Image preview - the first page of the document
>> Download aiwa VX-T147020ph[1].part2 documenatation <<Text preview - extract from the document VX-T1470 PH
SERVICE MANUAL
INTEGRATED COLOR TV/VIDEO
BASIC TAPE MECHANISM : OVD-5
CASSETTE RECORDER
SPECIFICATIONS
GENERAL
POWER REQUIREMENTS ................. 110-240V AC, 50/60Hz VIDEO SIGNAL SYSTEM ................ PAL/MESECAM color system,
POWER CONSUMPTION ................... 57W 625 lines, 50 fields
WEIGHT .............................................. 13.5 kg (29.7 lbs.) VIDEO HEAD ................................... Azimuth 2 head
DIMENSIONS ...................................... 435 mm (W) x 365 mm (D) x USABLE CASSETTES ..................... VHS video cassette
384.5 mm (H) TAPE SPEED ................................... PAL/MESECAM
(17 1/8 x 14 3/8 x 15 1/4 in.) SP: 23.39 mm/sec
LP: 11.69 mm/sec
TV SECTION NTSC (Playback SP only)
PICTURE TUBE .................................. 208 mm (W) x 211 mm (H) 33.35 mm/sec
(8 1/4 x 8 3/8 in.) RECORDING/PLAYBACK TIME ..... PAL/MESECAM
335 mm (diagonal) (13 1/4 in.) SP: 4 hours 20 minutes max.
TUNER SYSTEM ................................ Voltage synthesized tuner with E-260 tape
CHANNEL COVERAGE ...................... VHF-L (low): E2 to S7 LP: 8 hours 40 minutes max.
VHF-H (high): S8 to S36 with E-260 tape
UHF: S37 to 69 NTSC (Playback SP only)
TV SYSTEM ........................................ B/G, D/K, I 3 hours with T-180 tape
HORIZONTAL RESOLUTION ............ 240 lines VIDEO INPUT ................................... 1.0Vp-p, 75 ohm, unbalanced
VIDEO OUTPUT .............................. 1.0Vp-p, 75 ohm, unbalanced
VCR SECTION VIDEO S/N ....................................... 53dB (nominal)
OPERATING TEMPERATURE ........... 5
