Image preview - the first page of the document
>> Download candy_cdni4075a documenatation <<
Text preview - extract from the document
REFRIGERATORS
34001140 CDNI4075A
Service Manual
34001140 CDNI4075A 0827 (02/07/2008)
Ricambio Inizio Fine
Part No. Beginning Ending
Piece Debut Fin
Ref. Descrizione - Description - Beschreibung - Descripcion E-Teil Begin End
Pieza Inicio Fin
1 Compressor 41026387
1c Run capacitor 91200995
8a Adjustable levelling foot 92690593
18h Magnet (Inner Light) 41028395
22 Control panel frame 41028904
28 Condenser 41024572 0849 (01/12/2008)
28 Condenser 41027452 0849 (01/12/2008)
30 Clip-clamp 92663442
42b Compressor fixing plate 92854157
44b Drip evap.tray ZEM 41009011
49n Refrigerator door compl.(Tall end cap) 41028762
50 Freezer door complete 41028822
51 Door handle 41028565 1012 (15/03/2010)
51 Door handle 41028535 1012 (15/03/2010)
51c Plug for handle holes 41028536
51z Spring screw 92409028
58 Eggs holder 41000277
58g Bottle support 41021534
59 Lower bottles shelf 41022185 0915 (07/04/2009)
59 Lower bottles shelf 41021076 0915 (07/04/2009)
81 Refrigerator gasket 41028370
82 Freezer gasket 41024556
93 Jars door rail 41022184 0915 (07/04/2009)
93 Jars door rail 91602620 0915 (07/04/2009)
109 Upper hinge (R/H) 41009508
109a Upper hinge (L/H) 41010020
111 Door sleeve for hinge 92957018
111c Door safety holder (R/H) 41005685
111d Door safety holder (L/H) 41005690
111e Upper door sleeve for hinge 41010607
112c Middle hinge 91750659
113d Lower hinge 41025108
115 Spacer 92434190
Copyright 2011 Gias S.r.L.
34001140 CDNI4075A 0827 (02/07/2008)
Ricambio Inizio Fine
Part No. Beginning Ending
Piece Debut Fin
Ref. Descrizione - Description - Beschreibung - Descripcion E-Teil Begin End
Pieza Inicio Fin
124b 3 ways Dryer Filter 41012883
125a Insulating foam tube 92607720
127b Freezer evaporator 41027682
128 Defrostin.heating element 41027842
128b Drain hose heating strip 92894609
149 Crisper 41020553
149n Crisper handle/Front piece 41020554
149p Crisper wheel support 41020557
151 Crisper glass shelf 41021312
151a Crisper glass shelf trim 41021168
151q Crisper glass shelf trim air grate 41021167
153b Glass shelf with frame 41020852
160b Middle/upper basket 41022315
161o Large lower basket 41024967
161p Roller basket 41014144
162 Basket front piece 41022228
162a Lower bask. front piece 41024968
192a LCD Thermometer 41006776
201a Hinge hole plug 92957000
201c Plug 92957026
251 Evaporator cover panel 41008782
251c Evapora.cover-Upper panel 41025622
251e Cover gasket (Evaporator/fan support) 41030211
251o Evaporator cover panel trim 41022530
251p Evaporator cover panel (Refrigerator) 41028246
252 Fan motor 41026584
253b Refrigerator Fan Buffer 41023704
255 Rear stirrup 92941731
257 Fan 92633213
258a Self sticking gasket 92959170
258b Self sticking gasket 10x15 92058171
Copyright 2011 Gias S.r.L.
34001140 CDNI4075A 0827 (02/07/2008)
Ricambio Inizio Fine
Part No. Beginning Ending
Piece Debut Fin
Ref. Descrizione - Description - Beschreibung - Descripcion E-Teil Begin End
Pieza Inicio Fin
270b Defrost sensor and thermal fuse assy 41004399
284 Dashboard 41028634
284a Stopper for screw hole 41026619
288b Dashboard plate 41025548
330 Ice cubes tray 92952449
360 Compressor cross piece 92871789
369 Damper box assy 41025665
412 Refriger.insulating piece 41026960
422 Dashboard circuit plate 41026689
422z Led circuit plate 41026971
423a Control board barrier 41026961
428f Probe for temper.reading (refrigerator) 41027455
428g Probe for temper.reading (freezer) 41027456
999 Wiring diagram 91101070
Copyright 2011 Gias S.r.L.
34001140 CDNI4075A 0827 (02/07/2008) - Modifications History -
Ricambio Inizio Fine
Part No. Beginning Ending
Piece Debut Fin
Ref. Descrizione - Description - Beschreibung - Descripcion E-Teil Begin End
Pieza Inicio Fin
Condenser
28 Condenser 41024572 0849 (01/12/2008)
28 Condenser 41027452 0849 (01/12/2008)
Door rail
93 Jars door rail 41022184 0915 (07/04/2009)
59 Lower bottles shelf 41022185 0915 (07/04/2009)
93 Jars door rail 91602620 0915 (07/04/2009)
59 Lower bottles shelf 41021076 0915 (07/04/2009)
Door handle
51 Door handle 41028565 1012 (15/03/2010)
51 Door handle 41028535 1012 (15/03/2010)
Copyright 2011 Gias S.r.L.
