Image preview - the first page of the document
>> Download HP E1420B Plug & Play Note documenatation <<Text preview - extract from the document Agilent Technologies | ADN | Agilent E1420 VXIplug&play Instrument Driver Read Me
Agilent E1420 VXIplug&play Instrument Driver Read Me
README.TXT for HP E1420 Counter
Contents:
1 Introduction
2 VTL/VISA Specific Information
2.1 Instrument Addresses
2.2 Executing the Soft Front Panel without VTL/VISA
3 Using the HP E1420 Driver in Application Development Environments
3.1 C/C++
3.2 Microsoft Visual Basic
4.0 Known Defects
5.0 Online Information
6.0 Revision History
- ---------------------------------------------------------------------------
1. Introduction
The help file included with the HP E1420 VXIplug&play driver contains
instrument and programming information. This readme file contains
additional information for the HP VXIplug&play programmer.
- ---------------------------------------------------------------------------
2. VTL/VISA Specific Information
The following topics refer to instances when the driver is used with
different versions of VTL.
2.1 Instrument Addresses
When using HP VXIplug&play instrument drivers, instrument addresses must
http://adn.tm.agilent.com/index.cgi?CONTENT_ID=451 (1 of 3) [4/6/2006 11:02:51 AM]
Agilent Technologies | ADN | Agilent E1420 VXIplug&play Instrument Driver Read Me
be all uppercase letters. Implementation of the addressing scheme is
vendor specific and some vendors support mixed cases. However, for
maximum portability, the instrument address should use uppercase
characters only.
For example: use "VXI0::56::INSTR" instead of "vxi0::56::instr"
2.2 Executing the Soft Front Panel without VTL/VISA
The VTL/VISA dynamic link library provides a communication library
between your program and the instrument. The SFP may be executed without
VISA or without the HPE1420.dll present. It will do a partial emulation
of the hardware for demo purposes.
- --------------------------------------------------------------------------
3. Using the HP E1420 Driver in Application Development Environments
This section offers suggestions on using the hpe1420.dll within
various application development environments.
3.1 C/C++
Refer to your C/C++ manuals for information on linking
and calling .DLLs.
Rebuilding the driver DLL should be done in a different directory than
the one the driver was installed in order to differentiate the changes.
3.2 Microsoft Visual Basic
Refer to the Microsoft Visual BASIC manual for information on calling DLLs.
The BASIC include file is hpe1420.bas, which is contained in the directory
~vxipnpwinXXinclude. The ~ refers to the directory in the VXIPNP variable.
By default this is set to C:. winXX refers to the operating system -- win95
or winNT.
4.0 Known Defects
- ---------------------------------------------------------------------------
5.0 Online Information
The latest copy of this VXIplug&play driver and other HP
http://adn.tm.agilent.com/index.cgi?CONTENT_ID=451 (2 of 3) [4/6/2006 11:02:51 AM]
Agilent Technologies | ADN | Agilent E1420 VXIplug&play Instrument Driver Read Me
VXIplug&play and SCPI drivers are available at the Hewlett-Packard
customer WWW site: http://www.hp.com/go/inst_drivers
If you do not have Internet access, the drivers can be obtained by
contacting your country support organization. In the US, the phone
number is 800-452-4844.
A list of contact information for non-US countries is available on
the Access HP website: http://www.tmo.hp.com/tmo/contacts/English/callcenters.html
- ---------------------------------------------------------------------------
6.0 Revision History
A.01.00 May 1, 1996 Initial Release.
A.02.00 Aug 1996
A.02.01 2/98
hpe1420_32.dll: A.02.01
hps1420.exe : A.02.01
A.02.02 11/98
hpe1420_32.dll: A.02.02
hps1420.exe : A.02.02
A.02.03 8/99
hpe1420_32.dll: A.02.02
hps1420.exe : A.02.02
- ---------------------------------------------------------------------------
