CHAPTER 4. PARTS CATALOG
CONTENTS
PowerShot A300
Casing Parts ----------------------------------------------------------------------------------------------------------------------- Pg1
Internal Parts-1 ------------------------------------------------------------------------------------------------------------------- Pg2
Internal Parts-2 ------------------------------------------------------------------------------------------------------------------- Pg3
Accessories-1 ------------------------------------------------------------------------------------------------------------------------- Pg4
Accessories-2 ------------------------------------------------------------------------------------------------------------------------- Pg5
Service Tools-1 ----------------------------------------------------------------------------------------------------------------------- Pg6
Service Tools-2 ----------------------------------------------------------------------------------------------------------------------- Pg7
Category of CLASS
A: Frequency of use: High
B: Frequency of use: Middle
C: Frequency of use: Low
D: Safety-related critical parts
E: Consumable parts
F: Standard screws and washers
S: Supply of the parts is limited
Y: Service Tools
PowerShot A300
Pg1
Casing Parts
7
6
15
8
9
5
15
4
N.S
14
10
11
14
2
3
1
14
12
13
PowerShot A300
Pg1
PARTS LIST
SYMBOL PARTS NO. CLASS QTY DESCRIPTION REMARKS
1 CY1-6281-000 B 1 FRONT COVER UNIT
2 CD3-0406-000 B 1 COVER, CONNECTOR
3 CY1-6285-000 B 1 PLATE, BODY NUMBER (J) #13161xxxxx
CY1-6286-000 B 1 PLATE, BODY NUMBER (N) #13261xxxxx
CY1-6287-000 B 1 PLATE, BODY NUMBER (E) #13361xxxxx
CY1-6288-000 B 1 PLATE, BODY NUMBER (CH) #13661xxxxx
4 CD3-0417-000 B 1 COVER, CF
5 CD3-0413-000 C 1 PLATE, BATTERY CONTACT
6 CD3-0412-000 B 1 COVER, BATTERY
7 CD3-0410-000 B 1 COVER, SIDE
8 CY1-6282-000 B 1 REAR COVER UNIT
9 CD3-0445-000 B 1 HOLDER, LITHIUM BATTERY
10 CK9-1006-000 C 1 PANEL, LCD
CK9-1006-001 C 1 PANEL, LCD (SELECTION)
11 CD3-0776-000 C 1 SHEET, LIGHT SHIELDING
12 CM1-2006-000 C 1 BACK LIGHT UNIT
13 XA4-9170-407 F 4 SCREW
14 CD3-0443-000 C 4 SCREW
15 XA4-9170-607 F 4 SCREW
PowerShot A300
Pg2
Internal Parts-1
21
12
11
22 13
10
14
9
15
8
16
6 RED
BLACK
5
4 BLACK
18
7 17
RED
3
2
1
20
19 21
PowerShot A300
Pg2
PARTS LIST
SYMBOL PARTS NO. CLASS QTY DESCRIPTION REMARKS
1 CD3-0449-000 C 1 PLATE, GND
2 CK2-2002-000 C 1 FPC, M-S
3 CM1-2002-000 C 1 FLASH UNIT
4 CK2-2010-000 C 1 LEAD, BATTERY (+)
5 CD3-0451-000 C 1 CONTACT, BATTERY (+)
6 CD3-0770-000 C 1 GUARD, BATTERY CONTACT (+)
7 CK2-2011-000 C 1 LEAD, BATTERY (-)
8 CD3-0452-000 C 1 CONTACT, BATTERY (-)
9 CD3-0414-000 C 1 SPRING, BATTERY COVER
10 CM1-2004-000 C 1 PCB ASS'Y, RLS
11 CD3-0420-000 C 1 CASE, MAIN SHIELD 3
12 CD3-0419-000 C 1 CASE, MAIN SHIELD 2
13 CM1-2001-000 C 1 PCB ASS'Y, MAIN
14 CD3-0418-000 C 1 CASE, MAIN SHIELD 1
15 CD3-0441-000 C 1 BUSH, MICROPHONE
16 WR1-5089-000 C 1 MICROPHONE
17 CK2-2016-000 C 1 LEAD, MICROPHONE (+)
18 CK2-2017-000 C 1 LEAD, MICROPHONE (-)
19 CK9-0415-000 C 1 FUSE, SKK UMF2012 I14
20 CK9-0416-000 C 1 FUSE, SKK UMF2012 I18
21 XA4-9170-407 F 5 SCREW
22 XA4-9140-257 F 1 SCREW
PowerShot A300
Pg3
Internal Parts-2
14
10
9
8
14
11
7
14
6
12
ORANGE
GRAY
5
2 13
3
1
4
14
PowerShot A300
Pg3
PARTS LIST
SYMBOL PARTS NO. CLASS QTY DESCRIPTION REMARKS
1 CY1-6284-000 C 1 CCD UNIT
2 CD1-4906-000 C 1 RUBBER, CCD
3 YN1-2123-000 C 1 FILTER, IR
4 CY1-6283-000 B 1 OPTICAL UNIT
5 CK2-2009-000 C 1 LEAD, CAPACITOR (-)
6 CK2-2008-000 C 1 LEAD, CAPACITOR (+)
7 CK9-1009-000 C 1 CAPACITOR, ELECT., 80MF/330V
8 CD3-0402-000 C 1 FRAME, MAIN
9 CD3-0415-000 B 1 LOCKER, BATTERY
10 CD3-0416-000 C 1 PLATE, BATTERY LOCK
11 CD3-0453-000 C 1 CONTACT, LITHIUM (+)
12 CD3-0454-000 C 1 CONTACT, LITHIUM (-)
13 XA4-9140-307 F 3 SCREW
14 XA4-9170-407 F 6 SCREW
PowerShot A300
Pg4
A c c e s s o r i e s -1
Wrist Strap WS-200 USB Interface Cable CF Card FC-16M
IFC-300PCU
1
N.S
N.S
Canon Digital Camera AC Cable Alkaline Batteries (X2)
Solution Disk
2 3
N.S
CF CASE
4
N.Sl : N.S Stand for No Stock (Product available)
PowerShot A300
Pg4
PARTS LIST
SYMBOL PARTS NO. CLASS QTY DESCRIPTION REMARKS
1 C84-1060-000 B 1 WRIST STRAP WS-200
2 C84-1174-000 S 1 CD-ROM, SOLUTION DISK VER.12.0 (J/E) FOR JAPAN, ASIA,
AUSTRALIA
C84-1176-000 S 1 CD-ROM, SOLUTION DISK VER.12.0 (E/F/S) FOR USA, CANADA
C84-1178-000 S 1 CD-ROM, SOLUTION DISK VER.12.0 (J/E/SC) FOR JAPAN, ASIA,
AUSTRALIA
3 WT3-5062-000 C 1 AC CABLE (J) FOR JAPAN
WT3-5063-000 C 1 AC CABLE (N) FOR USA, CANADA
WT3-5064-000 C 1 AC CABLE (E) FOR EUROPE, ASIA
WT3-5115-000 C 1 AC CABLE (B) FOR USA
WT3-5066-000 C 1 AC CABLE (A) FOR AUSTRALIA
4 FC2-9610-000 B 1 CASE, CF
PowerShot A300
Pg5
A c c e s s o r i e s -2
Camera User Guide
1
Software Starter Guide
2
System Map
3
Quick Start Guide
4
PowerShot A300
Pg5
PARTS LIST
SYMBOL PARTS NO. CLASS QTY DESCRIPTION REMARKS
1 CDI-E078-000 S 1 I.BOOK (ENGLISH) FOR USA, CANADA,
ASIA, AUSTRALIA
CDI-S068-000 S 1 I.BOOK (SPANISH) FOR USA
CDI-J069-000 S 1 I.BOOK (JAPANESE) FOR JAPAN
CDI-F067-000 S 1 I.BOOK (FRENCH) FOR CANADA
2 CDI-E088-000 S 1 SOFTWARE GUIDE (ENGLISH) (FOR VER.12.0) FOR USA, CANADA,
ASIA, AUSTRALIA
CDI-S077-000 S 1 SOFTWARE GUIDE (SPANISH) (FOR VER.12.0) FOR USA
CDI-J079-000 S 1 SOFTWARE GUIDE (JAPANESE) (FOR VER.12.0) FOR JAPAN
CDI-F077-000 S 1 SOFTWARE GUIDE (FRENCH) (FOR VER.12.0) FOR CANADA
3 CDI-E079-000 S 1 SYSTEM MAP (ENGLISH) FOR USA, CANADA,
ASIA, AUSTRALIA
CDI-S069-000 S 1 SYSTEM MAP (SPANISH) FOR USA
CDI-J070-000 S 1 SYSTEM MAP (JAPANESE) FOR JAPAN
CDI-F068-000 S 1 SYSTEM MAP (FRENCH) FOR CANADA
4 CDI-E080-000 S 1 QUICK START GUIDE (ENGLISH) FOR USA, CANADA,
ASIA, AUSTRALIA
CDI-S070-000 S 1 QUICK START GUIDE (SPANISH) FOR USA
CDI-J071-000 S 1 QUICK START GUIDE (JAPANESE) FOR JAPAN
CDI-F069-000 S 1 QUICK START GUIDE (FRENCH) FOR CANADA
