Keysight Technologies, Inc.
Multi-Channel Antenna Calibration,
Reference Solution


                                 Solution Brochure
Multi-channel antenna calibration                                     Multi-channel antenna calibration,
challenges                                                            Reference Solution
As the market for multi-channel, phased-array antenas grow,           The multi-channel antenna test Reference Solution is a com-
manufacturers experience increased pressure to reduce cost            bination of hardware, software, and measurement expertise
and increase test capacity. At the same time, manufacturers           providing the essential components of a narrow-band antenna
would like to expand test system flexibility to cover broad use       calibration test system. This enables engineers to use, ehance,
cases and provide options for future upgrades. The calibration        or modify the test system as required to meet specific test
and testing of multi-channel antennas brings many challenges          application needs including scalable channel count, options
and, therefore requires a new testing approach:                       for downconversion of antenna receive channels, selectable
