Image preview - the first page of the document



>> Download hfe_denon_adv-1000_service_en documenatation <<

Text preview - extract from the document

                                                                             For Europe model


                                                                             Hi-Fi Component



                      SERVICE MANUAL
      MODEL                      ADV-1000
                    DVD SURROUND RECEIVER




Some illustrations using in this service manual are slightly different from the actual set.




               16-11, YUSHIMA 3-CHOME, BUNKYOU-KU, TOKYO 113-0034 JAPAN
                                 Telephone: 03 (3837) 5321

                                                                                         X0146 NC 0207
                                                                                                                                                ADV-1000




      SAFETY PRECAUTIONS
      The following check should be performed for the continued protection of the customer and service technician.

      LEAKAGE CURRENT CHECK
      Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to
      chassis resistance check. If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either
      side of the power cord is less than 460 kohms, the unit is defective.



SPECIFICATIONS
 Audio section
