Image preview - the first page of the document
>> Download CP-822F documenatation <<
Text preview - extract from the document
Nov. 2003
TABLE OF CONTENTS
SAFETY INSTRUCTION .................................................................................................................. 2
SPECIFICATIONS ............................................................................................................................ 3
CIRCUIT BLOCK DIAGRAM ........................................................................................................... 4
ALIGNMENT INSTRUCTION ........................................................................................................... 5
SCHEMATIC DIAGRAM .................................................................................................................. 11
EXPLODED VIEW ............................................................................................................................ 12
PRINTED CIRCUIT BOARD ............................................................................................................ 14
SERVICE PARTS LIST .................................................................................................................... 17
APPENDIX (" Appendix is provided only by internet [http://svc.dwe.co.kr] ")
IC DESCRIPTION ............................................................................................................................. 1
IC DC VOLTAGE CHARTS .............................................................................................................. 18
1
SAFETY INSTRUCTION
WARNING : Only competent service personnel may carry out work involving the testing or repair of this equipment
X-RAY RADIATION PRECAUTION
1. Excessive high voltage can prodece potentially haz- 2. The only source of X-RAY Radiation in this TV receiver
ardous X-RAY RADIATION. To avoid such hazards, is the picture tube. For continued X-RAY RADIATION
the high voltage must not exceed the specified limit. protection, the replacement tube must be exactly the
The nominal value of the high voltage of this receiver is same type tube as specified in the parts list.
29-31kv at max beam current. The high voltage must
not, under any circumstances, exceed 35kv. (33kv :
SAMSUNG CRT)
Each time a receiver require servicing, the high volt-
age should be checked. It is imprortant to use an accu-
rate and reliable high voltage meter.
SAFETY PRECAUTION
1. Potentials of high voltage are present when this 2. If any Fuse in this TV receiver is blown, replace it with
receiver is operating. Operation of the receiver outside the FUSE specified in the Replacement Parts List.
the cabinet or with the back board removed involves a 3. When replacing a high wattage resistor ( oxide metal
shock hazard from the receiver. film resistor ) in circuit board, keep the resistor 10mm
1) Servicing should not be attempted by anyone who is away from circuit board.
not thoroughly familiar with the precautions neces- 4. Keep wires away from high voltage or high tempera-
sary when working on high-voltage equipment. ture components.
2) Dischange the high potential of the picture tube 5. This receiver must operate under AC230 volts, 50Hz.
before handling the tube. The picture tube is highly NEVER connect to DC supply or any other power or
evacuated and if broken, glass fragments will be frequency.
violently expelled.
PRODUCT SAFETY NOTICE
Many electrical and mechanical parts in this have nents having such features are identified designated
special safety-related characteristics. These charac- symbol on the parts list.
teristics are often passed unnoticed by a visual Before replacing any of these components, read the
inspection and the X-RAY RADIATION protection parts list in this manual carefully. The use of substitute
afforded by them cannot necessarily be obtained by replacement parts which do not have the same safety
using replacement components rated for higher volt- characterisitics as specifide in the parts list may create
age, wattage, etc. Replacement parts which have X-RAY Radiation.
these special safety characteristics are identified in
this manual and its supplements, electrical compo-
2
SPECIFICATIONS
PIN Signal Designation Matching Value
1 Audio Out (linked with 3) 0.5Vrms, Imp < 1 k (RF 60% MOD)
2 Audio In (linked with 6) 0.5Vrms, Imp < 10 k
3 Audio Out (linked with 1) 0.5Vrms, Imp < 1 k (RF 60% MOD)
4 Audio Earth
5 Blue Earth
6 Audio in (linked with 2) 0.5Vrms, Imp < 10 k (RF 60% MOD)
7 Blue in 0.7Vpp + 2dB, Imp 75
-
8 Slow (Function) Switching TV : 0-2V, PERI : 9.5 - 12V, Imp > 10 k
9 Green Earth
10 NC
11 Green In 0.7Vpp + 2dB, Imp 75
-
12 NC
13 Red Earth
14 Rapid(Blanking) Switching Earth
15 Red In, C In 0.7Vpp + 2dB, Imp 75
-
16 Rapid(Blanking) switching Logic 0 : 0 - 0.4V, Logic 1 : 1 - 3V, Imp 75
17 Video Earth
18 Rapid Blanking Earth
19 Video Out 1Vpp + 2dB, Imp 75
-
20 Video In, Y In 1Vpp + 2dB, Imp 75
-
21 Common Earth
3
CIRCUIT BLOCK DIAGRAM
4
ALIGNMENT INSTRUCTIONS
User Remocon
1. R-22D06
TV...................................TXT TV................................TXT
PR UP..........................PAGE UP
VOLUME...............VOLUME (CURSOR UP)
DOWN ..................DOWN
(CURSOR LEFT) VOLUME UP...........VOLUME UP
(CURSOR RIGHT)
MENU.......................MENU
PR DOWN..............PAGE DOWN
(CURSOR DOWN)
POWER.................POWER
NORMAL .................... Not used
PR ......................... PAGE
NUMBER NUMBER A V .............................. Not used
0-9 0-9
TXT ............................. Not used
SOUND ....................... Not used
SLEEP...................Not used MODE
MUTE .......................... MUTE
Not used................CANCEL Not used ...................... INDEX
Not used................... HOLD Not used ....................... Size
RECALL...............SUBPAGE Zoom ..................Double Window
STILL......................REVEAL EFFECT ....................... Not used
Not used ..........................R Not used ...................... C
Not used ..........................G Not used ....................... Y
R-22D06
5
ALIGNMENT INSTRUCTIONS
IC MASTER MEMORY CONDITION TABLE FOR CP-822F CHASSIS
CONTROL MODEL BASIC W/VIRTUAL DOLBY
V. Slope -015 (const.) -015 (const.)
V. Center 955 955
V.Size 68 68
S.Curve 027 (const.) 027 (const.)
Deflection
H.Center -333 -333
H.Width 40 40
EW.Para -040 -040
EW.Cor Top 012 012
EW.Cor Low 008 008
EW. Sym -006 -006
R Bias 330 (const.) 330 (const.)
G Bias 330 330
B Bias 370 370
R Drive 400 (const.) 400 (const.)
W/B
G Drive 370 370
B Drive 370 370
G2 Adjust 000 000
Sub Bright 006 006
Double TEXT -514 (can't see) -514 (can't see)
Wide Option YES YES
Opt1.
* Tuner Is DWE (opt.) DWE (opt.)
Flat Option YES YES
Svm SVG 003 (const.) 003 (const.)
Svm SVD 004 (const.) 004 (const.)
SVM
Svm SVDEL 012 (const.) 012 (const.)
Svm SVCOR 009 (const.) 009 (const.)
Bcl Thres 580 (const.) 580 (const.)
BCL
Bcl Tc 250 (const.) 250 (const.)
Bcl Gain 511 (const.) 511 (const.)
Nor1 Bright 038 038
Normal 1
Nor1 Cont 058 058
Nor1 Color 042 042
Nor1 Sharp 032 032
Nor1 Tint 032 032
Nor2 Bright 038 038
Normal 2
Nor2 Cont 038 038
Nor2 Color 038 038
Nor2 Sharp 032 032
Nor2 Tint 032 032
OSD Sound
Dolby 3411 N0 YES
OSD Contrast 400 (const.) 400 (const.)
OSD Bright 000 (const.) 000 (const.)
Text Gain YES YES
Tilt Option YES YES
Opt2.
Transparent NO NO
Vertical Angle -769 (const.) -769 (const.)
Vertical Bow -769 (const.) -769 (const.)
* Tuner is
DW DAEWOO/PARTSNIC/SAMSUNG
PHI PHILIPS
SIE SIEL
6
ALIGNMENT INSTRUCTIONS
AFT
Standard B/G, D/K, Iand L
1) Set a Signal Generator with
- RF FREQUENCY = 38.9 MHz,
- RF OUTPUT LEVEL = 80 + 5dBuV
-
- Pattern = Color Bar
- System = PAL-B/G
2) Connect the Signal Generator RF Output to TP2 (Tuner IF Output).
There must be no signal input to the tuner.
3) Set the L103 to TP1(I101, #22) with DC Voltage to 2.5V +0.1V
-
RF AGC
1) Set a TV Signal Generator(e.g. PM5418)with
- RF FREQUENCY : 503.25 MHz, CH 25
- RF OUTPUT LEVEL : 1 60 dBuV(TECC2949PG35W:Samsung/DT5-BF18D:Partsnic)
2 60 dBuV(UV1316/A:Philips/EL2782/105-B-Siel)
- Pattern = Color Bar(or Philips patten)
2) Connect the Signal Generator RF output to Tuner input terminal.
Connect a Oscilloscope probe(or Digital Multi-meter) to P101(Tuner AGC input).
3) Set the voltage level to 1 3.0V + 0.1Vdc, 2 2.5V + 0.1Vdc by adjusting the RB02
- -
(Variable Resistor).
SCREEN (G2)
1) Set a Pattern Generator with - RF Frequency : 210.25MHz (10CH)
- Pattern : RETMA
2) Select the "G2" in Menu
3) And a Horizontal Line will appear on the screen.
4) Adjust the SCREEN VOLUME on FBT barely to see the Horizontal Line.
5) Press the PR UP/DOWN keys to finish the SCREEN adjustment.
FOCUS
1) Apply a RETMA PATTERN signal.
2) Adjust the FOCUS VOLUME on FBT to obtain optimal resolution.
GEOMETRY
1. VERTICAL SLOPE ( Fixed : Adjust if need be )
1) Apply a RETMA PATTERN Signal.
2) Set the TV to Normal I mode.
3) Adjust the higher semicircle and the lower semicircle to be the same, with the V.Slope
by volume Up/Down keys.
2. VERTICAL CENTER
1) Apply a RETMA PATTERN Signal.
2) Set the TV to Normal I mode.
3) Adjust the center of the picture with the V.Center by volume Up/Down keys.
7
ALIGNMENT INSTRUCTIONS
3. VERTICAL SIZE
* The VERTICAL CENTER adjustment has to be done in advance.
1) Apply a RETMA PATTERN Signal.
2) Set the TV to Normal I mode.
3) Adjust the VERTICAL SIZE of the picture with the select V.size by
volume UP/DOWN keys.
4. VERTICAL S-CORRECTION ( Fixed : Adjust if need be )
1) Apply a CROSSHATCH PATTERN Signal.
2) Adjust the S-CORRECTION to obtain the same distance between
horizontal lines with the S.Curve by volume UP/DOWN keys.
5. HORIZONTAL CENTER
1) Apply a RETMA PATTERN Signal.
2) Adjust picture centering with the select H.Center by volume UP/DOWN keys.
EW
1. WIDTH
1) Apply a RETMA PATTERN Signal.
2) Adjust the horizontal width to make a perfect circle with the select H.Width
by volume UP/DOWN keys.
2. PARA
1) Apply a CROSSHATCH PATTERN Signal.
2) Adjust the vertical line to straight with the select E.W Para by volume
UP/DOWN keys.
3. CORNER ( Fixed : Adjust if need be )
1) Apply a CROSSHATCH PATTERN Signal.
2) Adjust the vertical line to straight with the select EW.Cor T by volume
UP/DOWN keys.
4. SYMMETRY ( Fixed : Adjust if need be )
1) Apply a CROSSHATCH PATTERN Signal.
2) Adjust the symmetrical balance to be suitable with the select EW Sym by
volume UP/DOWN keys.
8
ALIGNMENT INSTRUCTIONS
WHITE BALANCE
1. RGB Reference R
2
2. Beam Reference LOW ( 288, 301 : 10Cd/ m )
2
HIGH ( 288, 301 : 100Cd/ m )
3. Adjust G, B Gain with select Menu G,B of BIAS, DRIVE of select Menu so that R, G, B Bars
are on the center position of the analog meter. If R Analog meter is not on center, control
the Brightness +/- of user Remocon so as R Analog meter to be on the center position.
SUB BRIGHT
1. Pattern : Retma
2. Adjust the SUB BRIGHT with the select Sub Bri by volume UP/DOWN keys.
so that only H-Center parts of picture can be seen.
DOUBLE TEXT CENTER
1. Pattern : Pattern RED
2. Select Menu
3. Select DT in SVC menu time to see the Double Text Picture.
( Left : RF Picture, Right : Text Picture )
4. Change the Double Text control keys volume UP/DOWN keys so that the left edge of text
picture concur with the right edge of RF picture.
WIDE MODE
1. Locate the cursor on `Wide' in SVC Menu.
2. `Yes' changes the display to 16:9 mode.
3. `No' change the display to 4:3 mode.
TUNER SELECTION
1. DWE : Partsnic Tuner or Samsung Tuner
2. PHI : Philips Tuner
3. SIE : Siel Tuner
FLAT MODE
1. Locate the cursor on `FLAT' in SVC Menu.
2. `Yes' changes the display to FLAT CRT mode.
3. `No' change the display to Normal CRT mode.
9
ALIGNMENT INSTRUCTIONS
SVM (Scan Velocity Modulation)
1. SVM SVG : SVM Gain
2. SVM SVD : SVM Differentiator delay (0 = filter off)
3. SVM SVDEL : Delay of SVMOUT in steps of 12.5nS
2. SVM SVCOR : SVM coring value
BCL (Beam Current Limit)
1. BCL Thres : BCL threshold current
2. BCL TC : BCL time constant
3. BCL Gain : BCL loop Gain
10
SCHEMATIC DIAGRAM
11
EXPLODED VIEW
DTA-3220ZZ/DTA-3220ZL
12
EXPLODED VIEW
DTA-32W9ZZ/DTA-3220ZL
13
PRINTED CIRCUIT BOARD
PRINTED CIRCUIT BOARD
15
PRINTED CIRCUIT BOARD
16
Part List
Caution In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need
the latest parts information, please refer to PPL(Prats Price List) in Service information Center (http://svc.dwe.co.kr)
Caution is a recommendable part for stock.
is safety component, so it must be used the same component.
LOC PART CODE PART NAME DESCRIPTION REMARK LOC PART CODE PART NAME DESCRIPTION REMARK
ZZ100 48B3822D06 TRANSMITTER REMOCON R-22D06 (AAA) 10 2193102005 SOLDER BAR SN:PB=63:47 S63S-1320
ZZ110 PTACPWD546 ACCESSORY AS DTL-29U8ZLF CF11 CMYH3D752J C MYLAR 2KV BUP 7500PF J
M821 4858213801 BAG INSTRUCTION L.D.P.E T0.05X250X400 I101 1TDA4470M- IC IF TDA4470-M
ZZ120 PTBCSHD764 COVER BACK AS DTA-3220ZZF I606 1MSP3410V3 IC SOUND PROCESSOR MSP3410G-PP-B8-V3
M211 4952102201 COVER BACK HIPS I901 PTC2SW5403 HEAT SINK ASS`Y 1STV5109 + 7174300811
M781 4857817610 CLOTH BLACK FELT 300X20X0.7 00001 1STV5109 IC VIDEO AMP STV5109
ZZ130 PTPKCPD764 PACKING AS DTA-3220ZZF 0000A 4857025403 HEAT SINK AL050P-H24 T=2
10 6520010100 STAPLE PIN AUTO W65 0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
M681 4856812400 BAND PP AUTO T1.1XW17mmXL770M IC01 1KSM9HP - IC PREAMP KSM-9HP
M801 4958002200 BOX CARTON DW-4 IF01 1MC7812 - IC REGULATOR MC7812 12V 1A (KA7812)
M811 4958102500 PAD EPS IF02 1KA4558 - IC AMP KA4558
M821 4958200701 BAG P.E FOAM T0.5X1880X1380 IT01 1LA6515 - IC OP AMP LA6515
ZZ131 58GD000003 COIL DEGAUSSING DC-3200(E) JZ01 4859105240 JACK PHONE LGT1516-0100
ZZ132 49519A0110 CRT GROUND NET DSC-3210E JZ02 4859105340 JACK S-VHS YKF51-5359
ZZ140 PTCACAD764 CABINET AS DTA-3220ZZF JZ03 4859105450 JACK PIN BOARD YSC03P-4120-9S
M201A 4956000100 SCREW CRT FIX SWRM10A L=35 L103 58E0000041 COIL AFT TRF-A005
M201B 4856215401 WASHER RUBBER CR T1.0 LED1 DSLR342MC3 LED SLR-342MC3
M201C 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK LED2 DSLR342VC3 LED SLR-342VC3
M201D 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK LF01 58CD000009 COIL CHOKE 920UH
M211A 7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK M232 4952300701 PANEL AV HIPS PAINT
M211B 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK M232A 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK
M211C 7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK M321 4953200600 BRKT POWER EGI T1.2
M211D 7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK M321A 7063300612 SCREW MACHINE M/C BIN 3X6 MFZN BK
M231 4952301301 PANEL CTRL HIPS PAINT M491 4954901601 BUTT0N CH ABS PAINT
M353 4853535600 HOLDER CORD NYLON 66 M551 4955501000 DECO SENSOR GPPS
M481 4954801001 BUTTON POWER ABS PAINT M684 4856812001 TIE CABLE NYLON66 DA100
M481A 4856716000 SPRING SWPA PIE0.5 P106 4853946000 BRKT JUMPER A SECC T1.0 (VCR-63DB)
M491A 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK P107 4853946000 BRKT JUMPER A SECC T1.0 (VCR-63DB)
M541 4955400100 SPEC PLATE P.E FILM 91.5X63 P108 4859279520 CONN WAFER TAC-L15P-A3 (ANGLE)
M681 4856812001 TIE CABLE NYLON66 DA100 P109 4859279820 CONN WAFER TAC-L18P-A3 (ANGLE)
M682 4856816300 CLAMP WIRE NYLON 6 (V0) P603A 4850704S04 CONNECTOR YH025-04+YST025+ULW=400
P405 4850706N14 CONNECTOR YFSH500-06+YH396V+ULW=600 P701A 4850708S02 CONNECTOR YH025-08+YST025+ULW=300
P601A 4850704S30 CONNECTOR YH025-04+YRT205+ULW700600 P803 4850702S09 CONNECTOR BL102NG+MXH40058-02=300
SP01 4858315610 SPEAKER SP-5090F13 P901 4859238620 CONN WAFER YPW500-02
SP01A 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK P902 4850703N24 CONNECTOR EHR-03+YBNH250-03+ULW=200
SP02 4858315610 SPEAKER SP-5090F13 PA01A 4850709N07 CONNECTOR YH025-09+YBNH250-09+USW=600
SP02A 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK PD06A 4850712N02 CONNECTOR YH025-12+YBNH250+USW=500
V901 4959601270 CPT W76ERF042X044 PF02 4859238620 CONN WAFER YPW500-02
ZZ200 PTFMSJD764 MASK FRONT AS DTA-3220ZZF PF3 4850702N06 CONNECTOR YPH500-02+YLT500+ULW=200
M201 4952002401 MASK FRONT HIPS PAINT PT02 4850703S21 CONNECTOR YH025-03+YBNH250+ULW=600
M201D 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK Q908 PTF2SW6900 HEAT SINK ASS`Y TKTA1659AY + 7178301011
M201E 4857817610 CLOTH BLACK FELT 300X20X0.7 00001 TKTA1659AY TR KTA1659AY
M561 4855617400 MARK BRAND CU AU+ABS BK 0000A 4857026900 HEAT SINK AL EX
ZZ202 PTU1MSD764 PCB UNION-1 MANUAL AS DTA-3220ZZF 0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
17
Part List
LOC PART CODE PART NAME DESCRIPTION REMARK LOC PART CODE PART NAME DESCRIPTION REMARK
Q909 PT62SW6900 HEAT SINK ASS Y TKTC4370AY + 7178301011 C639 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
00001 TKTC4370AY TR KTC4370AY C640 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
0000A 4857026900 HEAT SINK AL EX C641 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN C643 CEXF1H339V C ELECTRO 50V RSS 3.3MF (5X11) TP
QF04 T4636LSRB- TR 2SC4636LS-RB C644 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
SCT1 4859303730 SOCKET CRT ISD-07S C645 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
SF01 5PK3953M FILTER SAW K3953M C646 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
SF02 5PK9650M FILTER SAW K9650M C647 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
SW801 5S40000003 SW POWER PUSH SS-160-7-G C648 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
TF01 50D28A1 - TRANS DRIVE TD-28A1 C649 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
ZZ200 PTU1J0D764 PCB UNION RHU AS DTA-3220ZZF C650 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C908 CEXF2E100V C ELECTRO 250V RSS 10MF (10X20) TP C651 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C909 CCXB3D102K C CERA 2KV B 1000PF K (TAPPING) C652 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C913 CEXF2E100V C ELECTRO 250V RSS 10MF (10X20) TP C653 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C922 CCXB2H472K C CERA 500V B 4700PF K (TAPPING) C654 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C923 CCXB2H472K C CERA 500V B 4700PF K (TAPPING) C658 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C925 CEXF2E100V C ELECTRO 250V RSS 10MF (10X20) TP C901 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C941 CEXF2C470V C ELECTRO 160V RSS 47MF (13X25) TP C902 CMXM2A104K C MYLAR 100V 0.1MF K (TP)
C942 CEXF2E100V C ELECTRO 250V RSS 10MF (10X20) TP C904 CXSL2H471J C CERA 500V SL 470PF J (TAPPING)
C943 CEXF2C470V C ELECTRO 160V RSS 47MF (13X25) TP C905 CXSL2H471J C CERA 500V SL 470PF J (TAPPING)
C945 CEXF2E100V C ELECTRO 250V RSS 10MF (10X20) TP C906 CXSL2H471J C CERA 500V SL 470PF J (TAPPING)
CF02 CMXE2J333J C MYLAR 630V PU 0.033MF J (TP) C912 CMXL2E104J C MYLAR MEU 250V 0.1MF J
CF05 CMXE2J333J C MYLAR 630V PU 0.033MF J (TP) C915 CMXM2A822J C MYLAR 100V 8200PF J (TP)
CF07 CMXE2J333J C MYLAR 630V PU 0.033MF J (TP) C916 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
CF10 CMXE2J333J C MYLAR 630V PU 0.033MF J (TP) C920 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
ZZ200 PTU1JBD764 PCB UNION M-10 AS DTA-3220ZZF C921 CCXB1H101K C CERA 50V B 100PF K (TAPPING)
P401 485923172S CONN WAFER YW025-04 (STICK) C924 CCXB1H101K C CERA 50V B 100PF K (TAPPING)
P402 485923162S CONN WAFER YW025-03 (STICK) C944 CXSL2H560J C CERA 500V SL 56PF J (TAPPING)
PF01 485923202S CONN WAFER YW025-07 (STICK) CF01 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.5) TP
PT01 485923162S CONN WAFER YW025-03 (STICK) CF04 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
R904 RS02Z563JS R M-OXIDE FILM 2W 56K OHM J SMALL CF06 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
R907 RS02Z563JS R M-OXIDE FILM 2W 56K OHM J SMALL CF08 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
R910 RS02Z563JS R M-OXIDE FILM 2W 56K OHM J SMALL CF09 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
R954 RF02Z249J- R FUSIBLE 2W 2.4 OHM J (TAPPING) CF12 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
RF19 RF02Z479J- R FUSIBLE 2W 4.7 OHM J (TAPPING) CF13 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.5) TP
RF20 RS01Z472J- R M-OXIDE FILM 1W 4.7K OHM J (TAPPING) CF14 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
RF21 RS01Z228J- R M-OXIDE FILM 1W 0.22 OHM J CT01 CMXL1J474J C MYLAR 63V MEU 0.47MF J
ZZ200 PTU1JRD764 PCB UNION RADIAL AS DTA-3220ZZF CT02 CMXL1J474J C MYLAR 63V MEU 0.47MF J
C100 CXRH1H150J C CERA RH 50V 15PF J (TAPPING) CT03 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C108 CXCH1H220J C CERA 50V CH 22PF J (TAPPING) CT11 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C111 CXCH1H220J C CERA 50V CH 22PF J (TAPPING) G901 4SG0DX0001 SPARK GAP SSG-102-A1(1.0KV) TAP
C114 CEXF1E470C C ELECTRO 25V RUS 47MF (5X11) TP G902 4SG0DX0001 SPARK GAP SSG-102-A1(1.0KV) TAP
C116 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP G903 4SG0DX0001 SPARK GAP SSG-102-A1(1.0KV) TAP
C118 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP G904 4SG0DX0001 SPARK GAP SSG-102-A1(1.0KV) TAP
C122 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP JZ05 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
C123 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP JZ06 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
C630 CXCH1H309C C CERA 50V CH 3PF C L904 58C0000116 COIL BEAD HC-3550R
C631 CXCH1H309C C CERA 50V CH 3PF C Q104 TKTC3197 TR KTC3197 (TP)
C632 CCXF1H223Z C CERA 50V F 0.022MF Z (TAPPING) Q105 TKTC3198Y- TR KTC3198Y
C634 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP Q106 TKTC3198Y- TR KTC3198Y
C636 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP Q107 TKTC3198Y- TR KTC3198Y
C637 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP Q901 TKTC3198Y- TR KTC3198Y
C638 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP Q902 TKTC3198Y- TR KTC3198Y
18
Part List
LOC PART CODE PART NAME DESCRIPTION REMARK LOC PART CODE PART NAME DESCRIPTION REMARK
Q903 TKTC3198Y- TR KTC3198Y D909 D1N4148 - DIODE 1N4148 (TAPPING)
Q904 TKTC3198Y- TR KTC3198Y D910 D1N4148 - DIODE 1N4148 (TAPPING)
Q905 TKTC3198Y- TR KTC3198Y D911 DEU1Z - DIODE EU1Z (HIGH SPEED)
Q906 TKTC3198Y- TR KTC3198Y D912 DEU1Z - DIODE EU1Z (HIGH SPEED)
Q907 TKTA1266Y- TR KTA1266Y (TP) D920 D1N4937G DIODE 1N4937G (TAPPING)
QF01 TKTA1266Y- TR KTA1266Y (TP) D921 D1N4937G DIODE 1N4937G (TAPPING)
QF02 TKTA1266Y- TR KTA1266Y (TP) D922 D1N4937G DIODE 1N4937G (TAPPING)
QF03 TKTC3198Y- TR KTC3198Y DF01 D1N4937G DIODE 1N4937G (TAPPING)
QT01 TKTC3198Y- TR KTC3198Y DF02 D1N4937G DIODE 1N4937G (TAPPING)
R951 RN01B102JS R METAL FILM 1W 1K OHM J SMALL DF03 D1N4937G DIODE 1N4937G (TAPPING)
R953 RN02B331JS R METAL FILM 2W 330 OHM J SMALL DF04 D1N4937G DIODE 1N4937G (TAPPING)
R956 RN02B100JS R METAL FILM 2W 10 OHM J SMALL DT02 D1N4148 - DIODE 1N4148 (TAPPING)
RB02 RV5426103P R SEMI FIXED ENV-DJAA03B14 10K OHM B J151 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
RF24 RN02B683JS R METAL FILM 2W 68K OHM J SMALL J152 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
RF25 RN02B333JS R METAL FILM 2W 33K OHM J SMALL J153 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
RF26 RN02B683JS R METAL FILM 2W 68K OHM J SMALL J154 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
SW701 5S50101Z90 SW TACT THVV502GDA J155 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
SW702 5S50101Z90 SW TACT THVV502GDA J156 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
SW703 5S50101Z90 SW TACT THVV502GDA J157 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
SW704 5S50101Z90 SW TACT THVV502GDA J159 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
SW705 5S50101Z90 SW TACT THVV502GDA J160 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
X601 5XEX18R43E CRYSTAL QUARTZ HC-49/U 18.432MHZ 30PPM TP J161 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
ZZ200 PTU1JAD764 PCB UNION AXIAL AS DTA-3220ZZF J165 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
10 2TM14006LB TAPE MASKING 3M #232 6.0X2000M J167 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
20 2TM10006LB TAPE MASKING 3M #232-MAP-C 6.2X2000M J169 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
A001 4859809660 PCB UNION 330X246 D1B J170 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
C109 CCZB1H102K C CERA 50V B 1000PF K (AXIAL) J171 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
C110 CCZF1H103Z C CERA 50V F 0.01MF Z J172 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
C112 CZSL1H470J C CERA 50V SL 47PF J (AXIAL) J651 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
C113 CCZF1H103Z C CERA 50V F 0.01MF Z J652 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
C115 CCZF1H103Z C CERA 50V F 0.01MF Z J653 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
C117 CCZF1H103Z C CERA 50V F 0.01MF Z J654 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
C119 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z J655 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
C120 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z J656 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
C121 CCZF1H103Z C CERA 50V F 0.01MF Z J657 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
C124 CCZF1H103Z C CERA 50V F 0.01MF Z J658 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
C633 CCZB1H102K C CERA 50V B 1000PF K (AXIAL) J659 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
C635 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z J660 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
C642 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z J661 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
C656 CCZB1H102K C CERA 50V B 1000PF K (AXIAL) J662 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
C657 CCZB1H102K C CERA 50V B 1000PF K (AXIAL) J663 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
C917 CCZB1H391K C CERA 50V B 390PF K (AXIAL) J664 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
C918 CCZF1H103Z C CERA 50V F 0.01MF Z J665 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
C919 CCZB1H102K C CERA 50V B 1000PF K (AXIAL) J666 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
CC01 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z J667 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
CT05 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z J668 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
CZ01 CCZB1H561K C CERA 50V B 560PF K J669 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
CZ02 CCZB1H561K C CERA 50V B 560PF K J670 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
D102 DBA282 DIODE BA282 J672 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
D904 DLT2A05G DIODE LT2A05G (TP) J901 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
D906 D1N4148 - DIODE 1N4148 (TAPPING) J902 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
D907 D1N4148 - DIODE 1N4148 (TAPPING) J904 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
D908 D1N4148 - DIODE 1N4148 (TAPPING) J906 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
19
Part List
LOC PART CODE PART NAME DESCRIPTION REMARK LOC PART CODE PART NAME DESCRIPTION REMARK
J907 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING R909 RD-AZ392J- R CARBON FILM 1/6 3.9K OHM J
J908 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING R911 RD-AZ271J- R CARBON FILM 1/6 270 OHM J
J909 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING R912 RD-AZ392J- R CARBON FILM 1/6 3.9K OHM J
J910 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING R913 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
J913 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING R914 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
J914 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING R915 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
J915 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING R916 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
J916 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING R917 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
J918 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING R918 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
J919 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING R919 RC-2Z102K- R CARBON COMP 1/2 1K OHM K
J920 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING R920 RC-2Z102K- R CARBON COMP 1/2 1K OHM K
J930 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING R921 RC-2Z102K- R CARBON COMP 1/2 1K OHM K
JC01 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING R922 RD-2Z100J- R CARBON FILM 1/2 10 OHM J
JF01 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING R923 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
JF03 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING R924 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
JF04 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING R925 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
JF05 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING R926 RD-2Z471J- R CARBON FILM 1/2 470 OHM J
JF06 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING R927 RD-AZ121J- R CARBON FILM 1/6 120 OHM J
JZ04 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING R928 RD-AZ223J- R CARBON FILM 1/6 22K OHM J
L110 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM) R929 RD-AZ273J- R CARBON FILM 1/6 27K OHM J
L630 5CPZ109M02 COIL PEAKING 1UH M (AXIAL 3.5MM) R930 RD-AZ333J- R CARBON FILM 1/6 33K OHM J
L631 5CPZ109M02 COIL PEAKING 1UH M (AXIAL 3.5MM) R932 RD-AZ392J- R CARBON FILM 1/6 3.9K OHM J
L632 5CPZ479K02 COIL PEAKING 4.7UH K (AXIAL 3.5MM) R933 RD-AZ392J- R CARBON FILM 1/6 3.9K OHM J
L901 5MC0000100 COIL BEAD HC-3550 R934 RD-AZ393J- R CARBON FILM 1/6 39K OHM J
L902 5MC0000100 COIL BEAD HC-3550 R935 RD-AZ563J- R CARBON FILM 1/6 56K OHM J
L903 5MC0000100 COIL BEAD HC-3550 R936 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
LT01 5CPZ569K02 COIL PEAKING 5.6UH K (AXIAL 3.5MM) R937 RD-AZ820J- R CARBON FILM 1/6 82 OHM J
R112 RD-AZ153J- R CARBON FILM 1/6 15K OHM J R938 RD-2Z100J- R CARBON FILM 1/2 10 OHM J
R113 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J R939 RD-AZ820J- R CARBON FILM 1/6 82 OHM J
R114 RD-AZ751J- R CARBON FILM 1/6 750 OHM J R940 RD-AZ122J- R CARBON FILM 1/6 1.2K OHM J
R115 RD-AZ101J- R CARBON FILM 1/6 100 OHM J R941 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
R116 RD-AZ682J- R CARBON FILM 1/6 6.8K OHM J R942 RD-AZ683J- R CARBON FILM 1/6 68K OHM J
R117 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J R943 RD-AZ683J- R CARBON FILM 1/6 68K OHM J
R118 RD-AZ103J- R CARBON FILM 1/6 10K OHM J R944 RD-AZ123J- R CARBON FILM 1/6 12K OHM J
R119 RD-AZ563J- R CARBON FILM 1/6 56K OHM J R945 RD-AZ122J- R CARBON FILM 1/6 1.2K OHM J
R120 RD-AZ562J- R CARBON FILM 1/6 5.6K OHM J R946 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
R121 RD-AZ223J- R CARBON FILM 1/6 22K OHM J R947 RD-2Z620J- R CARBON FILM 1/2 62 OHM J
R122 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J R948 RD-2Z279J- R CARBON FILM 1/2 2.7 OHM J
R123 RD-AZ102J- R CARBON FILM 1/6 1K OHM J R950 RD-2Z279J- R CARBON FILM 1/2 2.7 OHM J
R124 RD-AZ153J- R CARBON FILM 1/6 15K OHM J R952 RD-2Z620J- R CARBON FILM 1/2 62 OHM J
R125 RD-AZ153J- R CARBON FILM 1/6 15K OHM J R955 RD-AZ182J- R CARBON FILM 1/6 1.8K OHM J
R126 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J R957 RD-4Z105J- R CARBON FILM 1/4 1M OHM J
R127 RD-AZ151J- R CARBON FILM 1/6 150 OHM J R958 RD-2Z102J- R CARBON FILM 1/2 1K OHM J
R128 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J RC01 RD-AZ153J- R CARBON FILM 1/6 15K OHM J
R129 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J RC02 RD-AZ392J- R CARBON FILM 1/6 3.9K OHM J
R130 RN-AZ1502F R METAL FILM 1/6 15K OHM F RC03 RD-AZ182J- R CARBON FILM 1/6 1.8K OHM J
R131 RN-AZ5101F R METAL FILM 1/6 5.1K OHM F RC04 RD-AZ132J- R CARBON FILM 1/6 1.3K OHM J
R630 RD-AZ101J- R CARBON FILM 1/6 100 OHM J RF01 RD-4Z431J- R CARBON FILM 1/4 430 OHM J
R631 RD-AZ101J- R CARBON FILM 1/6 100 OHM J RF02 RD-4Z561J- R CARBON FILM 1/4 560 OHM J
R901 RD-AZ431J- R CARBON FILM 1/6 430 OHM J RF03 RD-4Z332J- R CARBON FILM 1/4 3.3K OHM J
R905 RD-AZ271J- R CARBON FILM 1/6 270 OHM J RF04 RD-4Z682J- R CARBON FILM 1/4 6.8K OHM J
R906 RD-AZ392J- R CARBON FILM 1/6 3.9K OHM J RF05 RD-4Z911J- R CARBON FILM 1/4 910 OHM J
R908 RD-AZ271J- R CARBON FILM 1/6 270 OHM J RF06 RD-4Z221J- R CARBON FILM 1/4 220 OHM J
20
Part List
LOC PART CODE PART NAME DESCRIPTION REMARK LOC PART CODE PART NAME DESCRIPTION REMARK
RF07 RD-4Z182J- R CARBON FILM 1/4 1.8K OHM J D828 D1N4937G DIODE 1N4937G (TAPPING)
RF08 RD-4Z123J- R CARBON FILM 1/4 12K OHM J F801 5FSCB4022R FUSE CERA SEMKO F4AH 4A 250V MF51
RF09 RD-4Z103J- R CARBON FILM 1/4 10K OHM J I301 PTC2SW8218 HEAT SINK ASS`Y 1TDA8172 + 7174300811
RF10 RD-4Z103J- R CARBON FILM 1/4 10K OHM J 00001 1TDA8172 IC V-OUT TDA8172
RF11 RD-4Z911J- R CARBON FILM 1/4 910 OHM J 0000A 4857028218 HEAT SINK AL EX BK
RF12 RD-4Z513J- R CARBON FILM 1/4 51K OHM J 0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
RF13 RD-4Z103J- R CARBON FILM 1/4 10K OHM J I601 PTA2SW8224 HEAT SINK ASS`Y 1TDA7269 7174300811
RF14 RD-4Z820J- R CARBON FILM 1/4 82 OHM J 00001 1TDA7269 IC AUDIO TDA7269
RF15 RD-4Z103J- R CARBON FILM 1/4 10K OHM J 0000A 4857028224 HEAT SINK AL EX
RF16 RD-4Z153J- R CARBON FILM 1/4 15K OHM J 0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
RF17 RD-4Z272J- R CARBON FILM 1/4 2.7K OHM J I605 1KA4558 - IC AMP KA4558
RF18 RD-4Z132J- R CARBON FILM 1/4 1.3K OHM J I701 1ST195EPM- IC MICOM OTP ST92T195B1/EPM
RF27 RD-4Z221J- R CARBON FILM 1/4 220 OHM J I702 1AT24C16PC IC AT24C16-10PC
RT01 RD-2Z100J- R CARBON FILM 1/2 10 OHM J I801 PTG2SW8200 HEAT SINK ASS`Y 1STRF6656- + 7174301011
RT02 RD-AZ683J- R CARBON FILM 1/6 68K OHM J 00001 1STRF6656- IC POWER STR-F6656
RT03 RD-AZ334J- R CARBON FILM 1/6 330K OHM J 0000A 4857028200 HEAT SINK AL EX BK
RT04 RD-AZ392J- R CARBON FILM 1/6 3.9K OHM J 0000B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
RT05 RD-2Z100J- R CARBON FILM 1/2 10 OHM J I802 1KP1010C IC PHOTO COUPLER KP-1010C
RT06 RD-AZ683J- R CARBON FILM 1/6 68K OHM J I803 1SE140N - IC AMP SE140N
RT07 RD-AZ563J- R CARBON FILM 1/6 56K OHM J I804 PSH2SW6900 HEAT SINK ASS Y 1KA7805 - + 7174301011
RT08 RD-AZ103J- R CARBON FILM 1/6 10K OHM J 00001 1KA7805 - IC REGULATOR KA7805
RT09 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J 0000A 4857026900 HEAT SINK AL EX
RT10 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J 0000B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
RT14 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J I805 PTA2SW7720 HEAT SINK ASS`Y 1K78R05 - + 7174300811
ZZ290 PTMPMSD764 PCB MAIN MANUAL AS DTA-3220ZZF 00001 1K78R05 - IC REGULATOR KIA78R05API
10 2193102005 SOLDER BAR SN:PB=63:47 S63S-1320 0000A 4857027720 HEAT SINK AL EX
30 2291050616 FLUX SOLDER JS-64T3 0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
40 2291050301 FLUX SOLVENT IM-1000 I807 1MC7812 - IC REGULATOR MC7812 12V 1A (KA7812)
C405 CMYH3C432J C MYLAR 1.6KV BUP 4300PF J I808 1KA7808 - IC REGULATOR KA7808
C406 CMYH3C702J C MYLAR 1.6KV BUP 7000PF J I810 TX0202DA THYRISTOR X0202DA1BA2
C407 CMYE2J223J C MYLAR 630V PU 0.022MF J IA01 1MM1118 - IC A/V SWITCH MM1118
C408 CMYE2G184J C MYLAR 400V PU 0.18MF J JPA01 4959103680 JACK SCART DSAM-0266
C410 CEYD1H689W C ELECTRO 50V RHD 6.8MF (16X35.5) JPA02 4959103680 JACK SCART DSAM-0266
C441 CMYL2G104J C MYLAR 400V MEU 0.1MF J L401 58H0000085 COIL H-LINEARITY TRL-5R0D
C443 CMXF2G124J C MYLAR 400V MPP 0.12MF J L403 58C0000130 COIL CHOKE CH-161A
C801 CL1UC3474M C LINE ACROSS 0.47MF 1J(UCVSNDF/SV)+Q/O LF100 5PLF24A3 FILTER LINE LF-24A3
C802 CL1UC3474M C LINE ACROSS 0.47MF 1J(UCVSNDF/SV)+Q/O LF200 58C0000129 COIL CHOKE PFC CPC-201B
C807 CMYF2J154J C MYLAR 630V MPP 0.15MF J M207 4853535500 HOLDER AC CORD NYLON 66
C809 CEYN2W221P C ELECTRO 450V LHS 220MF (30X40) M351 4953500100 HOLDER CORD FR HIPS
C817 CH1BFE472M C CERA AC AC400V 4700PF M U/C/V M351A 7172401612 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK
C820 CEYF1E332V C ELECTRO 25V RSS 3300MF (16X31.5) M381 4953802800 FRAME MAIN PCB FR HIPS BK
C828 CEYE2D221E C ELECTRO 200V RM 220MF (18X35.5) M381A 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK
C829 CEYE2D331E C ELECTRO 200V RM 330MF M381B 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK
D401 DDTV32D - DIODE DTV32D M683 4856812001 TIE CABLE NYLON66 DA100
D805 DRL4A015 DIODE RL4A-015-308 P103 4859281020 CONN WAFER TAC-L15X-A3
D806 DRL4A015 DIODE RL4A-015-308 P104 4859281320 CONN WAFER TAC-L18X-A3
D820 DFMLG12S DIODE FML-G12S P401A 4850704S03 CONNECTOR YH025-04+YST025+ULW=300
D821 DFMLG12S DIODE FML-G12S P402A 4850703S29 CONNECTOR YH025-03+YST025+USW=300
D824 PTP2SW6900 HEAT SINK ASS`Y DFMLG12S + 7174300811 P405 4859240120 CONN WAFER YFW500-06
00001 DFMLG12S DIODE FML-G12S P503 4859281320 CONN WAFER TAC-L18X-A3
0000A 4857026900 HEAT SINK AL EX P504 4859281020 CONN WAFER TAC-L15X-A3
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN P801 4859242220 CONN WAFER YFW800-02
D827 DRGP30J - DIODE RGP30J DO-201AD 600V 3A P802 4859242220 CONN WAFER YFW800-02
21
Part List
LOC PART CODE PART NAME DESCRIPTION REMARK LOC PART CODE PART NAME DESCRIPTION REMARK
P803 4859242220 CONN WAFER YFW800-02 C842 CEXF1C471V C ELECTRO 16V RSS 470MF (8X12)TP
PD03A 4850703S29 CONNECTOR YH025-03+YST025+USW=300 C843 CEXF1H331V C ELECTRO 50V RSS 330MF (10X20) TP
PF01 4850707S02 CONNECTOR YH025-07+YST025+ULW=400 C846 CEXF1E471V C ELECTRO 25V RSS 470MF (10X16) TP
PF03 4859238620 CONN WAFER YPW500-02 ZZ200 PTMPJBD764 PCB MAIN M-10 AS DTA-3220ZZF
PW000 4859903110 CORD POWER AS KKP-419J-H03VVH2+H0U=2200 10 2TM18006BE TAPE MASKING 6.2X500
A000 4859903511 CORD POWER CW4232 H03VVH2-F=2250 E101 4856310300 EYE LET BSR T0.2 (R1.6)
Q401 PTD3SW1600 HEAT SINK ASS Y DFMP3FU - + 7174300811 E102 4856310300 EYE LET BSR T0.2 (R1.6)
00001 DFMP3FU - DIODE FMP3FU E103 4856310300 EYE LET BSR T0.2 (R1.6)
0000A 4857031600 HEAT SINK AL EX E104 4856310300 EYE LET BSR T0.2 (R1.6)
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN E105 4856310300 EYE LET BSR T0.2 (R1.6)
0000C TST2310DH1 TR ST2310DHI E106 4856310300 EYE LET BSR T0.2 (R1.6)
0000D 7174301211 SCREW TAPPTITE TT2 RND 3X12 MFZN E107 4856310300 EYE LET BSR T0.2 (R1.6)
Q402 T2SC4793 TR 2SC4793 E108 4856310300 EYE LET BSR T0.2 (R1.6)
Q403 PTB2SW7603 HEAT SINK ASS`Y T2SC4793 + 7174300811 E109 4856310300 EYE LET BSR T0.2 (R1.6)
00001 T2SC4793 TR 2SC4793 E110 4856310300 EYE LET BSR T0.2 (R1.6)
0000A 4857027603 HEAT SINK AL EX E111 4856310300 EYE LET BSR T0.2 (R1.6)
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN E112 4856310300 EYE LET BSR T0.2 (R1.6)
0000C 4856815900 CLAMP WIRE EGI T0.4+PVC COATING E113 4856310300 EYE LET BSR T0.2 (R1.6)
0000D 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN E114 4856310300 EYE LET BSR T0.2 (R1.6)
Q441 TKTC3209Y- TR KTC3209Y E115 4856310300 EYE LET BSR T0.2 (R1.6)
Q442 PTC2SW7603 HEAT SINK ASS`Y T1RF830 - + 7174300811 E116 4856310300 EYE LET BSR T0.2 (R1.6)
00001 T1RF830 - FET IRF830 E117 4856310300 EYE LET BSR T0.2 (R1.6)
0000A 4857027603 HEAT SINK AL EX E118 4856310300 EYE LET BSR T0.2 (R1.6)
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN E119 4856310300 EYE LET BSR T0.2 (R1.6)
R305 RN02B121JS R METAL FILM 2W 120 OHM J SMALL E120 4856310300 EYE LET BSR T0.2 (R1.6)
R306 RW01Y228F- R WIRE WOUND 1W 0.22 OHM F E121 4856310300 EYE LET BSR T0.2 (R1.6)
R401 RX05V301J- R CEMENT 5W 300 OHM J VERTICAL E122 4856310300 EYE LET BSR T0.2 (R1.6)
R407 RX05V561J- R CEMENT 5W 560 OHM J VERTICAL E123 4856310300 EYE LET BSR T0.2 (R1.6)
R424 RD-4Z682J- R CARBON FILM 1/4 6.8K OHM J E124 4856310300 EYE LET BSR T0.2 (R1.6)
R505 RM02Y338J- R METAL FLAT 2W 0.33 OHM J E125 4856310300 EYE LET BSR T0.2 (R1.6)
R801 DPC7R0M290 POSISTOR 2322 662 96709 E126 4856310300 EYE LET BSR T0.2 (R1.6)
R813 RX10T229J- R CEMENT 10W 2.2 OHM J TRIPOD E127 4856310300 EYE LET BSR T0.2 (R1.6)
T401 50D25A3 - TRANS DRIVE TD-25A3 E128 4856310300 EYE LET BSR T0.2 (R1.6)
T402 50H0000258 FBT BSC29-0125D E201 4856310600 EYE LET BSR T0.2 (R2.3)
T402A 7178301212 SCREW TAPPTITE TT2 WAS 3X12 MFZN BK E202 4856310600 EYE LET BSR T0.2 (R2.3)
T801 50M5345B8- TRANS SMPS TSM-5345B8 E206 4856310600 EYE LET BSR T0.2 (R2.3)
TU01 4859722630 TUNER VARACTOR TECC2949PG35W E208 4856310600 EYE LET BSR T0.2 (R2.3)
Y801 5SC0101003 SW RELAY DG12D1-0(M)-II 1C-1P E210 4856310600 EYE LET BSR T0.2 (R2.3)
ZZ200 PTMPJ0D764 PCB MAIN (RHU) AS DTA-3220ZZF E211 4856310600 EYE LET BSR T0.2 (R2.3)
C320 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP E212 4856310600 EYE LET BSR T0.2 (R2.3)
C321 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP E213 4856310600 EYE LET BSR T0.2 (R2.3)
C402 CEXF1H471V C ELECTRO 50V RSS 470MF (13X20) TP E214 4856310600 EYE LET BSR T0.2 (R2.3)
C416 CCXB3D471K C CERA 2KV B 470PF K (TAPPING) E215 4856310600 EYE LET BSR T0.2 (R2.3)
C420 CEXF2E100V C ELECTRO 250V RSS 10MF (10X20) TP E216 4856310600 EYE LET BSR T0.2 (R2.3)
C442 CEXF2E100V C ELECTRO 250V RSS 10MF (10X20) TP E217 4856310600 EYE LET BSR T0.2 (R2.3)
C610 CEXF1E471V C ELECTRO 25V RSS 470MF (10X16) TP E218 4856310600 EYE LET BSR T0.2 (R2.3)
C611 CEXF1E471V C ELECTRO 25V RSS 470MF (10X16) TP E219 4856310600 EYE LET BSR T0.2 (R2.3)
C813 CCXB3D471K C CERA 2KV B 470PF K (TAPPING) E220 4856310600 EYE LET BSR T0.2 (R2.3)
C821 CCXB3D102K C CERA 2KV B 1000PF K (TAPPING) E221 4856310600 EYE LET BSR T0.2 (R2.3)
C827 CEXF1E471V C ELECTRO 25V RSS 470MF (10X16) TP E222 4856310600 EYE LET BSR T0.2 (R2.3)
C831 CEXF1E222V C ELECTRO 25V RSS 2200MF (16X25) TP E223 4856310600 EYE LET BSR T0.2 (R2.3)
C832 CEXF1E222V C ELECTRO 25V RSS 2200MF (16X25) TP E224 4856310600 EYE LET BSR T0.2 (R2.3)
C836 CEXF1C471V C ELECTRO 16V RSS 470MF (8X12)TP E225 4856310600 EYE LET BSR T0.2 (R2.3)
22
Part List
LOC PART CODE PART NAME DESCRIPTION REMARK LOC PART CODE PART NAME DESCRIPTION REMARK
E226 4856310600 EYE LET BSR T0.2 (R2.3) C620 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
E227 4856310600 EYE LET BSR T0.2 (R2.3) C622 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
E228 4856310600 EYE LET BSR T0.2 (R2.3) C624 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
E229 4856310600 EYE LET BSR T0.2 (R2.3) C626 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
E230 4856310600 EYE LET BSR T0.2 (R2.3) C627 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
E231 4856310600 EYE LET ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
