCTION O R 0605 88-108-101-080 C-RES,U 100-1/16W J a
FUNCTION O R 0606 88-108-101-080 C-RES,U 100-1/16W J a
FUNCTION X R 0607 88-108-472-080 C-RES,U 4.7K-1/16W J a
FUNCTION X R 0608 88-108-472-080 C-RES,U 4.7K-1/16W J a
FUNCTION X R 0609 88-108-472-080 C-RES,U 4.7K-1/16W J a
FUNCTION X R 0610 88-108-472-080 C-RES,U 4.7K-1/16W J a
FUNCTION O R 0611 88-108-473-080 C-RES,U 47K-1/16W J a
FUNCTION O R 0612 88-108-473-080 C-RES,U 47K-1/16W J a
FUNCTION O R 0613 88-108-473-080 C-RES,U 47K-1/16W J a
FUNCTION O R 0614 88-108-473-080 C-RES,U 47K-1/16W J a
FUNCTION O R 0615 88-108-473-080 C-RES,U 47K-1/16W J a
FUNCTION O R 0616 88-108-473-080 C-RES,U 47K-1/16W J a
-7-
ELECTRICALPARTSLIST-6/28
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
AV-NW30
UBC
FUNCTION O R 0617 88-108-103-080 C-RES,U 10K-1/16W J a
FUNCTION O R 0618 88-108-103-080 C-RES,U 10K-1/16W J a
FUNCTION X R 0681 88-128-120-080 C-RES, 12-1/8W J a
FUNCTION X R 0682 88-128-120-080 C-RES, 12-1/8W J a
FUNCTION X R 0683 88-128-120-080 C-RES, 12-1/8W J a
FUNCTION X R 0684 88-128-150-080 C-RES, 15-1/8W J a
FUNCTION X R 0685 88-100-000-010 PLATING-JW, 0.58 SN95 a
FUNCTION O R 0686 88-108-103-080 C-RES,U 10K-1/16W J a
FUNCTION O R 0687 88-108-223-080 C-RES,U 22K-1/16W J a
FUNCTION O R 0688 88-108-103-080 C-RES,U 10K-1/16W J a
FUNCTION X R 0691 88-128-120-080 C-RES, 12-1/8W J a
FUNCTION O R 0692 87-A00-147-050 RES,M/F 68-1W J RSF(S) a
FUNCTION O R 0693 87-A00-147-050 RES,M/F 68-1W J RSF(S) a
FUNCTION X R 0694 88-129-000-080 C-JUMPER, 3216 a
FUNCTION X R 0695 88-128-120-080 C-RES, 12-1/8W J a
FUNCTION X R 0696 88-128-120-080 C-RES, 12-1/8W J a
FUNCTION X R 0697 88-128-120-080 C-RES, 12-1/8W J a
FUNCTION O R 0698 88-108-103-080 C-RES,U 10K-1/16W J a
HP/VIDEO O C 0551 87-012-278-080 C-CAP,U 2200P-50 K B GRM a
HP/VIDEO O C 0552 87-012-278-080 C-CAP,U 2200P-50 K B GRM a
AV-NW30
UBC
HP/VIDEO O C 0553 87-A12-317-080 C-CAP,U 0.1-50 Z F a
HP/VIDEO ! O CN 0551 87-099-209-010 CONN,4P H BLK 6216 a
HP/VIDEO O FB 0551 87-008-372-080 FLTR,EMI BL01 RN1 a
HP/VIDEO ! O J 0551 87-A60-483-010 JACK,DIA6.3 BLK ST W/S KM a
KEY ! O CN 0501 87-099-202-010 CONN,9P H BLK 6216 a
KEY ! O CN 0502 87-099-209-010 CONN,4P H BLK 6216 a
KEY O D 0525 87-A41-142-010 LED,SPR-39MVWF GRN/RED (L/M/N) a
KEY X JW 0521 88-100-000-010 PLATING-JW, 0.58 SN95 a
KEY S Q 0525 87-A30-677-040 C-TR,SRA2207S a
KEY S Q 0526 87-A30-071-080 C-TR,RT1N 144C a
KEY X R 0521 88-108-182-080 C-RES,U 1.8K-1/16W J a
KEY X R 0522 88-108-000-080 C-JUMPER,U a
KEY O R 0523 88-108-102-080 C-RES,U 1K-1/16W J a
KEY X R 0525 88-121-182-080 RES,1.8K-1/8W J a
KEY X R 0526 88-121-681-080 RES,680-1/8W J a
KEY O S 0521 87-A90-164-080 SW,TACT SKQNAB(N) a
KEY O S 0522 87-A90-164-080 SW,TACT SKQNAB(N) a
LPF/BUFFER O C 0101 87-010-405-080 CAP,E 10-50 M 11L SME a
LPF/BUFFER O C 0102 87-010-405-080 CAP,E 10-50 M 11L SME a
LPF/BUFFER O C 0111 87-012-270-080 C-CAP,U 470P-50 K B GRM a
AV-NW30
UBC
LPF/BUFFER O C 0112 87-012-270-080 C-CAP,U 470P-50 K B GRM a
LPF/BUFFER O C 0113 87-012-188-080 C-CAP,U 47P-50 J CH GRM a
LPF/BUFFER O C 0114 87-012-188-080 C-CAP,U 47P-50 J CH GRM a
LPF/BUFFER O C 0115 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
LPF/BUFFER O C 0116 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
LPF/BUFFER O C 0117 87-010-405-080 CAP,E 10-50 M 11L SME a
LPF/BUFFER O C 0118 87-010-405-080 CAP,E 10-50 M 11L SME a
LPF/BUFFER O C 0121 87-012-199-080 C-CAP,U 220P-50 J CH GRM a
LPF/BUFFER O C 0122 87-012-199-080 C-CAP,U 220P-50 J CH GRM a
LPF/BUFFER O C 0123 87-A10-369-080 C-CAP,S 0.47-16 K B a
LPF/BUFFER O C 0124 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
LPF/BUFFER O C 0125 87-010-759-080 C-CAP,U 0.1-25 Z F CM/CB a
LPF/BUFFER O C 0127 87-010-405-080 CAP,E 10-50 M 11L SME a
LPF/BUFFER O C 0128 87-010-405-080 CAP,E 10-50 M 11L SME a
LPF/BUFFER O C 0201 87-010-405-080 CAP,E 10-50 M 11L SME a
LPF/BUFFER O C 0202 87-010-405-080 CAP,E 10-50 M 11L SME a
LPF/BUFFER O C 0211 87-012-270-080 C-CAP,U 470P-50 K B GRM a
LPF/BUFFER O C 0212 87-012-270-080 C-CAP,U 470P-50 K B GRM a
LPF/BUFFER O C 0213 87-012-188-080 C-CAP,U 47P-50 J CH GRM a
LPF/BUFFER O C 0214 87-012-188-080 C-CAP,U 47P-50 J CH GRM a
AV-NW30
UBC
LPF/BUFFER O C 0215 87-010-759-080 C-CAP,U ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
