Image preview - the first page of the document
>> Download CANON_POWERSHOT_S60 documenatation <<
Text preview - extract from the document
PARTS CATALOG
c CANON INC., 2004
CONTENTS
PowerShot S70
PowerShot S60
Casing Parts ----------------------------------------------------------------------------------------------------------------------- Pg1
Internal Parts-1 ------------------------------------------------------------------------------------------------------------------- Pg2
Internal Parts-2 ------------------------------------------------------------------------------------------------------------------- Pg3
Fuse -------------------------------------------------------------------------------------------------------------------------------- Pg4
Accessories-1 ------------------------------------------------------------------------------------------------------------------------- Pg5
Accessories-2 ------------------------------------------------------------------------------------------------------------------------- Pg6
Accessories-3 ------------------------------------------------------------------------------------------------------------------------- Pg7
Service Tools-1 ----------------------------------------------------------------------------------------------------------------------- Pg8
Service Tools-2 ----------------------------------------------------------------------------------------------------------------------- Pg9
Category of CLASS
A: Frequency of use: High
B: Frequency of use: Middle
C: Frequency of use: Low
D: Safety-related critical parts
E: Consumable parts
F: Standard screws and washers
S: Supply of the parts is limited
Y: Service Tools
PowerShot S70
PowerShot S60
Pg1
Casing Parts
8
105 10
9
104
101
11
17
18
7
102 12
13 101
6
103
101
14
5
4 101
1
16
15
3
101 2
PowerShot S70
PowerShot S60
Pg1
PARTS LIST
SYMBOL PARTS NO. CLASS QTY DESCRIPTION REMARKS
1 CD3-2417-000 C 1 SPRING, LID
2 CM1-2672-000 B 1 LID UNIT, BOTTOM PowerShot S70
CM1-2404-000 B 1 LID UNIT, BOTTOM PowerShot S60
3 CM1-2675-000 B 1 COVER UNIT, FRONT PowerShot S70
CM1-2408-000 B 1 COVER UNIT, FRONT PowerShot S60
4 CD3-2416-000 C 1 SHAFT, LID
5 CD3-2122-000 C 1 SPACER, FINDER
6 CD3-3162-000 B 1 LID, COUPLER PowerShot S70
CD3-2401-000 B 1 LID, COUPLER PowerShot S60
7 CD3-2402-000 C 1 SPRING, COUPLER LID
8 CM1-2674-000 B 1 COVER UNIT, TOP PowerShot S70
CM1-2407-000 B 1 COVER UNIT, TOP PowerShot S60
9 CD3-2424-000 C 1 SPACER, LCD
10 CD3-3152-000 B 1 WINDOW, LCD PowerShot S70
CD3-2379-000 B 1 WINDOW, LCD PowerShot S60
11 CM1-2676-000 B 1 COVER UNIT, REAR PowerShot S70
CM1-2409-000 B 1 COVER UNIT, REAR PowerShot S60
12 CD3-2380-000 C 1 WINDOW, POWER LED
13 CM1-2671-000 B 1 CROSS KEY UNIT PowerShot S70
CM1-2399-000 B 1 CROSS KEY UNIT PowerShot S60
14 CY1-6361-000 B 1 PLATE, BODY NUMBER PowerShot S70
CY1-6336-000 B 1 PLATE, BODY NUMBER PowerShot S60
15 CD3-2949-000 B 1 COVER, JACK PowerShot S70
CD3-2349-000 B 1 COVER, JACK PowerShot S60
16 CD3-2948-000 B 1 BASE, JACK PowerShot S70
CD3-2348-000 B 1 BASE, JACK PowerShot S60
17 CD3-3359-000 C 1 SHEET, BUTTON
18 CD3-3646-000 C 1 SHEET, TOP
101 CD3-3167-000 C 7 SCREW PowerShot S70
CD3-2563-000 C 7 SCREW PowerShot S60
102 CD3-2564-000 C 1 SCREW
103 CD3-3169-000 C 2 SCREW PowerShot S70
CD3-2565-000 C 2 SCREW PowerShot S60
104 CD3-3170-000 C 2 SCREW PowerShot S70
CD3-2737-000 C 2 SCREW PowerShot S60
105 XA1-7170-257 F 1 SCREW
PowerShot S70
PowerShot S60
Pg2
Internal Parts-1
104
109
6
N.S
7
N.S
12
8
11
104
103
2 105
108 2
4
5
107 13
108
10
101
9
3
2 16
15 14
102
101
104
2
1
101
106
N.Sl : N.S Stand for No Stock
PowerShot S70
PowerShot S60
Pg2
PARTS LIST
SYMBOL PARTS NO. CLASS QTY DESCRIPTION REMARKS
1 CM1-2403-000 C 1 TRIPOD BASE UNIT
2 CD3-2933-000 C 4 TAPE, 18 X 9 PVF FILM
3 CD3-2559-000 C 1 TAPE, 22 X 3 DOUBLE-SIDE Discontinued soon
4 WK1-5140-000 C 1 BATTERY, LITHIUM-ION
5 CM1-2424-000 C 1 OPERATE ASS'Y
6 CM1-2677-000 C 1 OPERATE UNIT PowerShot S70
CM1-2410-000 C 1 OPERATE UNIT PowerShot S60
7 FC2-8744-000 C 1 SPRING, MODE DIAL CLICK
8 CL1-1060-000 C 1 BUSH UNIT
9 CK2-2159-000 C 1 WIRE, OPERATE - DC/DC
10 CM1-2520-000 C 1 FINDER UNIT
11 CD3-2374-000 C 1 PLATE, REAR
12 CM1-2426-000 C 1 REAR ASS'Y, 1
13 WG2-5267-000 C 1 PANEL, LCD
WG2-5267-001 C 1 PANEL, LCD (SELECTION)
14 CD3-2444-000 C 1 CUSHION, BACK LIGHT
15 CM1-2400-000 C 1 BACK LIGHT UNIT
16 CD3-3174-000 C 1 SHEET, LCD PowerShot S70
101 CD1-3108-000 C 5 SCREW
102 CD3-2456-000 C 1 SCREW NKGRIP
103 CD3-2936-000 C 1 SCREW NKGRIP
104 XA1-7170-257 F 3 SCREW
105 XA4-5170-307 C 1 SCREW
106 XA4-5170-357 F 2 SCREW
107 XA4-9140-407 F 3 SCREW
108 XA4-9170-307 F 2 SCREW
109 XA4-9170-357 F 1 SCREW
PowerShot S70
PowerShot S60
Pg3
Internal Parts-2
11
102 105
10 13
103
9
12
105 105
8
5
14
6
15
106
105
7
4 105
3 18
19
101 17
16 2
104
1
104
PowerShot S70
PowerShot S60
Pg3
PARTS LIST
SYMBOL PARTS NO. CLASS QTY DESCRIPTION REMARKS
1 CM1-2705-000 C 1 OPTICAL UNIT PowerShot S70
CM1-2521-000 C 1 OPTICAL UNIT PowerShot S60
2 CD3-2086-000 C 1 SPRING, CCD
3 CD3-2405-000 C 1 HOLDER, SWITCH
4 CM1-2406-000 C 1 BATTERY BOX UNIT
5 CD3-2406-000 C 1 SPRING, EJECT
6 CK2-2158-000 C 1 WIRE, LID SWITCH
7 CM1-2427-000 C 1 SWITCH ASS'Y
8 CD3-2395-000 C 1 FRAME, MAIN
9 CM1-2402-000 C 1 FLASH UNIT
10 CD3-2558-000 C 1 TAPE, 16 X 7 DOUBLE-SIDE
11 CM1-2425-000 C 1 REAR ASS'Y, 2
12 CD3-2935-000 C 1 TAPE, 21 X 9.6 BUSTERAID K4E
13 CM1-2578-000 C 1 PCB ASS'Y, MAIN PowerShot S70
CM1-2422-000 C 1 PCB ASS'Y, MAIN PowerShot S60
14 WS3-5920-000 C 1 EJECTOR, CARD
15 CD3-2559-000 C 1 TAPE, 22 X 3 DOUBLE-SIDE
16 CM1-2429-000 C 1 PCB ASS'Y, DC/DC
17 CM1-2423-000 C 1 PCB ASS'Y, JAL
18 CD3-1650-000 C 1 LENS, CONTROLLER
19 CM1-2406-010 C 1 BATTERY BOX UNIT
101 CB3-0228-000 C 1 SCREW
102 CD1-3108-000 C 1 SCREW
103 CD3-2936-000 C 1 SCREW NKGRIP
104 XA1-7170-257 F 3 SCREW
105 XA4-5170-357 F 8 SCREW
106 XA4-9170-357 F 1 SCREW
PowerShot S70
PowerShot S60
Pg4
Fuse
1 2
2
DC/DC PCB ASS'Y
OPERATE ASS'Y
PowerShot S70
PowerShot S60
Pg4
PARTS LIST
SYMBOL PARTS NO. CLASS QTY DESCRIPTION REMARKS
1 VD7-2242-501 D 1 FUSE, LITTEL 049402.5 F2
2 VD7-2242-001 D 2 FUSE, LITTEL 0494002. FU100, FU1
PowerShot S70
PowerShot S60
Pg5
Accessories-1
Wrist Strap WS-300 USB Interface Cable
1
IFC-400PCU
N.S
CF CASE AV Cable AVC-DC300
2
N.S
CF Card FC-32MH Canon Digital Camera
Solution Disk,
ArcSoft camera Suite Disk
N.S
N.S
ArcSoft camera
Suite Disk
N.S
Battery Charger Battery Pack NB-2LH
CB-2LT / CB-2LTE
N.S
3
N.S
N.Sl : N.S Stand for No Stock
PowerShot S70
PowerShot S60
Pg5
PARTS LIST
SYMBOL PARTS NO. CLASS QTY DESCRIPTION REMARKS
1 C84-1082-000 B 1 STRAP, WRIST WS-300
2 FC2-9610-000 B 1 CASE, CF
3 CD1-4054-010 B 1 COVER, TERMINAL NB-2L
PowerShot S70
PowerShot S60
Pg6
Accessories-2
Compact Power Adapter Tele Converter TC-DC10
CA-PS700
7
N.S
N.S
8
AC Cable Conversion Lens Adapter LA-DC10
N.S
1
2
3
PLUG TYPE 4
5
Wireless Controller WL-DC100 Car Battery Charger CBC-NB2
6
N.S
N.S
N.S
DC Coupler
DR-700
9
N.Sl : N.S Stand for No Stock
PowerShot S70
PowerShot S60
Pg6
PARTS LIST
SYMBOL PARTS NO. CLASS QTY DESCRIPTION REMARKS
1 D82-0641-000 C 1 CABLE, AC, JAPAN FOR JAPAN
2 WT3-5063-000 C 1 CABLE, AC, USA FOR USA, CANADA
3 D82-0643-000 C 1 CABLE, AC, EUROPE FOR EUROPE, ASIA
4 D82-0644-000 C 1 CABLE, AC, UK FOR ASIA
5 D82-0645-001 C 1 CABLE, AC, AUSTRALIA FOR AUSTRALIA
6 CY1-6074-000 B 1 HOLDER, BATTERY
7 CD3-3016-000 B 1 CAP, FRONT
8 CD3-3017-000 B 1 CAP, REAR
9 C84-1078-000 B 1 DC COUPLER DR-700
PowerShot S70
PowerShot S60
Pg7
Accessories-3
Waterproof Case WP-DC 40 N.S N.S 10 8 9
4 N.S N.S
2 5 3
1 6
4
3
10 3
4
4 7
4 10
N.S
N.S
9
N.S 5
N.S
5 5
N.S N.S
5 6 4
6
5 N.S
N.S
10
N.S 5
Waterproof Seal Wrist Strap
11 15
Silicone Grease
12
Diffusion Plate Unit
16
Neck Strap
13
Hood 17
14
Strap
N.Sl : N.S Stand for No Stock
PowerShot S70
PowerShot S60
Pg7
PARTS LIST
SYMBOL PARTS NO. CLASS QTY DESCRIPTION REMARKS
1 CY1-6349-000 C 1 BUCKLE ASS'Y
2 CD1-5042-000 C 1 SHAFT, BUCKLE
3 CD1-5038-000 C 10 SPRING, COIL
4 CD1-5041-000 C 16 O RING(P-3)
5 CD1-5039-000 C 16 E RING
6 CY1-6350-000 C 8 CAP, BUTTON
7 CY1-6354-000 C 1 HOLDER, DEFUSION PLATE
8 CY1-6355-000 C 1 PROTECTOR, DEFUSION PLATE
9 CD1-5047-000 C 8 SCREW
10 CY6-3252-000 C 7 SCREW
11 CY1-6351-000 B 1 PACKING, RUBBER
12 DY9-3029-000 C 1 GREASE PACKING
13 CY1-6099-000 B 1 STRAP, NECK
14 CY1-6329-000 B 2 STRAP
15 CY1-6174-000 B 1 STRAP, WRIST
16 CY1-6352-000 B 1 PLATE, DIFFUSION
17 CY1-6353-000 B 1 HOOD
PowerShot S70
PowerShot S60
Pg8
Service Tools-1
DIA Bond NO.1663G Black Service Manual CD-ROM
4
1
Adhesive Tape SONY T4000 LEAD FREE SOLDER RMA-98
2 5
Logenest Rambda A-74
3
PowerShot S70
PowerShot S60
Pg8
PARTS LIST
SYMBOL PARTS NO. CLASS QTY DESCRIPTION REMARKS
1 CY9-8129-000 Y 1 BOND, DIA BOND NO.1663G BLACK 200mml
2 CY4-6012-000 Y 1 ADHESIVE TAPE, SONY T4000 6mm x 50m roll
3 CY9-8102-000 Y 1 LUBE, LOGNEST RAMBDA A-74 80g
4 CY8-4394-031 Y 1 CD-ROM, SERVICE MANUAL (J/E)
5 CY9-4045-000 Y 1 SOLDER, LEAD FREE RMA-98
PowerShot S70
PowerShot S60
Pg9
Service Tools-2
