Image preview - the first page of the document
>> Download casio-tv-600cdin documenatation <<Text preview - extract from the document (with price)
POCKET TELEVISION
TV-600C
TV-600D
TV-600I
TV-600N
DECEMBER 1994
Page
Specifications............................................................................................. 1
Block Diagram ........................................................................................... 2
Circuit Description...................................................................................... 3
Adjustment
Linear PCB.......................................................................................... 5
A/D PCB .............................................................................................. 9
Troubleshooting ....................................................................................... 10
Printed Circuit Boards .............................................................................. 11
Wiring Diagram ........................................................................................ 15
Exploded View / Disassembly.................................................................. 16
Electrical Parts List .................................................................................. 17
Mechanical Parts List............................................................................... 23
IC and Transistor Lead Identification ....................................................... 24
Schematic Diagrams and Waveforms ..................................................... 26
INDEX R
SPECIFICATIONS
Item Specification
1. Reception channels VHF : 2 ~ 13 ch UHF : 14 ~ 69 ch
2. Power voltage DC 6.0 V
3. Power consumption Approx. 3.4 W
4. Current consumption Approx. 566 mA
5. Battery life (with alkaline batteries) Approx 3.0 hours
Batteries : 4 AA size batteries
6. Power supply Car adaptor : CA-K65
AC adaptor : ADK-65, 64
Earphone jack : 3.5
