                                              XR-H2000 EZ,K




  SERVICE MANUAL
      COMPACT DISC STEREO                   BASIC TAPE MECHANISM : 2ZM-3MK2 PR4NM
           SYSTEM                           BASIC CD MECHANISM : AZG-1 ZD3RNDM



            STEREO          CD         CASSETTE GRAPHIC                            REMOTE
SYSTEM     RECEIVER       PLAYER         DECK   EQUALISER SPEAKERS                 CONTROL
XR-H2000   MX-NH2000 DX-NH2000 FX-NH2000 GE-NH2000 SX-NDPH2100 RC-ZAS04
