Image preview - the first page of the document
>> Download aiwa_tpvs480 documenatation <<
Text preview - extract from the document
TP-VS480 YB YUBB YLB
TP-VS610 YS YUBS
TP-VS610 TP-VS480
SERVICE MANUAL
CASSETTE RECORDER BASIC TAPE MECHANISM : TN-9XR-107
This Service Manual is the "Revision Publishing" and replaces "Simple Manual"
(S/M Code No. 09-991-315-20A).
N
SIO
VI
RE
TA
DA
S/M Code No. 09-992-315-2R1
SPECIFICATIONS
[TP-VS610] [TP-VS480]
Track system 2 tracks 1 channel, monaulal Track system 2 tracks 1 channel, monaulal
Frequency response 250 - 8,000 Hz (4.8 cm/sec) EIAJ Frequency response 250 - 8,000 Hz EIAJ
Microphone Electret condenser microphone (monaural) Microphone Electret condenser microphone (monaural)
Maximum output 300 mW (EIAJ/DC) Maximum output 300 mW (EIAJ/DC)
Input jack EXT MIC jack (monaural mini-jack) (1) Input jack EXT MIC jack (monaural mini-jack) (1)
Output jack EARPHONE jack (monaural mini-jack) (1) Output jack EARPHONE jack (monaural mini-jack) (1)
Other jack DC 3 V jack Other jack DC 3 V jack
Speaker Diameter 50 mm, 4 ohms Speaker Diameter 50 mm, 4 ohms
Recording system DC bias Recording system DC bias
Erasing system Magnet erasure Erasing system Magnet erasure
Recording speed Approx. 4.8 cm/sec. with the REC MODE Power sources DC 3 V using two R6 (size AA) dry cell bat-
switch set to NORMAL teries
Approx. 2.4 cm/sec. with the REC MODE AC house current using the AC adaptor Aiwa
switch set to EXTENDED AC-D302
Power sources DC 3 V using two R6 (size AA) dry cell bat- Battery life
teries Battry EIAJ Recording EIAJ 10 mW
AC house current using the AC adaptor Aiwa Manganese (R6P) Batteries Approx. 5 hrs Approx. 6.5 hrs
AC-D302 Alkaline (LR) batteries Approx. 18.5 hrs Approx. 13.5hrs
Battery life Dimensions 113.5 (W) x 90 (H) x 38.4 (D) mm
Battry EIAJ Recording EIAJ 10 mW (41/2 x 35/8 x 19/16 in.)
Manganese (R6P) Batteries Approx. 5 hrs Approx. 6.5 hrs Weight Approx. 166 g, 5.8 oz (excluding batteries)
Alkaline (LR) batteries Approx. 18.5 hrs Approx. 13.5hrs
Dimensions 90 (W) x 113.5 (H) x 41 (D) mm
(33/8 x 41/2 x 15/8 in.)
Weight Approx. 170 g, 6 oz (excluding batteries) ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
