Service Manuals, User Guides, Schematic Diagrams or docs for : BECKER BE3309 BE3309
<< Back | HomeMost service manuals and schematics are PDF files, so You will need Adobre Acrobat Reader to view : Acrobat Download Some of the files are DjVu format. Readers and resources available here : DjVu Resources
For the compressed files, most common are zip and rar. Please, extract files with Your favorite compression software ( WinZip, WinRAR ... ) before viewing. If a document has multiple parts, You should download all, before extracting.
Good luck. Repair on Your own risk. Make sure You know what You are doing.
Image preview - the first page of the document
>> Download BE3309 documenatation <<
Text preview - extract from the document
Spare Parts List Type:3302_e Page:1 of 21 Pos. Part.-No. Denomination 1 1284614 CHASSIS VMT 2 1309765 COVER, CHASSIS 3 1284622 HOLDING SPRING-RIGHT 4 1284630 HOLDING SPRING-LEFT 5 1271997 PROTECTION CAP -D2B HEADER- AMP 6 1278916 CONNECTOR 21 POL D&R K37000300 7 1246909 HEAT SINK 3310 WGR11318 8 1246917 IC-HOLDER 9 1246992 SCREENING FRAME-FM- WITH ANT.SOCKET 10 1244744 TAPEDECK ASSY ALP GR71-S36B (MJ'98) 11 1285300 OPERATION ESCUTCHEON 12 1286579 P.C. BOARD FRONT 9090 13 xxxxxxx TRIM PLATE FIX CPL. RIGHT 14 1294391 OPERATION ESCUTCHEON MOBIL CPL. LEFT 15 1294415 COVER, MOBIL AUDIO 30 US 16 1295421 TRIM PLATE CPL. LEFT 17 1283812 CONTACT MAT -12 -KEYS 18 1284150 UNCLAMP 19 1284169 WITH CLOCK SPRING 20 1309110 LCD-MODUL CPL. 21 1286552 TRIM PLATE LCD PRINTING 22 1284193 COVER, LCD 23 1284207 FLEX LINE 24 1284266 ROTATION DAMPER 25 1284258 CLOCK SPRING-LCD 26 1257919 SPRING CLAMP (CC) 27 1284290 CONTROL LEVER (CC) 28 1284061 LIGHT CONDUCTOR (CC) 29 1284177 BUTTON TURNING KNOB / ON BU1802 1284282 CONNECTOR,7POL MB98/DIN AMP 487951-7 BU1803 1284282 CONNECTOR,7POL MB98/DIN AMP 487951-7 C101 1223925 CECA-CH 6P8 J NP0 0603 BAW SPE0030A315 C102 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315 C103 1223909 CECA-CH 1P5 J NP0 0603 BAW SPE0030A315 C104 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315 C105 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C106 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315 C107 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315 C108 1249150 ALCA 22U M 16V BAW SPE0067A312-RM2,5 C109 1233971 CECA-CH 10P J NP0 0603 BAW SPE0030A315 C110 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315 C111 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C112 1288180 CECA-CH 1P8 J NPO 0603 BAW SPE0030A315 C113 1223925 CECA-CH 6P8 J NP0 0603 BAW SPE0030A315 C114 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315 C115 1238787 CECA-CH 5P6 J NP0 0603 BAW SPE0030A315 Spare Parts List Type:3302_e Page:2 of 21 C116 1223925 CECA-CH 6P8 J NP0 0603 BAW SPE0030A315 C117 1223951 CECA-CH 22P J NP0 0603 BAW SPE0030A315 C118 1223976 CECA-CH 47P J NP0 0603 BAW SPE0030A315 C120 1238787 CECA-CH 5P6 J NP0 0603 BAW SPE0030A315 C121 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315 C122 1243012 CECA-CH 27P J NPO 0603 BAW SPE0030A315 C123 1166751 CECA-CH 4N7 K X7R 0805 BAW SPE0015A315 C125 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C126 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315 C127 1249150 ALCA 22U M 16V BAW SPE0067A312-RM2,5 C128 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C1301 1238787 CECA-CH 5P6 J NP0 0603 BAW SPE0030A315 C1302 1258321 CECA-CH 3P3 J NP0 0603 BAW SPE0030A315 C1303 1233971 CECA-CH 10P J NP0 0603 BAW SPE0030A315 C1304 1119117 CECA-CH 10N J X7R 0805 BAW SPE0014A315 C1306 1243012 CECA-CH 27P J NPO 0603 BAW SPE0030A315 C1307 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315 C1308 1223925 CECA-CH 6P8 J NP0 0603 BAW SPE0030A315 C1309 1258321 CECA-CH 3P3 J NP0 0603 BAW SPE0030A315 C1314 1223976 CECA-CH 47P J NP0 0603 BAW SPE0030A315 C1331 1119214 CECA-CH 100N J X7R 1206 BAW SPE0016A315 C1332 1119214 CECA-CH 100N J X7R 1206 BAW SPE0016A315 C1333 1171984 ALCA 10U M 35V G BAW SPE0053A31 RM2,5 C1334 1171984 ALCA 10U M 35V G BAW SPE0053A31 RM2,5 C1336 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C151 1223968 CECA-CH 33P J NP0 0603 BAW SPE0030A315 C152 1223925 CECA-CH 6P8 J NP0 0603 BAW SPE0030A315 C153 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315 C155 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315 C156 0356417 FOCA 6N8 K 100V G WIM FKS2-RM5 C157 1246631 CECA-CH 390P J NP0 0603 BAW SPE0030A315 C158 1119176 CECA-CH 22N J X7R 0805 BAW SPE0014A315 C159 1249169 ALCA 47U M 16V BAW SPE0068A312-RM2,5 C161 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315 C162 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C165 1119222 CECA-CH 470P K X7R 0805 BAW SPE0015A315 C166 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315 C168 1249169 ALCA 47U M 16V BAW SPE0068A312-RM2,5 C169 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C1801 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C1802 1223951 CECA-CH 22P J NP0 0603 BAW SPE0030A315 C1803 1223951 CECA-CH 22P J NP0 0603 BAW SPE0030A315 C1804 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315 C1805 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315 C1808 1238647 TACA-CH 1U K B G 35V BAW SPE0005A313 C1810 1166751 CECA-CH 4N7 K X7R 0805 BAW SPE0015A315 C1811 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315 Spare Parts List Type:3302_e Page:3 of 21 C1836 1166751 CECA-CH 4N7 K X7R 0805 BAW SPE0015A315 C1861 1246208 CECA-CH 330N J X7R 1206 16V MUR GRM42-6 C1862 1246208 CECA-CH 330N J X7R 1206 16V MUR GRM42-6 C1863 1246208 CECA-CH 330N J X7R 1206 16V MUR GRM42-6 C1864 1246208 CECA-CH 330N J X7R 1206 16V MUR GRM42-6 C1865 1246208 CECA-CH 330N J X7R 1206 16V MUR GRM42-6 C1866 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C1867 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C1868 1028715 TACA-CH 4U7 M B G 10V BAW SPE0008A313 C1869 1028715 TACA-CH 4U7 M B G 10V BAW SPE0008A313 C1870 1028715 TACA-CH 4U7 M B G 10V BAW SPE0008A313 C1871 1166751 CECA-CH 4N7 K X7R 0805 BAW SPE0015A315 C1900 1223933 CECA-CH 15P J NP0 0603 BAW SPE0030A315 C1901 1223933 CECA-CH 15P J NP0 0603 BAW SPE0030A315 C1902 1223933 CECA-CH 15P J NP0 0603 BAW SPE0030A315 C1903 1223933 CECA-CH 15P J NP0 0603 BAW SPE0030A315 C1904 1223933 CECA-CH 15P J NP0 0603 BAW SPE0030A315 C1905 1223933 CECA-CH 15P J NP0 0603 BAW SPE0030A315 C1906 1223933 CECA-CH 15P J NP0 0603 BAW SPE0030A315 C1907 1223933 CECA-CH 15P J NP0 0603 BAW SPE0030A315 C204 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315 C206 1119176 CECA-CH 22N J X7R 0805 BAW SPE0014A315 C207 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315 C209 1249150 ALCA 22U M 16V BAW SPE0067A312-RM2,5 C210 1119176 CECA-CH 22N J X7R 0805 BAW SPE0014A315 C211 1073516 CECA-CH 150P J NP0 0805 BAW SPE0003A315 C212 1166751 CECA-CH 4N7 K X7R 0805 BAW SPE0015A315 C213 1167170 CECA-CH 2N2 K X7R 0805 BAW SPE0015A315 C214 1119176 CECA-CH 22N J X7R 0805 BAW SPE0014A315 C215 1182943 CECA-CH 47N K X7R 0805 BAW SPE0015A315 C217 1119176 CECA-CH 22N J X7R 0805 BAW SPE0014A315 C218 1066110 CECA-CH 470P J NP0 0805 BAW SPE0003A315 C219 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315 C226 1234897 CECA-CH 150P J P2H 0603 MUR GRM39 C227 1270788 CECA-CH 1N2 J S2H 1206 50V MUR GRM42-6 C232 1258877 ALCA 4U7 M 50V G BAW SPE0049A31 RM2,5 C233 1258877 ALCA 4U7 M 50V G BAW SPE0049A31 RM2,5 C234 1119192 CECA-CH 33N K X7R 0805 BAW SPE0015A315 C235 1246321 CECA-CH 220N K X7R 1206 BAW SPE0036A315 C236 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315 C237 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C238 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C239 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C240 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C241 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C251 1166751 CECA-CH 4N7 K X7R 0805 BAW SPE0015A315 C252 1272357 TACA-CH 6U8 K B G 16V SNPB SIE B45196-H Spare Parts List Type:3302_e Page:4 of 21 C253 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C301 1119117 CECA-CH 10N J X7R 0805 BAW SPE0014A315 C303 1246321 CECA-CH 220N K X7R 1206 BAW SPE0036A315 C304 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C310 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C312 1258877 ALCA 4U7 M 50V G BAW SPE0049A31 RM2,5 C314 1223976 CECA-CH 47P J NP0 0603 BAW SPE0030A315 C315 1223984 CECA-CH 68P J NP0 0603 BAW SPE0030A315 C317 1223941 CECA-CH 18P J NP0 0603 BAW SPE0030A315 C319 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C321 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C322 1119060 CECA-CH 1N K X7R 0805 BAW SPE0015A315 C323 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C324 1223992 CECA-CH 150P J NP0 0603 BAW SPE0030A315 C325 1223992 CECA-CH 150P J NP0 0603 BAW SPE0030A315 C327 1223968 CECA-CH 33P J NP0 0603 BAW SPE0030A315 C328 1258877 ALCA 4U7 M 50V G BAW SPE0049A31 RM2,5 C329 1249150 ALCA 22U M 16V BAW SPE0067A312-RM2,5 C330 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315 C331 1182943 CECA-CH 47N K X7R 0805 BAW SPE0015A315 C332 1233971 CECA-CH 10P J NP0 0603 BAW SPE0030A315 C333 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C334 1246208 CECA-CH 330N J X7R 1206 16V MUR GRM42-6 C335 1246208 CECA-CH 330N J X7R 1206 16V MUR GRM42-6 C336 1182943 CECA-CH 47N K X7R 0805 BAW SPE0015A315 C337 1258796 CECA-CH 56P J S2H 0603 50V MUR GRM39 C338 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C339 1182943 CECA-CH 47N K X7R 0805 BAW SPE0015A315 C340 1244035 CECA-CH 560P J U2J 0603 MUR GRM39 C343 1182943 CECA-CH 47N K X7R 0805 BAW SPE0015A315 C344 1225545 CECA-CH 120P J 0603 NP0 BAW SPE0030A315 C345 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C346 1162241 CECA-CH 470P G NP0 0805 BAW SPE0027A315 C347 1162284 CECA-CH 560P G NP0 0805 BAW SPE0027A315 C348 1254782 CECA-CH 2N G NPO 0805 50V MUR GRM40 C349 1239961 CECA-CH 1N F NP0 0805 BAW SPE0029A315 C350 1270540 CECA-CH 560P J NPO 0603 50V MUR GRM39 C352 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315 C353 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315 C354 1283499 CECA-CH 1U K X7R 0805 10V MUR GRM 40 C360 1258877 ALCA 4U7 M 50V G BAW SPE0049A31 RM2,5 C361 1119192 CECA-CH 33N K X7R 0805 BAW SPE0015A315 C362 1171879 ALCA 1U M 50V G BAW SPE0042A312 RM2,5 C363 1270648 CECA-CH 68N J X7R 0805 25V MUR GRM40 C364 1119192 CECA-CH 33N K X7R 0805 BAW SPE0015A315 C365 1119192 CECA-CH 33N K X7R 0805 BAW SPE0015A315 C367 1119192 CECA-CH 33N K X7R 0805 BAW SPE0015A315 Spare Parts List Type:3302_e Page:5 of 21 C368 1276220 CECA-CH 2N2 J X7R 0805 50V BAW SPE0014A C369 1119117 CECA-CH 10N J X7R 0805 BAW SPE0014A315 C370 1246321 CECA-CH 220N K X7R 1206 BAW SPE0036A315 C371 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315 C374 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315 C375 1227653 CECA-CH 12P J NP0 0603 BAW SPE0030A C380 1249150 ALCA 22U M 16V BAW SPE0067A312-RM2,5 C423 1258877 ALCA 4U7 M 50V G BAW SPE0049A31 RM2,5 C424 1258907 ALKO-CH 1U M 50V I G BAW SPE0161A312 C425 1182943 CECA-CH 47N K X7R 0805 BAW SPE0015A315 C426 1182943 CECA-CH 47N K X7R 0805 BAW SPE0015A315 C427 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C428 1258877 ALCA 4U7 M 50V G BAW SPE0049A31 RM2,5 C429 1255711 CECA-CH 220N J X7R 1206 BAW SPE0037A315 C430 1255711 CECA-CH 220N J X7R 1206 BAW SPE0037A315 C431 1255711 CECA-CH 220N J X7R 1206 BAW SPE0037A315 C432 1255711 CECA-CH 220N J X7R 1206 BAW SPE0037A315 C433 1083945 CECA-CH 2N7 J NP0 1206 BAW SPE0007A315 C434 1083945 CECA-CH 2N7 J NP0 1206 BAW SPE0007A315 C435 1258877 ALCA 4U7 M 50V G BAW SPE0049A31 RM2,5 C437 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315 C438 1246321 CECA-CH 220N K X7R 1206 BAW SPE0036A315 C439 1258877 ALCA 4U7 M 50V G BAW SPE0049A31 RM2,5 C440 1258877 ALCA 4U7 M 50V G BAW SPE0049A31 RM2,5 C441 1258877 ALCA 4U7 M 50V G BAW SPE0049A31 RM2,5 C442 1258877 ALCA 4U7 M 50V G BAW SPE0049A31 RM2,5 C449 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C450 1119060 CECA-CH 1N K X7R 0805 BAW SPE0015A315 C451 1182943 CECA-CH 47N K X7R 0805 BAW SPE0015A315 C452 1066102 CECA-CH 330P J NP0 0805 BAW SPE0003A315 C453 1279416 CECA-CH 1N5 K X7R 0805 50V BAW SPE0015A3 C454 1279416 CECA-CH 1N5 K X7R 0805 50V BAW SPE0015A3 C455 1258877 ALCA 4U7 M 50V G BAW SPE0049A31 RM2,5 C456 1223976 CECA-CH 47P J NP0 0603 BAW SPE0030A315 C457 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C458 1270648 CECA-CH 68N J X7R 0805 25V MUR GRM40 C459 1119133 CECA-CH 15N J X7R 0805 BAW SPE0014A315 C471 1171984 ALCA 10U M 35V G BAW SPE0053A31 RM2,5 C472 1083899 CECA-CH 820P J NP0 1206 BAW SPE0006A315 C473 1171984 ALCA 10U M 35V G BAW SPE0053A31 RM2,5 C474 1083899 CECA-CH 820P J NP0 1206 BAW SPE0006A315 C475 1223976 CECA-CH 47P J NP0 0603 BAW SPE0030A315 C483 1253441 FOKO-CH 10N J 1206 50V G PAN ECHU C484 1253441 FOKO-CH 10N J 1206 50V G PAN ECHU C485 1258877 ALCA 4U7 M 50V G BAW SPE0049A31 RM2,5 C486 1258877 ALCA 4U7 M 50V G BAW SPE0049A31 RM2,5 C487 1171984 ALCA 10U M 35V G BAW SPE0053A31 RM2,5 Spare Parts List Type:3302_e Page:6 of 21 C488 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C501 1186973 ALCA 1M M 25V G BAW SPE0074A312-RM5 C502 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C506 1281641 FOKO 470N J 50V G BAW SPE0018A314 RM5 C507 1281641 FOKO 470N J 50V G BAW SPE0018A314 RM5 C508 1281641 FOKO 470N J 50V G BAW SPE0018A314 RM5 C509 1281641 FOKO 470N J 50V G BAW SPE0018A314 RM5 C521 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C522 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C523 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C524 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C525 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C526 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C527 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C528 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C601 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C602 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C603 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C604 1290282 ALCA 2M2 M 25V G BAW SPE0084A312RM7,5 C605 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C606 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C607 1253360 ALCA 56U M 2000/105 16V NCC SXE-VB F0 C609 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C610 1253360 ALCA 56U M 2000/105 16V NCC SXE-VB F0 C611 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315 C612 1249150 ALCA 22U M 16V BAW SPE0067A312-RM2,5 C613 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C614 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315 C616 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315 C617 1073516 CECA-CH 150P J NP0 0805 BAW SPE0003A315 C618 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315 C619 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315 C620 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315 C621 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315 C622 1229974 ALCA 100U M 25V I G BAW SPE0108 RM2,5 C623 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315 C626 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315 C627 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315 C628 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C629 1119117 CECA-CH 10N J X7R 0805 BAW SPE0014A315 C702 1281437 FOKO 100N J 63V G BAW SPE0015A314 RM5 C704 1258877 ALCA 4U7 M 50V G BAW SPE0049A31 RM2,5 C705 1281283 FOKO 15N J 63V G BAW SPE0010A314 RM5 C706 1275992 CECA-CH 330P J NP0 0603 BAW SPE0030A315 C707 1275992 CECA-CH 330P J NP0 0603 BAW SPE0030A315 C712 1281437 FOKO 100N J 63V G BAW SPE0015A314 RM5 C714 1258877 ALCA 4U7 M 50V G BAW SPE0049A31 RM2,5 Spare Parts List Type:3302_e Page:7 of 21 C715 1281283 FOKO 15N J 63V G BAW SPE0010A314 RM5 C716 1275992 CECA-CH 330P J NP0 0603 BAW SPE0030A315 C717 1275992 CECA-CH 330P J NP0 0603 BAW SPE0030A315 C720 1249150 ALCA 22U M 16V BAW SPE0067A312-RM2,5 C721 1252585 CECA-CH 470N J X5R 1206 16V MUR GRM42-6 C722 1166751 CECA-CH 4N7 K X7R 0805 BAW SPE0015A315 C723 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C724 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C725 1172085 ALCA 100U M 16V G BAW SPE0063A3 RM2,5 C780 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C781 1258877 ALCA 4U7 M 50V G BAW SPE0049A31 RM2,5 C782 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C783 1171984 ALCA 10U M 35V G BAW SPE0053A31 RM2,5 C784 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C785 1223968 CECA-CH 33P J NP0 0603 BAW SPE0030A315 C786 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315 C788 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C789 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C790 1223951 CECA-CH 22P J NP0 0603 BAW SPE0030A315 C791 1223951 CECA-CH 22P J NP0 0603 BAW SPE0030A315 C792 1233971 CECA-CH 10P J NP0 0603 BAW SPE0030A315 C793 1233971 CECA-CH 10P J NP0 0603 BAW SPE0030A315 C794 1233971 CECA-CH 10P J NP0 0603 BAW SPE0030A315 C795 1233971 CECA-CH 10P J NP0 0603 BAW SPE0030A315 C796 1233971 CECA-CH 10P J NP0 0603 BAW SPE0030A315 C797 1233971 CECA-CH 10P J NP0 0603 BAW SPE0030A315 C798 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315 C799 1173324 CECA-CH 1N J NP0 0805 BAW SPE0003A315 C801 1258907 ALKO-CH 1U M 50V I G BAW SPE0161A312 C802 1171895 ALCA 2U2 M 50V G BAW SPE0044A3 RM2,5 C803 1258907 ALKO-CH 1U M 50V I G BAW SPE0161A312 C805 1113259 CECA-CH 1N K X7R 1206 BAW SPE0017A315 C806 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315 C807 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315 C808 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315 C809 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315 C810 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315 C811 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315 C812 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315 C813 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315 C814 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315 C815 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315 C816 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315 C817 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315 C818 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315 C819 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315 C820 1234536 CECA-CH 100P J NP0 0603 BAW SPE0030A315 Spare Parts List Type:3302_e Page:8 of 21 C821 1229974 ALCA 100U M 25V I G BAW SPE0108 RM2,5 C850 1182943 CECA-CH 47N K X7R 0805 BAW SPE0015A315 C851 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C852 1119125 CECA-CH 10N K X7R 0805 BAW SPE0015A315 C854 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C856 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C857 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C908 1223951 CECA-CH 22P J NP0 0603 BAW SPE0030A315 C909 1238787 CECA-CH 5P6 J NP0 0603 BAW SPE0030A315 C919 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C928 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C929 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C939 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C949 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C958 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C968 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C969 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C980 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 C981 1246348 CECA-CH 100N K X7R 0805 BAW SPE0035A315 CT151 1279750 TRICA-CH 3P/10 NPO 100V MUR TZBX4Z100AA1 D101 1156128 INDUCTOR-CH G MUR BLM21B050S D102 1178237 CHOKE-CH 2,2UH K G SIE B82422-A1222-K D152 1246811 CHOKE-CH 47UH K G SIE B82432-A1473-K D1801 1227221 INDUCTOR-CH G MUR BLM11A221S D1802 1227221 INDUCTOR-CH G MUR BLM11A221S D301 1237691 CHOKE-CH 5,6UH K G SIE B82422-A1562-K D302 1237691 CHOKE-CH 5,6UH K G SIE B82422-A1562-K D472 1237705 INDUCTOR-CH G MUR BLM21A601S D601 1244922 CHOKE,BATT.- 200UH VOG 5730409900 D602 1237705 INDUCTOR-CH G MUR BLM21A601S D603 1237705 INDUCTOR-CH G MUR BLM21A601S D604 1237705 INDUCTOR-CH G MUR BLM21A601S D780 1237705 INDUCTOR-CH G MUR BLM21A601S D781 1000950 CHOKE-CH 47UH K G SIE B82422-A1473-K D901 1237705 INDUCTOR-CH G MUR BLM21A601S D909 1237705 INDUCTOR-CH G MUR BLM21A601S D920 1237705 INDUCTOR-CH G MUR BLM21A601S D930 1237705 INDUCTOR-CH G MUR BLM21A601S D980 1237705 INDUCTOR-CH G MUR BLM21A601S DI101 1183710 DIODE-CH BAW BB814 GRPP-1/2 G SPE0043A30 DI102 1183710 DIODE-CH BAW BB814 GRPP-1/2 G SPE0043A30 DI103 1183710 DIODE-CH BAW BB814 GRPP-1/2 G SPE0043A30 DI104 1227017 DIODE-CH TEL S392D G DI1801 1252143 DIODE-CH PHI BAS216 G DI1802 1252143 DIODE-CH PHI BAS216 G DI1803 1252143 DIODE-CH PHI BAS216 G DI231 1252143 DIODE-CH PHI BAS216 G Spare Parts List Type:3302_e Page:9 of 21 DI251 1252143 DIODE-CH PHI BAS216 G DI301 1229788 DIODE-CH BAW BA779-2/1SV234/DPA05 G SPE DI302 1252143 DIODE-CH PHI BAS216 G DI306 1073656 DIODE-CH BAW BAV99 SHIP-TO-ST.G SPE0030A DI311 1252143 DIODE-CH PHI BAS216 G DI321 1183710 DIODE-CH BAW BB814 GRPP-1/2 G SPE0043A30 DI501 1252143 DIODE-CH PHI BAS216 G DI601 1179683 DIODE-CH GIC S3B G DI603 1118757 DIODE-CH BAW 6V8 5% SHIP-TO-STOCK G SPE0 DI604 1252143 DIODE-CH PHI BAS216 G DI605 1252143 DIODE-CH PHI BAS216 G DI606 1252143 DIODE-CH PHI BAS216 G DI607 1252143 DIODE-CH PHI BAS216 G DI784 1148842 DIODE-CH BAW 4V7 SHIP-TO-STOCK G SPE0022 DI785 0672475 DIODE-CH BAW BAV70 SHIP-TO-STOCK G SPE00 DI801 1043587 DIODE-CH BAW BAW56 SHIP-TO ST.G SPE0028A DI850 1252143 DIODE-CH PHI BAS216 G DI851 1043587 DIODE-CH BAW BAW56 SHIP-TO ST.G SPE0028A DI852 1252143 DIODE-CH PHI BAS216 G DI853 1252143 DIODE-CH PHI BAS216 G DI854 1252143 DIODE-CH PHI BAS216 G DI855 1252143 DIODE-CH PHI BAS216 G DI856 1076353 DIODE-CH BAW 5V6 2% SHIP-TO-STOCK G SPE0 DI857 1252143 DIODE-CH PHI BAS216 G F102 1270486 FILTER, FMV- 100MHZ TOK/P666SNS-286IB-BR F104 1253395 FILTER, FMZ- 100MHZ TOK/P666SNS-256Z-RT F105 1284827 FILTER,AMO/FMO-120MHZ TOK VAG,VWA,GEA F1301 1284835 FILTER,WBV- TOK XXXX VAG,VWA,GEA F1302 1284835 FILTER,WBV- TOK XXXX VAG,VWA,GEA F201 1270291 FILTER, FM-ZF- 10,7MHZ TOK C805PN-0642UH F204 1291637 FILTER,FM-PHASENKR.-10,7MHZ MSI RA7008-2 F321 1294784 FILTER,AM-WBO-160MHZ SGM 970954341 F341 1246003 FILTER, AM-ZF 450KHZ TOK C805LN-0586N-SW F342 1258028 FILTER,AM-ZF1- 10,7MHZ TOK C805PN-0640-U F343 1275984 FILTER, AM-PH 450KHZ SGM5CG-960954187-SW IC151 1223526 IC-CH TEL U4283BM-BFS G IC1801 1254790 IC-DIE SEP SED1530 DOA IC1802 1299662 IC-CH BAW NEC UPD 754302-3200-04/98 3200 IC201 1220357 IC-CH SIE TDA4320X G IC231 1239139 IC-CH TEL U4275B IC301 1254308 IC-CH SIE TDA4362-P-MQFP-44-2 G IC361 1283669 IC-CH HIT HA12181FP FP-16DA IC421 1247921 IC-CH SGT TDA7340TR G IC471 1250477 IC-CH CRY CS4331-BSR G IC472 1250485 IC-CH CRY CS5331A-BSR G IC501 1271180 IC PHI TDA8569Q /N1 IC601 1240481 IC-CH SIE BSP452 G Spare Parts List Type:3302_e Page:10 of 21 IC602 1258397 IC-CH SIE TLE4276GV P-TO220-5-122 IC603 1246674 IC-CH SIE TLE4269GL P-DSO20-6 G IC604 1286242 IC-CH TOS TC7S14F G IC701 1246607 IC-CH SOY CXA2510Q IC702 1245996 IC-CH PHI 74HC03D,653 G IC780 1239147 IC-CH AUM OCC8001-01 IC781 1249101 IC-CH TOS TC7S08F G IC850 1225162 IC-CH AMC 24LC04BTI (LEER) IC850 1332211 IC-CH AMC 24LC04BTI (PROG) IC901 1245058 IC-CH SIE SAF-C515C-8R P-MQFP-80 IC902 1185616 IC-CH PHI PC74HC573D G IC903 1230964 IC-SOCKET+C469 32POL STANDARD BAW SPE000 IC903 1312960 IC BAW 27C1001/27C010 3302 27/98 3302 IC903 1243454 IC BAW 27C1001/27C010 SPE0022A308 IC904 1305859 IC-CH SAY LC3564BM-10 TE-L IC905 1185616 IC-CH PHI PC74HC573D G IC906 1185616 IC-CH PHI PC74HC573D G IC909 0588121 IC-CH PHI PC74HC02D G IC980 1012071 IC-CH BAW 74HC4094 G SPE0005A308 IC981 1012071 IC-CH BAW 74HC4094 G SPE0005A308 KF201 1185411 KERA-FIL. MUR SFE 10,7MS2A10K1-A KF202 1185411 KERA-FIL. MUR SFE 10,7MS2A10K1-A KF203 1185411 KERA-FIL. MUR SFE 10,7MS2A10K1-A KF204 1185411 KERA-FIL. MUR SFE 10,7MS2A10K1-A KF341 1253808 KERA-FILTER MUR CFWS 450 D KF343 1237721 KERA-FILTER MUR CFWS 450 HT L101 1235915 COIL+C484 14WDG 4,0 0,4 1088 L312 1252615 CHOKE-CH 220UH K G SIE B82432-S1224-K L313 1252615 CHOKE-CH 220UH K G SIE B82432-S1224-K L322 1249398 CHOKE-CH 2,2MH K G MSI C6-R/3333 L380 1000942 CHOKE-CH 10UH K G SIE B82422-A1103-K LD1801 1285122 LED-CH SIE LYT670E9008 K2/U Q62703-Q4228 LD1802 1285122 LED-CH SIE LYT670E9008 K2/U Q62703-Q4228 LD1803 1285084 LED-CH SIE LYA676E9349 P2/U Q62703-Q4232 LD1804 1285084 LED-CH SIE LYA676E9349 P2/U Q62703-Q4232 LD1805 1285084 LED-CH SIE LYA676E9349 P2/U Q62703-Q4232 LD1806 1285084 LED-CH SIE LYA676E9349 P2/U Q62703-Q4232 LD1807 1285084 LED-CH SIE LYA676E9349 P2/U Q62703-Q4232 LD1808 1285084 LED-CH SIE LYA676E9349 P2/U Q62703-Q4232 LD1809 1285084 LED-CH SIE LYA676E9349 P2/U Q62703-Q4232 LD1810 1285084 LED-CH SIE LYA676E9349 P2/U Q62703-Q4232 LD1811 1285084 LED-CH SIE LYA676E9349 P2/U Q62703-Q4232 LD1812 1285084 LED-CH SIE LYA676E9349 P2/U Q62703-Q4232 LD1813 1285084 LED-CH SIE LYA676E9349 P2/U Q62703-Q4232 LD1814 1285084 LED-CH SIE LYA676E9349 P2/U Q62703-Q4232 LD1831 1285122 LED-CH SIE LYT670E9008 K2/U Q62703-Q4228 LD1832 1285122 LED-CH SIE LYT670E9008 K2/U Q62703-Q4228 Spare Parts List Type:3302_e Page:11 of 21 LD1833 1285122 LED-CH SIE LYT670E9008 K2/U Q62703-Q4228 LD1834 1285122 LED-CH SIE LYT670E9008 K2/U Q62703-Q4228 LD1835 1285122 LED-CH SIE LYT670E9008 K2/U Q62703-Q4228 LD1836 1285122 LED-CH SIE LYT670E9008 K2/U Q62703-Q4228 LD1837 1285122 LED-CH SIE LYT670E9008 K2/U Q62703-Q4228 LD1838 1285122 LED-CH SIE LYT670E9008 K2/U Q62703-Q4228 LD1839 1285122 LED-CH SIE LYT670E9008 K2/U Q62703-Q4228 LD1840 1285122 LED-CH SIE LYT670E9008 K2/U Q62703-Q4228 LD1841 1285122 LED-CH SIE LYT670E9008 K2/U Q62703-Q4228 LD1842 1285122 LED-CH SIE LYT670E9008 K2/U Q62703-Q4228 LD1843 1285122 LED-CH SIE LYT670E9008 K2/U Q62703-Q4228 LD1844 1285122 LED-CH SIE LYT670E9008 K2/U Q62703-Q4228 LD1845 1285122 LED-CH SIE LYT670E9008 K2/U Q62703-Q4228 LD1846 1285122 LED-CH SIE LYT670E9008 K2/U Q62703-Q4228 LD1847 1285122 LED-CH SIE LYT670E9008 K2/U Q62703-Q4228 LD1848 1285122 LED-CH SIE LYT670E9008 K2/U Q62703-Q4228 LD1849 1285122 LED-CH SIE LYT670E9008 K2/U Q62703-Q4228 LD1850 1285122 LED-CH SIE LYT670E9008 K2/U Q62703-Q4228 LD1851 1285122 LED-CH SIE LYT670E9008 K2/U Q62703-Q4228 LD1852 1285122 LED-CH SIE LYT670E9008 K2/U Q62703-Q4228 LD1853 1285122 LED-CH SIE LYT670E9008 K2/U Q62703-Q4228 LD1854 1285122 LED-CH SIE LYT670E9008 K2/U Q62703-Q4228 LD1855 1285084 LED-CH SIE LYA676E9349 P2/U Q62703-Q4232 OT780 1248121 TRANSCEIVER AMP 966893 D2BOPTICAL-HEADER P251 1245090 TRIRES-CH 5K LIN 0,10W MUR RVG3A08- P701 1246615 TRIRES-CH 10K 0,10W MUR POZ3AN1-103N-T00 P702 1246615 TRIRES-CH 10K 0,10W MUR POZ3AN1-103N-T00 Q151 1280279 QUARTZ 10,250 MHZ G NDK AT-51 M.ISOPL. Q1801 1171501 KERA-RESON-CH MUR CSAC 4,19 MGCA G Q231 1245112 KERA-RESON-CH MUR CSBF456JF211 G Q451 1245112 KERA-RESON-CH MUR CSBF456JF211 G Q780 1283464 QUARTZ 16,9344 MHZ G NDK AT-51 M.ISOPL. Q901 1276964 QUARTZ 10,000 MHZ NDK AT-51 M. ISO-PL
