Image preview - the first page of the document
AIWA ACCESORIOS PX-E860K


>> Download AIWA ACCESORIOS PX-E860K documenatation <<

Text preview - extract from the document
                                         PX-E860                        K(ST)




SERVICE MANUAL
STEREO TURNTABLE SYSTEM


                              SPECIFICATIONS




This Service Manual is the "Revision Publishing" and replaces "Simple Manual"
PX-E860(S/M Code No.09-993-322-0T1).
                                                                                 N
                                                                                SIO
                                                                          VI
                                                                      RE
                                                                                  TA
                                                                                DA




                       S/M Code No. 09-993-322-0R4
2
ELECTRICAL MAIN PARTS LIST


 REF. NO       PART NO.    KANRI           DESCRIPTION
                            NO.
IC

             87-027-683-010    IC,TA7325


DIODE

             87-001-783-080    DIODE,1N4002


PRE AMP C.B

             S8-E27-BK0-190    SIGNAL WIRE
  C102       87-015-995-810    CAP,E 4.7-50V
  C104       87-010-412-010    CAP,E 10-25V
  C107       87-015-995-810    CAP,E 4.7-50V
  C202       87-015-995-810    CAP,E 4.7-50V

  C204       87-010-412-010    CAP,E   10-25V
  C207       87-015-995-810    CAP,E   4.7-50V
  C301       87-010-564-010    CAP,E   100-16V
  C302       87-010-564-010    CAP,E   100-16V
  SW101      S3-PXE-900-280    SLIDE   SWITCH


POWER C.B

  C1         87-010-237-010    CAP,E 1000UF/16V M




ACCESSORIES LIST


 REF. NO       PART NO.    KANRI         DESCRIPTION
                            NO.
         1   S0-0H2-000-160     ADAPTOR 45RPM
         2   S8-60E-1C7-500     INSTRUCTION BOOK(PXE860EZ)
         2   SE-860-KC7-530     INSTRUCTION BOOK(PXE860K)
         2   SE-860-UC7-520     INSTRUCTION BOOK(PXE860U)
         3   SX-E85-5E6-050     INSTRUCTION BOOK




                                                                 3
WIRING
         1   2   3       4   5   6   7



A




B




C




D




E




F




G




H




I




J




                     4
SCHEMATIC DIAGRAM




                    5
MECHANICAL EXPLODED VIEW 1/1

                                                                                                                                                                     1




                                                            20
                                                            21
                                                            2
                                                            16
                                                            22
                                                            23
                                                            24                                         25                                          3
                                                            27                                     C
                                                                                     L                                      2             8                                      4
                                                            16
                                                                                                       26                         SHIELD WIRE
                                                            22                                                                    (WHITE)
                                                                                                         WIRE(BLK)                                                                5
                                                            28                                                                                                       P
                                                                                                       GROUND
                                                            29                                         SHEET
                                                                                                                9                                                            6
                                                            30
                                                                                                          F                                   SHIELD WIRE
                                                                          14                                    13                        Q (RED)
                                                                          31                                    14
                                                                                                                                           10           7
                                                   34
                                                                                                                     10-1
                                                                          32                                         10-2
                                                   35
                                                                                K             16                                                       11
                                                            C        33                                                                                                              U only
                                                                                                                            15
                                                                 H                            17                                                                                      12
                                                   36                C K                                             C
                                                   37                                                       18
                                38
                                                                     33                                                                                                  K only
                                39                                                                          19
                                                                                                                                                                           12

      STEEL CLAMPER                                                                                                                                                                  EZ only
      (K only)                                                                                                                                                                        12
                               40


     75

     65
                               77
     67
     76                                        G                                                            56                   NUT
     69                                                                                                                     B                 51
                                                                                                            57
                                                                                65                     F
                     E                                                                                      58                                52
                                                                                                                 M          N     54          53                                 91
                                                                 90        66                 60
                          78                                                                                                              G
                                                        68                                         62
                                      81                         69 E                                                            O                          D
                                                        72                                61                                                       D
                79                                                  70                             C                59 J                                                         41
                                                                                                                C                     I                                          42
                     80                                          73 71                                      A
                                      82                                                                                         55                                              43
                                                                                               64 63                                          45
                                                                                                                    M                                                            44
                                     83                                                  F                  R                                 46
                                     84                                                                     M                     47
                                                                          74                                                                                    M
                                                   F                                                                              48                             K
                                                                 E                                                                49               I
                     86                                                                                                           50
                     85
                                                                                                                                                            BOTTOM PLATE
            C
                      INSULATION
                      SHEET
                      87         88                                                                                                                    89

                                          89                                                                                              E
                                                                      F
           F                                                                                                            F
                                                        E
                                                                                F                                                                           89
                                                                                     88
                                                                                                                            E
                                                                                         89
                                                                                                   E




                                                                                     6
MECHANICAL MAIN PARTS LIST 1/1


REF. NO      PART NO.     KANRI        DESCRIPTION              REF. NO      PART NO.   KANRI         DESCRIPTION
                           NO.                                                           NO.
      1   S0-3B6-000-260      HINGE ASS'Y                            67   S0-0B6-001-390     KNOB SHAFT
      2   S4-B60-002-6A0      FOOT FOR DUST COVER(PXE850)            68   SP-EX8-509-000     CUE,KNOB(PXE860)
      3   S0-SL2-4F1-180      PIN (FOR TONEARM SET)                  69   S0-0F7-002-590     KNOB SET
      4   S0-SL2-4F2-310      TONE ARM SET                           70   S0-0L1-001-330     PULLEY
      5   S3-SL2-4F0-830      SPRING
                                                                     71   S0-1H7-030-380      MOTOR MMI-6T2RWK
      6   S3-SL2-4F0-560      ROTARY SHAFT ASSY                      72   S0-SL2-4F2-400      PENDULUM(S)
      7   S0-SL2-4F1-070      TONE ARM SHAFT SET                     73   S3-SL2-4F0-660      SPRING
      8   S0-SL2-4F1-320      TONE ARM TUBE                          74   S0-0B6-001-440      PRESS SET
      9   S0-SL3-4F2-320      HEADSHELL                              75   SP-XE8-508-500      DECORATIVE PLATE
     10   S2-E27-BK0-480      CARTRIDGE(W/STYLUS)
                                                                     76   S8-60L-HA8-970      SPEED KNOB(PXE860)
     10-1S1-E27-BK0-230       STYLUS                                 77   S3-SL2-4F0-110      MICRO SWITCH
     10-2S0-0B6-011-800       STYLUS COVER                           78   S3-SL2-4F0-760      SPRING
     11 S8-E27-BK0-190        SIGNAL WIRE                            79   SP-XE8-508-980      START KNOB(PXE860)
!    12 S0-930-040-160        AC CORD(E)                         80   SP-XE8-508-990      CUT KNOB(PXE860)
!    12 SH-MD5-00B-037        AC CORD(K)
                                                                     81   SP-XE8-501-820      SPR
!    12   SC-132-0FA-034      AC CORD(U)                          82   SP-XE8-501-830      SPR
     13   S3-SL2-4F0-670      SPRING                                 83   S0-SL2-4F2-340      PENDULUM(L)
     14   S0-SL2-4F1-17A      COPPER WASHER                          84   S3-SL2-4F0-680      SPRING
     15   S0-SL2-4F2-470      SELECT PLATE                           85   S0-SL2-4F2-430      STATING SUPPORT
     16   S0-6F2-000-130      CS WASHER (3M/M)
                                                                !    86   S1-PXE-850-068      POWER TRANS(EZ)
     17   S3-SL2-4F0-690      SPRING                            !    86   SP-XE8-50K-070      POWER TRANS(K)
     18   S0-SL2-4F2-380      LIFTER                            !    86   SP-XE8-50U-067      POWER TRANS(U)
     19   S0-3MD-260-590      SPRING                            !    87      --------------   POWER P.C.B Assy
     20   S4-PXE-900-720      PLATTER MAT                            88   S0-PXE-903-320      FOOT RING
     21   SP-XE8-508-950      DUST COVER
                                                                     89   S4-SL2-4F0-360      RUBBER FOOT
     22   S6-SL2-4F0-570      WASHER METAL 3-10-0.5                  90   S8-60K-C18-060      CUE KNOB SHAFT BASE(PXE860)
     23   S0-SL2-4F1-300      FRICTION LINK                          91      --------------   DUAL PREAMP P.C.B
     24   S0-SL2-4F1-310      ACTUATING LINK                          A   87-741-072-410      SCREW,UT2+2.6-5
     25   S0-6B3-000-290      E-RING WASHER 1.5MM                     B   S6-SL2-4F0-550      WASHER
     26   S3-SL2-4F0-770      SPRING
                                                                      C   87-761-095-410      SCREW   VFT2+3-8
     27   S0-0F7-002-280      PLATTER TARNTABULE                      D   87-751-095-410      SCREW   VT2+3-8
     28   S0-SL2-4F2-480      CAM GEAR                                E   87-761-097-410      SCREW   VFT2+3-12
     29   S4-PXE-900-760      BELT                                    F   87-751-096-410      SCREW   VT2+3-10
     30   S3-SL2-4F0-500      CAM GEAR CONTROL ASSY                   G   87-751-074-410      SCREW   VT2+2.6-8
     31   S3-SL2-4F0-490      RETURN LINK ASS'Y
                                                                      H   S2-SL2-4F0-930      SCREW
     32   S0-0H2-000-160      ADAPTOR 45RPM                           I   87-761-096-410      SCREW VFT2+3-10
     33   S4-SL2-4F0-380      RUBBER FOOT FOR MOTOR                   J   87-481-097-410      SCREW VWS+3-12
     34   S0-SL2-4F2-440      SMALL GEAR                              K   87-481-103-410      SCREW VWS+3-24
     35   S2-PXE-900-090      PLATER SHAFT ASS'Y                      L   S0-6F2-000-060      WASHER
     36   S3-SL2-4F0-510      PLATE SHAFT SET ASY
                                                                      M   S0-6F2-000-110      E-RING WASHER (3M/M)
     37   S0-7B6-000-020      STEEL BALL                              N   S0-6F2-000-120      E-RING WASHER (5M/M)
     38   S0-SL2-4F2-360      SELECT RECORD KNOB                      O   S6-SL2-4F0-580      WASHER
     39   SP-EX8-508-500      DECORATIVE PLATE                        P   87-261-097-410      SCREW V+3-12
     40   S8-55L-HA8-940      BASE                                    Q   87-261-074-410      SCREW,V+2.6-8
     41   S4-SL2-4F0-390      RUBBER CAP
                                                                      R S6-DP3-6F0-640        WASHER\
     42   S0-SL2-4F1-140      SHAFT
     43   S6-SL2-4F0-560      WASHER METAL 5-8-0.5
     44   S3-SL2-4F0-780      SPRING
     45   S0-SL2-4F2-410      LIFTER SET
     46   S3-SL2-4F0-720      SPRING

     47   S0-SL2-4F1-120      SHAFT
     48   S3-SL2-4F0-520      CUEING LEVER ASSY
     49   S0-6B3-000-390      SPRING WASHER METAL 3-5-1
     50   S1-A10-000-400      NUT
     51   S0-SL2-4F2-390      FIEXING SWITCH SET

     52   S3-SL2-4F0-160      SW,MICRO
     53      --------------   CONDENSOR
     54   S0-6D2-000-510      SPRING WASHER METAL 3-6-1
     55   S0-SL2-4F1-130      SHAFT
     56   S0-SL2-4F1-160      SHAFT

     57   S3-SL2-4F0-790      SPRING
     58   S0-6H2-000-190      WASHER METAL 3-5-1
     59   S0-SL2-4F2-420      STATING LEVER
     60   S0-SL2-4F2-350      PENDULUM(M)
     61   S0-3L1-001-030      SPRING

     62   S0-0F7-002-720      OIL SHAFT SET
     63   S0-SL2-4F1-260      CONTROL PLATE
     64   SP-XE8-501-840      SPR,FOR CUE
     65   S0-3B6-000-400      SPRING
     66   S0-SL2-4F2-450      SELECTOR



                                                            7
                                       COLOR NAME TABLE
    Basic color symbol   Color      Basic color symbol      Color       Basic color symbol         Color
            B            Black              C               Cream               D                 Orange
            G            Green              H                Gray               L                  Blue
            N            Gold               P                Pink               R                  Red
            S            Silver             ST           Titan Silver           T                 Brown
            V            Violet             W               White               Y                 Yellow
