Image preview - the first page of the document



>> Download hfe_denon_avr-4802_avc-a11sr_service_en documenatation <<

Text preview - extract from the document

                                                             For U.S.A., Canada, Europe,
                                                             Asia, China, Hong Kong,
                                                             Korea & Taiwan R.O.C. model
                                                                             Hi-Fi Component




                     SERVICE MANUAL
   MODEL                       AVR-4802
   MODEL                       AVC-A11SR
         AV SURROUND RECEIVER / AMPLIFIER




                                                                     For AVR-4802   For AVC-A11SR




Some illustrations using in this service manual are slightly different from the actual set.




                14-14, AKASAKA 4-CHOME, MINATO-KU, TOKYO 107-8011 JAPAN
                                  Telephone: 03 (3584) 8111


                                                                                     X0120 1174 NC 0108
                                                                                                                        AVR-4802/AVC-A11SR




    SAFETY PRECAUTIONS
    The following check should be performed for the continued protection of the customer and service technician.

    LEAKAGE CURRENT CHECK
    Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to chassis
    resistance check. If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the
    power cord is less than 460 kohms, the unit is defective.



SPECIFICATIONS
Audio Section
       Power amplifier:
        Rated output:                                                Stereo (2 ch driven)
        (All properties shown are only for the                         125 W + 125 W (8 /ohms, 20 Hz ~ 20 kHz with 0.05 % T.H.D.)
        power amplifer stage.)                                         150 W + 150 W (6 /ohms, 20 Hz ~ 20 kHz with 0.05 % T.H.D.)
        Dynamic power:                                               170 W
