Image preview - the first page of the document
HV-GX950


>> Download HV-GX950 documenatation <<

Text preview - extract from the document
                                                                                         HV-GX950 K
                                                                                         HV-GX900 K




SERVICE MANUAL
VIDEO CASSETTE RECORDER                                                                  BASIC TAPE MECHANISM : OVD-6


                                                                          SPECIFICATIONS

POWER REQUIREMENTS .................                    230 V AC, 50 Hz                   TAPE SPEED ................................... PAL          SP: 23.39 mm/sec
POWER CONSUMPTION ...................                   14W                                                                                           LP: 11.69 mm/sec
WEIGHT ..............................................   3.5 kg (7.7 lbs.)                                                                     NTSC (playback only)
DIMENSIONS ......................................       380 mm (W) x 267 mm (D) x                                                                     SP: 33.35 mm/sec
                                                        95 mm (H)                         RECORDING/PLAYBACK TIME .....                       PAL SP: 5 hours with E-300 tape
                                                        (15 x 10 5/8 x 3 3/4 in.)                                                                     LP: 10 hours with E-300 tape
OPERATING TEMPERATURE ...........                       5
