Image preview - the first page of the document
>> Download BEKO_BKL15LW03_Chassis_LW_sm documenatation <<
Text preview - extract from the document
ULC TARGET SPECS Ultra low cost 15"
(15" - 19" 4:3)
SCALER MST7610 (Maria) Mstar or Renesas Scaler
DISPLAY
Type TFT
Aspect ratio 4:3
Brightness 250 cd, 180 cd
Contrast ratio (typical) 500:1
Diagonal screen size 15 inch / 38 cm
Panel resolution 1024*768
Viewing angle (H / V) 160/155
Response time (typical) 12
CONNECTIONS
Antenna
1
(IEC 169-2, Female)
Scart 1 full default
S-video In (DIN) NO
Video In (RCA) 1
Audio In (2 RCA) 1
Video Out (RCA) NO
Audio Out (2 RCA) NO
Progressive YPbPr In
No
(3 RCA)
Audio In for progressive input
No
(2 RCA)
DVI NO
HDMI NO
PC Audio (L, R) PC input via stereo jack available (OPT)
Subwoofer NO
D-Sub 15 D-SUB 15 available (OPT)
SPDIF Coaxial NO
SPDIF Optic NO
RS232 NO
Headphone NO
ADD ON MODULE CONNECTION OPTIONS
Front\Side AV NO
VIDEO & GRAPHICS
IN\OUT
CVBS In 1 through SCART, 1 through RCA
RF In 1 through tuner
Y\C In No
RGB+FB In-Video 1 through SCART1
RGB+HS, VS In -
1 through DSUB-15
Graphics
YPbPr In
NO
(Progressive)
DVI In NO
HDMI In NO
CVBS Out 1 through SCART1
RGB, FB Out no
HDMI out no
AUDIO IN\OUT
Stereo L, R In 1 mono through RCA, 2 MONO through SCARTS
AV Stereo IN 1 stereo through RCA, 1 stereo through SCARTS, 1 PC audio in
Stereo L, R Out NO
Subwoofer Out NO
S\PDIF In NO
S\PDIF Out NO
Subwoofer Out NO
Subwoofer Output
NO
Power
Audio Output Power 1x3W
Number of speakers 1
Speaker Placement Inside the cabinet
ANALOG FRONT END
Conventional tuner
Type
+IF Demodulator
Receiving System
Input Freq. Range VHF (48,25-463,25MHz)
(MHz) UHF (471,25-855,25MHz)
Tune down to
45,25MHz
YES
Tune up to
863,25MHz
Input Connector IEC 169-2, Female
Aerial Input
75 Ohm (unbalanced)
Impedance
Signal Level NO
Tuning System FST
Tuning Control PLL
Antenna Loop
NO
Through
RF Modulator NO
Channel Bandwidth 6\7\8 MHz Switchable
FE Control I2C
TV system PAL/SECAM BG/DK/I From Service Menu
Video Playback NTSC, PAL, SECAM
VIDEO & GRAPHICS
PROCESSING
Data Rate >=
De-multiplexing PID Filters >=
Section Filters >=
ADC (Video) Resolution 8 bit
Chroma Decoding Standart PAL, SECAM, NTSC
Comb Filter -
Color Temparature Yes
LTI, CTI Filters Yes
Sync On Green (SOG)
YES
support on graphics
De-Interlacer 2D-DI
PAT No
Gamma Correction Yes
PIP\PAP\ No
OSD font based
Saturation Yes
Contrast Yes
Tint Yes
Noise reduction 2D
AUDIO PROCESSING
Virtual Dolby/SRS
No
WOW
Subwoofer NO
Effect\Spatial NO
Dynamic Bass NO
VBI DATA
PROCESSING
Teletext Teletext 1.5
Fast text optional
Top text optional
page 8
WSS YES
VPS\PDC\CNI YES
Closed Caption NO
SUPPORTED
OUTPUTS
FOR DISPLAYS
Single TTL support YES
Dual TTL support NO
Single 10-bit TTL
NO
support
Dual 10-bit TTL
NO
support
Single LVDS support
YES
(8-bit)
Dual LVDS support
YES
(8-bit)
Single LVDS support
NO
(10-bit)
Dual LVDS support
NO
(10-bit)
Timing Control
NO
Support
Supported Output Upto WXGA+ at 60Hz (1440x900)
APPLICATIONS
Menu System Beko GUI / Beko OSD
Remote Control Beko RC
Supported Menu
tbd
Languages
Picture Formats
(Auto, 4:3, 16:9, 14:9,
for 4:3 models 16:10 ,4:3 and Auto ,16:9 models have all
Zoom, LetterBox,
Subtitle)
WSS (Wide Screen
YES
Signalling)
Channel skip
<1 sec
time
ATS
(Automatic Tuning Frequency Search time tbd
System)
Black Line Detection no
Manual Search Channel search
AFC (Auto Frequency
YES
Correction)
Number of Program 100
Storage 99
No Ident Timer YES
Picture Freeze no
Equalizer NO
AVL
(Automatic Volume NO
Level)
Optic sensor no
Sound Status
no
Memory
Picture Status
YES
Memory
Zapping\Swap Swap
Child Lock NO
Program Lock no
Picture Format
Switching Through YES
Scart (Pin 8)
Auto RGB Detect
Through Scart (Pin YES
16)
DDC Support YES
Timer On\Off or Sleep Sleep
Picture Smart Modes YES
Sound Smart Modes no
Scart2 Out Selectable no
S-Video Input
no
Through Scart2
Stby to On in PC mode
YES
when last watched is PC
Wake Up in PC
Stby to On automatically
when PC signal is YES
available
POWER SUPPLY
PSU Type LIPS
Input Range 100V-240V, 50, 60Hz
Groundless AC Plug YES (EXCEPT UK)
St-By Power
<2W
Consumption
12V ext power in NO
REGULATIONS
EN55020
EMC EN55013
EN55022 (with PC)
SAFETY EN60065
CABINET
On\Off no
Volume Up no
Volume Down no
Keyboard Program Up no
Program Down no
Menu no
Source no
Single color
no
/Single Intensity
Single Color
LED yes
/Double Intensity
Multi color no
On Timer Led NO
SEQUENCE OF ADJUSTMENT AND CHECKING
SERVS MENU OPTIONS 1
OPTIONS 1
FAST TEXT: ON: Fast Text features ON, OFF: Fast Text feature OFF.
NOTE : Unless customer special choice, select it ON.
TOP TEXT : ON: Top Text features ON, OFF: Top Text feature OFF.
NOTE : Unless customer special choice, select it OFF.
TEXT LANGUAGE : AUTO; automatically selects the TEXT language
NOTE : Unless the customer demands; it will be set as AUTO
WEST : English,French, German, Turkish, Spanish, Italian, Finnish,
