Image preview - the first page of the document
>> Download vvx380 documenatation <<
Text preview - extract from the document
0128711501
DE'LONGHI "INT" VVX380 (G)
BIANCO - WHITE
58
13
14
12
11
08 09 56
10 54
07 55
06 57
05
03 15 26
04
24
30
02 27
52
51
50
01 41
32 48
33 47
40 46
36 45
37 12
19
38
43 44
49
42
39
DE'LONGHI INT VVX380 0128711501
Pos. Spare part code Description
01 7328148700 IRON
02 5328132700 CONNECTION L
03 5928126600 BODY
04 5328503500 TUBE
05 5328132600 CONNECTION
06 5328134200 SUPPORT
07 5328133200 STOP
08 5528108200 KNOB
09 5128105900 MICROSWITCH
10 5328134000 LEVER
11 5328148500 COVER
12 5528104000 CABLE
13 5328133700 CABLE GROMMET
14 5928126300 COVER
15 5928130100 COVER
19 5312810001 CONNECTION
24 5928128700 TEMPLATE
26 5128105400 LAMP
27 5328142400 KNOB
30 5128107300 SWITCH
32 9811861646 SCREW
33 9816100626 NUT
36 SC5654800 PISTON
37 SC5654780 TAP
38 6128101700 SPRING
39 5028101900 POWER SUPPLY CORD
40 5228105200 SOLENOID VALVE
41 5328163000 GASKET
- Pag. 1/2 -
DE'LONGHI INT VVX380 0128711501
Pos. Spare part code Description
42 5328128900 BODY LOWER
43 5328135600 STOPPER
44 SC5174020 TUBE
45 6828100400 BOILER LOWER
46 5228105100 THERMOSTAT 180◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
