Image preview - the first page of the document



>> Download Compaq Presario 1200 Series documenatation <<

Text preview - extract from the document

                                          Presario 1200 Series
                             Models: XL101-XL113, XL115, XL118-XL127


Removal Sequence
This section explains the removal and replacement procedures for the 1200XL unit.

Serial Number Location
Report the unit's serial number 1 to Compaq when requesting information or ordering
spare parts. The serial number is located underneath the notebook as shown below.




PRESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE 1200XL SERIES             REMOVAL SEQUENCE 1
                                      Presario 1200 Series
                           Models: XL101-XL113, XL115, XL118-XL127


Electrostatic Discharge
A sudden discharge of static electricity from a finger or other conductor can destroy static-
sensitive devices or microcircuitry. Often the spark is neither felt nor heard, but damage
occurs. An electronic device exposed to electrostatic discharge (ESD) may not seem to be
affected at all and works perfectly throughout a normal cycle. Although it may function
normally for a while, it may be degraded in the internal layers, reducing its life expectancy.
Networks built into many integrated circuits provide some protection, but in many cases,
the discharge contains enough power to alter device parameters or melt silicon junctions.

Generating Static
The table below shows activities that generate static electricity and the associated
electrostatic voltage level.

                                   Typical Electrostatic Voltages
                                                               Relative Humidity
                 Event
                                                          10%          40%           55%
                 Walking across carpet                 35,000 V      15,000 V       7,500 V
                 Walking across vinyl floor            12,000 V       5,000 V       3,000 V
                 Motions of bench worker                 6,000 V         800 V        400 V
                 Removing DIPS from plastic tubes        2,000 V         700 V        400 V
                 Removing DIPS from vinyl trays        11,500 V       4,000 V       2,000 V
                 Removing DIPS from styrofoam          14,500 V       5,000 V       3,500 V
                 Removing bubble pack from PCBs        26,000 V      20,000 V       7,000 V
                 Packing PCBs in foam-lined box     21,000 V         11,000 V       5,000 V
                 Note: 700 Volts can degrade a product.




2 REMOVAL SEQUENCE                                PRESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE 1200XL SERIES
                                          Presario 1200 Series
                             Models: XL101-XL113, XL115, XL118-XL127


Service Considerations
Listed below are some of the considerations to consider during the disassembly and
assembly of the Notebook.

Tool and Software Requirements
The following items are required to service the computer:
