Image preview - the first page of the document
cd mechanism aiwa 4zg-1


>> Download cd mechanism aiwa 4zg-1 documenatation <<

Text preview - extract from the document
                        4ZG-1                English




SERVICE MANUAL                               KSM-2131FAM
                                             3ZG-2 E1
 CD MECHANISM           BASIC CD MECHANISM :
                                             3ZG-2 E3
                                             3ZG-2 E4



               TYPE     BASIC CD MECHANISM
          Z3NDSH        3ZG-2 E1
          Z3RDLSHJ      3ZG-2 E3
          Z3RNDSHJ      3ZG-2 E1
          Z3RNDSH       3ZG-2 E1
          Z3RNSMDJ      3ZG-2 E1
          Z3RSHMDJ      3ZG-2 E3
          PZ3MD         3ZG-2 E4
          Z4RNDSH       KSM-2131 FAM
          Z4RNSHMDJ     KSM-2131 FAM




                                                           A
                                                       D AT
           S/M Code No. 09-992-325-4N2
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING
This set employs laser. Therefore, be sure to follow carefully the        CAUTION
instructions below when servicing.                                        Use of controls or adjustments or performance of procedures
                                                                          other than those specified herein may result in hazardous
WARNING!                                                                  radiation exposure.
WHEN SERVICING, DO NOT APPROACH THE LASER EXIT
WITH THE EYE TOO CLOSELY. IN CASE IT IS NECESSARY TO                      ATTENTION
CONFIRM LASER BEAM EMISSION. BE SURE TO OBSERVE                           L'utilisation de commandes, r
