Image preview - the first page of the document
>> Download alpine_iva-w200_w200e documenatation <<
Text preview - extract from the document
SERVICE MANUAL
Mobile Multimedia Station
Mobile Media Station
TM
DIGITAL VIDEO
Caution : The part marked with ! is generating a high voltage, so care will be necessary when working.
(IVA-W200)
TO ALPINE Home Page
3 / 06-A
A05036
IVA-W200/IVA-W200E
The following cautions will prevent accidents in the workplace and will ensure safe products.
*The symbols indicate caution is needed to prevent injuries and damage to property.
The symbols and their meanings follow.
If you ignore this symbol and handle the product incorrectly or unsafely,
Warning serious injury or death may result.
If you ignore this symbol and handle the product incorrectly or unsafely,
Caution injury or only material damage may result.
*The following symbols indicate two levels of cautions.
When you see this symbol, you have to be very careful.
When you see this symbol, you have to follow the instructions there.
Warning
Do not look squarely into the laser light Fuse Caution
coming from the pickup. Always use a designated fuse.
You may loose you sight. Use of an incorrect fuse may result in a fire.
Caution
Do not allow wiring to be caught in the Battery Caution
screw/chassis. Use the designated battery.
If wiring is caught in the screw/chassis, it may Confirm the correct polarity and seat of the battery.
cause a short circuit, resulting in a fire. An incorrect battery or an improperly connected or
seated battery may result in a fire.
High Temperature Caution Designated Parts Caution
Touching the heat sink may cause severe burns. Look up the part list and ensure that only
designated parts are used to prevent problems or
accidents.
Reverse Power Supply Connections or Wiring Caution
Misconnections Caution Ensure that the wiring is correct when rewiring to
Reverse power supply connections or prevent problems with ignition/breakdown.
misconnections may cause ignition problems and
smoke may result.
Soldering Caution Wear Gloves
Hot solder from solder splash may cause severe Wear gloves to prevent electrical shocks or injury
burns. from the end face of the metal.
For the FDA laser standard, the following CAUTION label is stuck on each product.
Please be careful for repair.
CAUTION-Laser radiation when open, DO NOT STARE INTO BEAM
-2-
IVA-W200/IVA-W200E
Contents
Packing Assembly Parts List 4
Packing Method View 4
System Connections 5 to 14
Specifications 15 to 19
Extension Cable 20
Adjustment Procedures 21 to 26
Block Diagram 27 , 28
Parts Layout on P.W.Boards and Wiring Diagram 29 to 37
Schematic Diagram 38 to 55
Terminal Voltage of IC/TR 56 to 83
Description of IC Terminal 84 to 94
Exploded View (Cabinet) 95 to 97
Exploded View (DVD Deck Mechanism) (DV37M15B) 98
NOTE : Due to continuing product improvement, specifications and designs are subject to
change without notice.
-3-
IVA-W200/IVA-W200E
Packing Assembly Parts List Packing Method View
Symbol Part No. Description
No.
101-1 03S60820Y16 SCR,MCH 5X8 ZN A
101-2 03S60820Y17 SCR,MCH 5X8 ZN A
#1 101-3 60S70585F01 BAT,LIT.3V (CR2025) 105 101 #1
102 15-05590Z01 CASE,INNER
103
#1 103 97-02173Z01 ASSY,SBNN00003A
#1 104 68-04123Z67 O/M AOAM AODL
$1 104 68-04123Z69 O/M AAO AODL 107 back
%1 104 68-04123Z69 O/M AAO AODL
&1 104 68-05946Z33 O/M AOCH
surface
105 01T75479Y02 ASSY,REMOTE W200A
#1 106 09-05505Z01 ASSY,POW WIRE W100A
$1 106 09-05506Z01 ASSY,POW WIRE W100E
%1 106 09-05506Z01 ASSY,POW WIRE W100E
&1 106 09-05506Z01 ASSY,POW WIRE W100E
107 07-01964Z01 BKT,RELEASE
104
108 33-05591Z01 FACE,PLATE
NOTE : #1 : For North American Model Only,
$1 : For General Foreign (Region3) Model Only,
%1 : For General Foreign (Region4) Model Only,
&1 : For Chinese Model Only,
Others : Common.
Product
108
BO 106
TT
OM
sid
e
102
#1
#1
102 103
101 -1 101 -2 101 -3
X6 X8 X1
X1
X1
105 106 107 108
X1 X1
X2
X1
TO CONTENTS
-4-
IVA-W200/IVA-W200E
System Connections
(North American Model Only)
Connections
Antenna
(Yellow)
(White)
To Video Input terminal
(Red) To Audio Input terminals
(Yellow) (R, L)
To Video output terminal
(White)
(Red) To Audio output terminals
(R, L)
REMOTE OUT
To remote input lead
(White/Brown)
REMOTE IN
To remote output lead
(White/Brown)
REVERSE
To plus side of the back
(Orange/White)
lamp signal lead of the car
M.CONT
To monitor control lead
(White/Pink)
Rear Left
Amplifier
Rear Right
Front Left
Amplifier
Front Right
Amplifier Subwoofers
Ai-NET
EQ/DIV NORM To iPod
*
CD Changer
(Sold Separately)
REMOTE
TURN-ON
To amplifier or
(Blue/White)
equalizer
POWER ANT
(Blue)
To power antenna
AUDIO INTERRUPT IN
To vehicle phone
(Pink/Black)
PARKING BRAKE
To the parking brake
(Yellow/Blue)
signal lead
FOOT BRAKE
To the foot brake cord
(Yellow/Black)
or brake lamp cord
IGNITION
(Red) Ignition key
BATTERY
(Yellow)
GND
Battery
(Black)
SPEAKER SPEAKER SPEAKER SPEAKER
LEFT LEFT RIGHT (Violet/ RIGHT
FRONT (White/ REAR (Green) REAR
Black) FRONT (Gray)
(White) Black) (Green/ (Violet) (Gray/
Black) Black)
Speakers
Front left Rear left Rear right Front right
