0191720511
DE LONGHI "INT/RU" XTL 212 PET
69
DE'LONGHI INT/RU XTL 212 PET 0191720511
Pos. Spare part code Description
01 CJ1220 COVER
02 CJ1248 PROTECTION Upper
03 CJ1227 GRID
04 CJ1166 HOOK
05 CJ1167 SPRING
06 CJ1228 CONTROL BOARD
07 CJ1169 COVER
08 CJ1170 SWITCH
09 CJ1171 SWITCH
10 5519110021 FILTER HEPA
11 CJ1173 GASKET
12 CJ1174 INSULATOR
13 CJ1175 INSULATOR
14 CJ1176 INSULATOR
15 CJ1177 INSULATOR
16 CJ1178 DUCT
17 CJ1179 CLOSURE
18 CJ1181 RUBBER PAD
19 CJ1184 MOTOR
20 CJ1185 GASKET
21 CJ1186 GASKET
22 CJ1180 RUBBER PAD
23 CJ1182 CABLE WINDER
24 CJ1183 SUPPORT
25 CJ1190 CABLE WINDER
27 CJ1187 ASS. CASTOR
29 CJ1195 FILTER
30 CJ1196 GRID
- Pag. 1/3 -
DE'LONGHI INT/RU XTL 212 PET 0191720511
Pos. Spare part code Description
31 CJ1192 GASKET
32 CJ1193 CASTOR
33 CJ1191 BODY LOWER
34 CJ1194 CLOSURE
35 CJ1197 CLOSURE
36 CJ1199 GASKET
37 CJ1200 GASKET
38 CJ1201 CLOSURE
39 CJ1203 HOOK
40 CJ1204 SPRING
41 CJ1202 SUPPORT
42 CJ1205 RING
43 CJ1206 GASKET
44 CJ1207 GASKET
45 CJ1208 HOOK
46 CJ1209 SPRING
47 CJ1198 HOOK
48 CJ1210 CLOSURE
49 CJ1223 FRONT PANEL
50 CJ1247 LENS
51 CJ1217 SPRING
52 CJ1212 SUPPORT
53 CJ1213 PUSH BUTTON
54 CJ1224 SPRING
55 CJ1225 PUSH BUTTON
56 CJ1253 PUSH BUTTON ARG.
57 CJ1254 PUSH BUTTON ARG.
58 CJ1212 SUPPORT
- Pag. 2/3 -
DE'LONGHI INT/RU XTL 212 PET 0191720511
Pos. Spare part code Description
59 CJ1229 FILTER
60 CJ1230 HOOK
61 CJ1238 HANDLE
62 CJ1232 FLEXIBLE TUBE
63 CJ1094 SUPPORT
64 CJ1233 VENT
65 CJ1234 BRUSH
66 CJ1235 VENT
67 CJ1236 BRUSH
68 CJ1237 TUBE
69 CJ1239 TURBO BRUSH
Spare parts list extract from the site on 09-12-2010
