Service Manuals, User Guides, Schematic Diagrams or docs for : AIWA TV vx-t1470

<< Back | Home

Most service manuals and schematics are PDF files, so You will need Adobre Acrobat Reader to view : Acrobat Download Some of the files are DjVu format. Readers and resources available here : DjVu Resources
For the compressed files, most common are zip and rar. Please, extract files with Your favorite compression software ( WinZip, WinRAR ... ) before viewing. If a document has multiple parts, You should download all, before extracting.
Good luck. Repair on Your own risk. Make sure You know what You are doing.




Image preview - the first page of the document
vx-t1470


>> Download vx-t1470 documenatation <<

Text preview - extract from the document
                                                                                         VX-T1470 PH




SERVICE MANUAL
INTEGRATED COLOR TV/VIDEO
                                                                                          BASIC TAPE MECHANISM : OVD-5
    CASSETTE RECORDER

                                                                            SPECIFICATIONS

GENERAL
POWER REQUIREMENTS .................                    110-240V AC, 50/60Hz             VIDEO SIGNAL SYSTEM ................ PAL/MESECAM color system,
POWER CONSUMPTION ...................                   57W                                                                                625 lines, 50 fields
WEIGHT ..............................................   13.5 kg (29.7 lbs.)              VIDEO HEAD ................................... Azimuth 2 head
DIMENSIONS ......................................       435 mm (W) x 365 mm (D) x        USABLE CASSETTES ..................... VHS video cassette
                                                        384.5 mm (H)                     TAPE SPEED ................................... PAL/MESECAM
                                                        (17 1/8 x 14 3/8 x 15 1/4 in.)                                                     SP: 23.39 mm/sec
                                                                                                                                           LP: 11.69 mm/sec
TV SECTION                                                                                                                                 NTSC (Playback SP only)
PICTURE TUBE .................................. 208 mm (W) x 211 mm (H)                                                                    33.35 mm/sec
                                                   (8 1/4 x 8 3/8 in.)                   RECORDING/PLAYBACK TIME ..... PAL/MESECAM
                                                   335 mm (diagonal) (13 1/4 in.)                                                          SP: 4 hours 20 minutes max.
TUNER SYSTEM ................................ Voltage synthesized tuner                                                                        with E-260 tape
CHANNEL COVERAGE ...................... VHF-L (low): E2 to S7                                                                              LP: 8 hours 40 minutes max.
                                                   VHF-H (high): S8 to S36                                                                     with E-260 tape
                                                   UHF: S37 to 69                                                                          NTSC (Playback SP only)
TV SYSTEM ........................................ B/G, D/K, I                                                                             3 hours with T-180 tape
HORIZONTAL RESOLUTION ............ 240 lines                                             VIDEO INPUT ................................... 1.0Vp-p, 75 ohm, unbalanced
                                                                                         VIDEO OUTPUT .............................. 1.0Vp-p, 75 ohm, unbalanced
VCR SECTION                                                                              VIDEO S/N ....................................... 53dB (nominal)
OPERATING TEMPERATURE ........... 5
