Image preview - the first page of the document
>> Download CANON_EOS_350D documenatation <<
Text preview - extract from the document
EOS KISS DIGITAL N (SILVER) REF.NO. C12-6071
EOS KISS DIGITAL N (BLACK) C12-6072
EOS DIGITAL REBEL XT (SILVER) C12-6073
EOS DIGITAL REBEL XT (BLACK) C12-6074
EOS 350D DIGITAL (SILVER) C12-6075
EOS 350D DIGITAL (BLACK) C12-6076
PARTS
CATALOG
1 CANON DIGITAL CAMERA EOS KISS DIGITAL N (SILVER) REF. NO. C12-6071
EOS KISS DIGITAL N (BLACK) C12-6072
EOS DIGITAL REBEL XT (SILVER) C12-6073
EOS DIGITAL REBEL XT (BLACK) C12-6074
EOS 350D DIGITAL (SILVER) C12-6075
EOS 350D DIGITAL (BLACK) C12-6076
CB3-2337 x2 (Silver)
CB3-2468 x2 (Black)
CG2-1563 (Silver)
CG2-1610 (Black) CB3-2319
CB3-2322 (Silver) (See Page 6)
CB3-2449 (Black)
CB3-2323
CB3-2348
CB3-2320
CG2-1606
CH1-8319
CB3-2317
CB3-2334 x3 (Silver)
CB3-2112 x3 (Black)
CB3-2232 (See Page 2)
(See Detail) CB3-2321
CB3-1339 x2
YN2-3472
N.S.
CB3-2232-000 (XXX) Detail
CB3-2392 A SIZE
A (XXX) 0.05mm (005)
0.10mm (010)
0.15mm (015)
CG2-1607 (Silver) 0.20mm (020)
CG2-1639 (Black) 0.25mm (025)
0.30mm (030)
0.35mm (035)
0.40mm (040)
0.45mm (045)
0.50mm (050)
PARTS LIST Pg. 1
REF.NO. C12-6071, 2, 3, 4, 5, 6
NEW PARTS No. CLASS QTY DESCRIPTION
* CB3-1339-000 000 C 2 SCREW
CB3-2112-000 000 F 3 SCREW
* CB3-2232-000 (XXX) C 1 PLATE, FINDER FOCUS
* CB3-2317-000 000 C 1 COVER, SIDE
* CB3-2319-000 000 A 1 WINDOW, TFT DISPLAY
* CB3-2320-000 000 A 1 TAPE, TFT WINDOW
* CB3-2321-000 000 C 1 CAP, INTERFACE
* CB3-2322-000 000 C 1 BUTTON, AE/FP SELECT, S
* CB3-2323-000 000 C 1 COVER, AE/FP SELECT BUTTON
* CB3-2334-000 000 C 3 SCREW
* CB3-2337-000 000 C 2 SCREW, SILVER
* CB3-2348-000 000 C 1 TAPE, TFT GROUNDING
* CB3-2392-000 000 C 1 CASE, BATTERY
* CB3-2449-000 000 C 1 BUTTON, AE/FP SELECT
* CB3-2468-000 000 C 2 SCREW
* CG2-1563-000 000 B 1 COVER ASS'Y, BACK, S
* CG2-1606-000 000 B 1 LCD ASS'Y, TFT
* CG2-1607-000 000 B 1 COVER ASS'Y, BATTERY, S
* CG2-1610-000 000 B 1 COVER ASS'Y, BACK
* CG2-1639-000 000 B 1 COVER ASS'Y, BATTERY
* CH1-8319-000 000 C 1 FPC, B-M CONNECT
* YN2-3472-000 000 B 1 PLATE, FOCUSING SCREEN
2 CANON DIGITAL CAMERA EOS KISS DIGITAL N (SILVER) REF. NO. C12-6071
EOS KISS DIGITAL N (BLACK) C12-6072
EOS DIGITAL REBEL XT (SILVER) C12-6073
EOS DIGITAL REBEL XT (BLACK) C12-6074
EOS 350D DIGITAL (SILVER) C12-6075
EOS 350D DIGITAL (BLACK) C12-6076
CB3-2332 (Silver)
CB3-1815 (Black)
(See Page 3)
CB3-2333 x2 (Silver)
CB3-2114 x2 (Black)
CG2-1564 (Silver)
CG2-1609 (Black)
(See Page 7)
CB3-2333 (Silver)
CB3-2114 (Black)
CB3-2334 (Silver)
CB3-2112 (Black)
Silver Black
DIGITAL N CB3-2331 CB3-2453 CB3-2335 (Silver)
REBEL XT CB3-2478 CB3-2479 CB3-2115 (Black)
350D DIGITAL CB3-2480 CB3-2481
CY3-1487 (Silver)
CY3-1492 (Black)
PARTS LIST Pg. 2
REF.NO. C12-6071, 2, 3, 4, 5, 6
NEW PARTS No. CLASS QTY DESCRIPTION
CB3-1815-000 000 F 1 SCREW
CB3-2112-000 000 F 1 SCREW
CB3-2114-000 000 F 3 SCREW
CB3-2115-000 000 F 1 SCREW
* CB3-2331-000 000 C 1 PLATE, MODEL NAME (JPN), S
* CB3-2332-000 000 C 1 SCREW, SILVER
CB3-2333-000 000 C 3 SCREW
* CB3-2334-000 000 C 1 SCREW, SILVER
* CB3-2335-000 000 C 1 SCREW, SILVER
* CB3-2453-000 000 C 1 PLATE, MODEL NAME (JPN)
* CB3-2478-000 000 C 1 PLATE, MODEL NAME (USA), S
* CB3-2479-000 000 C 1 PLATE, MODEL NAME (USA)
* CB3-2480-000 000 C 1 PLATE, MODEL NAME (EUR), S
* CB3-2481-000 000 C 1 PLATE, MODEL NAME (EUR)
* CG2-1564-000 000 B 1 COVER ASS'Y, FRONT, S
* CG2-1609-000 000 B 1 COVER ASS'Y, FRONT
* CY3-1487-000 000 C 1 LABEL, BODY NUMBER, S
* CY3-1492-000 000 C 1 LABEL, BODY NUMBER
3 CANON DIGITAL CAMERA EOS KISS DIGITAL N (SILVER) REF. NO. C12-6071
EOS KISS DIGITAL N (BLACK) C12-6072
EOS DIGITAL REBEL XT (SILVER) C12-6073
EOS DIGITAL REBEL XT (BLACK) C12-6074
EOS 350D DIGITAL (SILVER) C12-6075
EOS 350D DIGITAL (BLACK) C12-6076
CB3-2332 x2 (Silver) CB3-1086
CB3-1815 x2 (Black)
CB3-2332 x2 (Silver)
CB3-1815 x2 (Black)
CB3-2404
CB3-2332 (Silver)
CB3-1815 (Black)
XA4-9170-607 x2
CG2-1608 (Silver)
CG2-1566 (Black) CG2-1597
(See Page 8)
XA4-9170-457 x3
(See Page 4) CG2-1576
CG2-1604
CB1-1902 x2
CG2-1605
XA1-3200-307 x2
XA4-9200-507 x2
PARTS LIST Pg. 3
REF.NO. C12-6071, 2, 3, 4, 5, 6
NEW PARTS No. CLASS QTY DESCRIPTION
CB1-1902-000 000 F 2 SCREW
CB3-1086-000 000 F 1 SCREW
CB3-1815-000 000 F 5 SCREW
* CB3-2332-000 000 C 5 SCREW, SILVER
* CB3-2404-000 000 C 1 DIAL, DIOPTER ADJUSTING
* CG2-1566-000 000 B 1 COVER ASS'Y, TOP, S
* CG2-1576-000 000 C 1 FINDER UNIT
* CG2-1597-000 000 B 1 COVER ASS'Y, EYEPIECE
* CG2-1604-000 000 C 1 AUTO FOCUS UNIT
* CG2-1605-000 000 C 1 PLATE ASS'Y, TRIPOD SOCKET
* CG2-1608-000 000 B 1 COVER ASS'Y, TOP
XA1-3200-307 000 F 2 SCREW
XA4-9170-457 000 F 3 SCREW
XA4-9170-607 000 F 2 SCREW
XA4-9200-507 000 F 2 SCREW
4 CANON DIGITAL CAMERA EOS KISS DIGITAL N (SILVER) REF. NO. C12-6071
EOS KISS DIGITAL N (BLACK) C12-6072
EOS DIGITAL REBEL XT (SILVER) C12-6073
EOS DIGITAL REBEL XT (BLACK) C12-6074
EOS 350D DIGITAL (SILVER) C12-6075
EOS 350D DIGITAL (BLACK) C12-6076
CB2-0682-000 (XXX) Detail
A SIZE
0.03mm (003) N.S. x2 XA1-7170-167
A (XXX)
0.05mm (005)
0.08mm (008)
0.10mm (010)
0.12mm (012) WS1-6518
0.15mm (015) CB3-2351
0.18mm (018)
0.20mm (020)
N.S.
XA1-7170-257
XA4-9170-457 x3 x2
CG2-1636
CB2-0682 x3 CY3-1488
(See Detail) XA1-7170-167
(See Detail)
XA1-7170-167 x2
XA1-7170-257 x2
CG2-1552
N.S.
(See Page 5)
N.S.
CB3-2247
XA1-7170-307 x2
CY3-1489
CY3-1488 Detail
PARTS LIST Pg. 4
REF.NO. C12-6071, 2, 3, 4, 5, 6
NEW PARTS No. CLASS QTY DESCRIPTION
CB2-0682-000 (XXX) C 3 WASHER, FLANGE BACK
* CB3-2247-000 000 C 1 TAPE, LOW PASS FILTER
* CB3-2351-000 000 C 1 CASE, MAIN PCB SHIELD
* CG2-1552-000 000 B 1 PCB ASS'Y, INTERFACE
* CG2-1636-000 000 A 1 PCB ASS'Y, MAIN
* CY3-1488-000 000 A 1 PCB ASS'Y, IMAGING PROCESSING
* CY3-1489-000 000 C 1 FILTER ASS'Y, LOW PASS
XA1-7170-167 000 F 4 SCREW
XA1-7170-257 000 F 4 SCREW
XA1-7170-307 000 F 2 SCREW
XA4-9170-457 000 F 3 SCREW
WS1-6518-000 000 C 1 SLOT MODULE, CF
5 CANON DIGITAL CAMERA EOS KISS DIGITAL N (SILVER) REF. NO. C12-6071
EOS KISS DIGITAL N (BLACK) C12-6072
EOS DIGITAL REBEL XT (SILVER) C12-6073
EOS DIGITAL REBEL XT (BLACK) C12-6074
EOS 350D DIGITAL (SILVER) C12-6075
EOS 350D DIGITAL (BLACK) C12-6076
XA1-3170-257 x2
XA4-9170-457 x4
CB3-2263
CB3-2263
XA1-3170-257 x2
CG2-1545
(See Page 9) CG2-1558
XA4-9170-407 x2
CG2-1559
PARTS LIST Pg. 5
REF.NO. C12-6071, 2, 3, 4, 5, 6
NEW PARTS No. CLASS QTY DESCRIPTION
* CB3-2263-000 000 C 2 HOLDER, STRAP
* CG2-1545-000 000 C 1 PLATE ASS'Y, MAIN BASE
* CG2-1558-000 000 B 1 PCB ASS'Y, FLASH
* CG2-1559-000 000 B 1 FPC ASS'Y, ST-M CONNECT
XA1-3170-257 000 F 4 SCREW
XA4-9170-407 000 F 2 SCREW
XA4-9170-457 000 F 4 SCREW
6 CANON DIGITAL CAMERA EOS KISS DIGITAL N (SILVER) REF. NO. C12-6071
EOS KISS DIGITAL N (BLACK) C12-6072
EOS DIGITAL REBEL XT (SILVER) C12-6073
EOS DIGITAL REBEL XT (BLACK) C12-6074
EOS 350D DIGITAL (SILVER) C12-6075
EOS 350D DIGITAL (BLACK) C12-6076
N.S.
XA4-9170-307 x2
CB3-2318 (Silver)
CB3-2454 (Black) N.S.
CB3-2316 (Silver)
CB3-2451 (Black)
CB3-2343 (Silver)
CB3-2455 (Black)
CB3-2341
CB3-2357
XA4-9170-357 x4
CB3-2326 CG2-1571
CB3-2358
CH2-8339 CH5-2060 CB3-2342 (Silver)
N.S. CB3-2456 (Black)
CB3-2325
CB3-2324
CG2-1550
XA4-9170-407 x2
PARTS LIST Pg. 6
REF.NO. C12-6071, 2, 3, 4, 5, 6
NEW PARTS No. CLASS QTY DESCRIPTION
* CB3-2316-000 000 C 1 COVER, BACK, S
* CB3-2318-000 000 C 1 COVER, BACK CF, S
* CB3-2324-000 000 C 1 PLATE, EXTERNAL LCD GUIDE
* CB3-2325-000 000 C 1 PLATE, EXTERNAL LCD REFLECT
* CB3-2326-000 000 C 1 HOLDER, EXTERNAL LCD
* CB3-2341-000 000 C 1 BUTTON, SET SELECT
* CB3-2342-000 000 C 1 BUTTON, MENU-ERASE, S
* CB3-2343-000 000 C 1 BUTTON, AF SELECT, S
* CB3-2357-000 000 C 1 TAPE, LEFT
* CB3-2358-000 000 C 1 TAPE, RIGHT
* CB3-2451-000 000 C 1 COVER, BACK
* CB3-2454-000 000 C 1 COVER, BACK CF
* CB3-2455-000 000 C 1 BUTTON, AF SELECT
* CB3-2456-000 000 C 1 BUTTON, MENU-ERASE
* CG2-1550-000 000 C 1 PCB ASS'Y, BACK
* CG2-1571-000 000 C 1 FPC ASS'Y, BACK
* CH2-8339-000 000 C 1 CONNECTOR, EXTERNAL LCD
* CH5-2060-000 000 C 1 LCD, EXTERNAL
XA4-9170-307 000 F 2 SCREW
XA4-9170-357 000 F 4 SCREW
XA4-9170-407 000 F 2 SCREW
7 CANON DIGITAL CAMERA EOS KISS DIGITAL N (SILVER) REF. NO. C12-6071
EOS KISS DIGITAL N (BLACK) C12-6072
EOS DIGITAL REBEL XT (SILVER) C12-6073
EOS DIGITAL REBEL XT (BLACK) C12-6074
EOS 350D DIGITAL (SILVER) C12-6075
EOS 350D DIGITAL (BLACK) C12-6076
N.S.
N.S.
N.S.
CB3-2423
N.S. XD2-1100-172
N.S.
CB3-2424
N.S.
CS5-0263
CB3-2329
PARTS LIST Pg. 7
REF.NO. C12-6071, 2, 3, 4, 5, 6
NEW PARTS No. CLASS QTY DESCRIPTION
* CB3-2329-000 000 C 1 BUTTON, UNLOCK
* CB3-2423-000 000 C 1 BUTTON, POP UP
* CB3-2424-000 000 C 1 BUTTON, PREVIEW
* CS5-0263-000 000 C 1 SPRING, UNLOCK BUTTON
XD2-1100-172 000 F 1 RETAINING RING
8 CANON DIGITAL CAMERA EOS KISS DIGITAL N (SILVER) REF. NO. C12-6071
EOS KISS DIGITAL N (BLACK) C12-6072
EOS DIGITAL REBEL XT (SILVER) C12-6073
EOS DIGITAL REBEL XT (BLACK) C12-6074
EOS 350D DIGITAL (SILVER) C12-6075
EOS 350D DIGITAL (BLACK) C12-6076
N.S. x4
CA1-9328
CB3-2410 (Silver)
CB3-1418 (Black)
N.S.
CB3-2286 (Silver)
CB3-2459 (Black)
CG2-1567
XA1-9170-407 x2
N.S.
XA1-9170-457 x2
CG2-1561
N.S.
N.S.
XA1-9170-307 x2
N.S.
N.S.
PARTS LIST Pg. 8
REF.NO. C12-6071, 2, 3, 4, 5, 6
NEW PARTS No. CLASS QTY DESCRIPTION
CA1-9328-000 000 C 1 SPRING, PLATE (BL)
CB3-1418-000 000 C 1 SHOE, ACCESSORY
* CB3-2286-000 000 C 1 COVER, FLASH, S
* CB3-2410-000 000 C 1 SHOE, ACCESSORY, S
* CB3-2459-000 000 C 1 COVER, FLASH
* CG2-1561-000 000 C 1 FPC ASS'Y, MAIN SWITCH
* CG2-1567-000 000 C 1 DIAL ASS'Y, MAIN
XA1-9170-307 000 F 2 SCREW
XA1-9170-407 000 F 2 SCREW
XA1-9170-457 000 F 2 SCREW
9 CANON DIGITAL CAMERA EOS KISS DIGITAL N (SILVER) REF. NO. C12-6071
EOS KISS DIGITAL N (BLACK) C12-6072
EOS DIGITAL REBEL XT (SILVER) C12-6073
EOS DIGITAL REBEL XT (BLACK) C12-6074
EOS 350D DIGITAL (SILVER) C12-6075
EOS 350D DIGITAL (BLACK) C12-6076
N.S. x3 XA4-9170-407 x2
CY3-1490
N.S.
XA4-9170-309
N.S.
CG2-1603
CG2-1634
XA4-9170-307
CG2-1565
XA4-9170-459 x2
CS2-7205
N.S.
CF1-1948
CS2-5020
CB1-4085 x4
CB3-1700
PARTS LIST Pg. 9
REF.NO. C12-6071, 2, 3, 4, 5, 6
NEW PARTS No. CLASS QTY DESCRIPTION
CB1-4085-000 000 F 4 SCREW
CB3-1700-000 000 C 1 MOUNT
CF1-1948-000 000 C 1 LEVER ASS'Y, LENS LOCK
* CG2-1565-000 000 C 1 BASE ASS'Y, CONTACT
* CG2-1603-000 000 A 1 SHUTTER UNIT
* CG2-1634-000 000 B 1 PCB ASS'Y, MOTOR DRIVE
CS2-5020-000 000 E 1 SPRING, COIL
CS2-7205-000 000 D 1 SPRING, MOUNT
* CY3-1490-000 000 B 1 MIRROR BOX ASS'Y
XA4-9170-307 000 F 1 SCREW
XA4-9170-309 000 F 1 SCREW
XA4-9170-407 000 F 2 SCREW
XA4-9170-459 000 F 2 SCREW
10
Accessories
Battery Charger CB-2LT Battery Pack NB-2LH
N.S (Product Available) N.S (Product Available)
DC Coupler DR-700 Compact Power Adapter
CA-PS700
C84-1078
N.S (Product Available)
Interface Cable Video Cable VC-100
IFC-400 PCU(USB)
N.S (Product Available) FH6-3922
Wide Strap EW-100DB II
Pg 10
BATTERY CHARGER CB-5L
REF.NO.C84-1078-000
NEW PARTS NO. CLASS QTY DESCRIPTION
* C84-1078-000 B 1 DC COUPLER DR-700
VIDEO CABLE VC-100
REF.NO.FH6-3922
NEW PARTS NO. CLASS QTY DESCRIPTION
FH6-3922-000 C 1 VIDEO CABLE VC-100
ELECTRIC PARTS LIST
REF.NO.C12-6071,2,3,4,5,6
NEW PARTS NO. CLASS QTY DESCRIPTION
* CH2-8321-000 C 1 WIRE ASS'Y, LEAD MD-MAIN
* CH2-8322-000 C 1 WIRE ASS'Y, LEAD MD-ST
* CH2-8326-000 C 1 WIRE ASS'Y, LEAD MAIN-IF
I N D E X O F PA R T S L I S T Pg. 11
REF.NO. C12-6071, 2, 3, 4, 5, 6
NEW PARTS NO. PAGE NEW PARTS NO. PAGE
* C84-1078-000 10 * CB3-2423-000 7
CA1-9328-000 8 * CB3-2424-000 7
CB1-1902-000 3 * CB3-2449-000 1
CB1-4085-000 9 * CB3-2451-000 6
CB2-0682-000 4 * CB3-2453-000 2
CB3-1086-000 3 * CB3-2454-000 6
* CB3-1339-000 1 * CB3-2455-000 6
CB3-1418-000 8 * CB3-2456-000 6
CB3-1700-000 9 * CB3-2459-000 8
CB3-1815-000 2,3 * CB3-2468-000 1
CB3-2112-000 1,2 * CB3-2478-000 2
CB3-2114-000 2 * CB3-2479-000 2
CB3-2115-000 2 * CB3-2480-000 2
* CB3-2232-000 1 * CB3-2481-000 2
* CB3-2247-000 4 CF1-1948-000 9
* CB3-2263-000 5 * CG2-1545-000 5
* CB3-2286-000 8 * CG2-1550-000 6
* CB3-2316-000 6 * CG2-1552-000 4
* CB3-2317-000 1 * CG2-1558-000 5
* CB3-2318-000 6 * CG2-1559-000 5
* CB3-2319-000 1 * CG2-1561-000 8
* CB3-2320-000 1 * CG2-1563-000 1
* CB3-2321-000 1 * CG2-1564-000 2
* CB3-2322-000 1 * CG2-1565-000 9
* CB3-2323-000 1 * CG2-1566-000 3
* CB3-2324-000 6 * CG2-1567-000 8
* CB3-2325-000 6 * CG2-1571-000 6
* CB3-2326-000 6 * CG2-1576-000 3
* CB3-2329-000 7 * CG2-1597-000 3
* CB3-2331-000 2 * CG2-1603-000 9
* CB3-2332-000 2,3 * CG2-1604-000 3
CB3-2333-000 2 * CG2-1605-000 3
* CB3-2334-000 1,2 * CG2-1606-000 1
* CB3-2335-000 2 * CG2-1607-000 1
* CB3-2337-000 1 * CG2-1608-000 3
* CB3-2341-000 6 * CG2-1609-000 2
* CB3-2342-000 6 * CG2-1610-000 1
* CB3-2343-000 6 * CG2-1634-000 9
* CB3-2348-000 1 * CG2-1636-000 4
* CB3-2351-000 4 * CG2-1639-000 1
* CB3-2357-000 6 * CH1-8319-000 1
* CB3-2358-000 6 * CH2-8321-000 10
* CB3-2392-000 1 * CH2-8322-000 10
* CB3-2404-000 3 * CH2-8326-000 10
* CB3-2410-000 8 * CH2-8339-000 6
I N D E X O F PA R T S L I S T Pg. 12
REF.NO. C12-6071, 2, 3, 4, 5, 6
NEW PARTS NO. PAGE NEW PARTS NO. PAGE
* CH5-2060-000 6
CS2-5020-000 9
CS2-7205-000 9
* CS5-0263-000 7
* CY3-1487-000 2
* CY3-1488-000 4
* CY3-1489-000 4
* CY3-1490-000 9
* CY3-1492-000 2
FH6-3922-000 10
WS1-6518-000 4
XA1-3170-257 5
XA1-3200-307 3
XA1-7170-167 4
XA1-7170-257 4
XA1-7170-307 4
XA1-9170-307 8
XA1-9170-407 8
XA1-9170-457 8
XA4-9170-307 6,9
XA4-9170-309 9
XA4-9170-357 6
XA4-9170-407 5,6,9
XA4-9170-457 3,4,5
XA4-9170-459 9
XA4-9170-607 3
XA4-9200-507 3
XD2-1100-172 7
* YN2-3472-000 1
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
