Image preview - the first page of the document
cp-822f[1].part1


>> Download cp-822f[1].part1 documenatation <<

Text preview - extract from the document
Nov. 2003
TABLE OF CONTENTS
SAFETY INSTRUCTION .................................................................................................................. 2

SPECIFICATIONS ............................................................................................................................ 3

CIRCUIT BLOCK DIAGRAM ........................................................................................................... 4

ALIGNMENT INSTRUCTION ........................................................................................................... 5

SCHEMATIC DIAGRAM .................................................................................................................. 11

EXPLODED VIEW ............................................................................................................................ 12

PRINTED CIRCUIT BOARD ............................................................................................................ 14

SERVICE PARTS LIST .................................................................................................................... 17

APPENDIX (" Appendix is provided only by internet [http://svc.dwe.co.kr] ")

IC DESCRIPTION ............................................................................................................................. 1

IC DC VOLTAGE CHARTS .............................................................................................................. 18


                                                                       1
SAFETY INSTRUCTION

 WARNING : Only competent service personnel may carry out work involving the testing or repair of this equipment




   X-RAY RADIATION PRECAUTION
1. Excessive high voltage can prodece potentially haz-            2. The only source of X-RAY Radiation in this TV receiver
  ardous X-RAY RADIATION. To avoid such hazards,                     is the picture tube. For continued X-RAY RADIATION
  the high voltage must not exceed the specified limit.              protection, the replacement tube must be exactly the
  The nominal value of the high voltage of this receiver is          same type tube as specified in the parts list.
  29-31kv at max beam current. The high voltage must
  not, under any circumstances, exceed 35kv. (33kv :
  SAMSUNG CRT)
   Each time a receiver require servicing, the high volt-
  age should be checked. It is imprortant to use an accu-
  rate and reliable high voltage meter.


   SAFETY PRECAUTION
1. Potentials of high voltage are present when this               2. If any Fuse in this TV receiver is blown, replace it with
  receiver is operating. Operation of the receiver outside          the FUSE specified in the Replacement Parts List.
  the cabinet or with the back board removed involves a           3. When replacing a high wattage resistor ( oxide metal
  shock hazard from the receiver.                                   film resistor ) in circuit board, keep the resistor 10mm
  1) Servicing should not be attempted by anyone who is             away from circuit board.
     not thoroughly familiar with the precautions neces-          4. Keep wires away from high voltage or high tempera-
     sary when working on high-voltage equipment.                   ture components.
  2) Dischange the high potential of the picture tube             5. This receiver must operate under AC230 volts, 50Hz.
     before handling the tube. The picture tube is highly           NEVER connect to DC supply or any other power or
     evacuated and if broken, glass fragments will be               frequency.
     violently expelled.




   PRODUCT SAFETY NOTICE
   Many electrical and mechanical parts in this have                nents having such features are identified designated
   special safety-related characteristics. These charac-            symbol on the parts list.
   teristics are often passed unnoticed by a visual                 Before replacing any of these components, read the
   inspection and the X-RAY RADIATION protection                    parts list in this manual carefully. The use of substitute
   afforded by them cannot necessarily be obtained by               replacement parts which do not have the same safety
   using replacement components rated for higher volt-              characterisitics as specifide in the parts list may create
   age, wattage, etc. Replacement parts which have                  X-RAY Radiation.
   these special safety characteristics are identified in
   this manual and its supplements, electrical compo-




                                                              2
SPECIFICATIONS

PIN   Signal Designation                Matching Value
1     Audio Out (linked with 3)         0.5Vrms, Imp < 1 k (RF 60% MOD)
2     Audio In (linked with 6)          0.5Vrms, Imp < 10 k
3     Audio Out (linked with 1)         0.5Vrms, Imp < 1 k (RF 60% MOD)
4     Audio Earth
5     Blue Earth
6     Audio in (linked with 2)          0.5Vrms, Imp < 10 k (RF 60% MOD)
7     Blue in                           0.7Vpp + 2dB, Imp 75
                                               -
8     Slow (Function) Switching         TV : 0-2V, PERI : 9.5 - 12V, Imp > 10 k
9     Green Earth
10    NC
11    Green In                          0.7Vpp + 2dB, Imp 75
                                               -
12    NC
13    Red Earth
14    Rapid(Blanking) Switching Earth
15    Red In, C In                      0.7Vpp + 2dB, Imp 75
                                               -
16    Rapid(Blanking) switching         Logic 0 : 0 - 0.4V, Logic 1 : 1 - 3V, Imp 75
17    Video Earth
18    Rapid Blanking Earth
19    Video Out                         1Vpp + 2dB, Imp 75
                                             -
20    Video In, Y In                    1Vpp + 2dB, Imp 75
                                             -
21    Common Earth




                                        3
CIRCUIT BLOCK DIAGRAM




                  4
ALIGNMENT INSTRUCTIONS
User Remocon
1. R-22D06




   TV...................................TXT                 TV................................TXT


                                                            PR UP..........................PAGE UP
   VOLUME...............VOLUME                              (CURSOR UP)
   DOWN ..................DOWN
   (CURSOR LEFT)                                            VOLUME UP...........VOLUME UP
                                                            (CURSOR RIGHT)
   MENU.......................MENU
                                                            PR DOWN..............PAGE DOWN
                                                            (CURSOR DOWN)
   POWER.................POWER

                                                            NORMAL .................... Not used
   PR ......................... PAGE
   NUMBER                   NUMBER                          A V .............................. Not used
   0-9                           0-9
                                                            TXT ............................. Not used

                                                            SOUND ....................... Not used
   SLEEP...................Not used                         MODE
                                                            MUTE .......................... MUTE
   Not used................CANCEL                           Not used ...................... INDEX
   Not used................... HOLD                         Not used ....................... Size
   RECALL...............SUBPAGE                             Zoom ..................Double Window
   STILL......................REVEAL                        EFFECT ....................... Not used
   Not used ..........................R                     Not used ...................... C
   Not used ..........................G                     Not used ....................... Y




                                                  R-22D06




                                              5
                                                             ALIGNMENT INSTRUCTIONS


               IC MASTER MEMORY CONDITION TABLE FOR CP-822F CHASSIS
CONTROL           MODEL                       BASIC             W/VIRTUAL DOLBY
                  V. Slope                 -015 (const.)           -015 (const.)
                  V. Center                     955                     955
                    V.Size                       68                      68
                   S.Curve                  027 (const.)            027 (const.)
  Deflection




                  H.Center                     -333                    -333
                  H.Width                        40                      40
                  EW.Para                      -040                    -040
                EW.Cor Top                      012                     012
                EW.Cor Low                      008                     008
                  EW. Sym                      -006                    -006
                    R Bias                  330 (const.)            330 (const.)
                    G Bias                      330                     330
                    B Bias                      370                     370
                   R Drive                  400 (const.)            400 (const.)
  W/B




                   G Drive                      370                     370
                   B Drive                      370                     370
                 G2 Adjust                      000                     000
                 Sub Bright                     006                     006
                Double TEXT               -514 (can't see)        -514 (can't see)
                Wide Option                     YES                     YES
  Opt1.




                 * Tuner Is                 DWE (opt.)              DWE (opt.)
                 Flat Option                      YES                   YES
                  Svm SVG                  003 (const.)            003 (const.)
                  Svm SVD                  004 (const.)            004 (const.)
  SVM




                Svm SVDEL                  012 (const.)            012 (const.)
                Svm SVCOR                  009 (const.)            009 (const.)
                 Bcl Thres                 580 (const.)            580 (const.)
  BCL




                   Bcl Tc                  250 (const.)            250 (const.)
                  Bcl Gain                 511 (const.)            511 (const.)
                Nor1 Bright                       038                   038
  Normal 1




                 Nor1 Cont                        058                   058
                 Nor1 Color                       042                   042
                Nor1 Sharp                        032                   032
                 Nor1 Tint                        032                   032
                Nor2 Bright                       038                   038
  Normal 2




                 Nor2 Cont                        038                   038
                 Nor2 Color                       038                   038
                Nor2 Sharp                        032                   032
                 Nor2 Tint                        032                   032
  OSD Sound




                Dolby 3411                        N0                   YES

                OSD Contrast               400 (const.)            400 (const.)
                 OSD Bright                000 (const.)            000 (const.)
                 Text Gain                        YES                   YES
                 Tilt Option                      YES                   YES
  Opt2.




                Transparent                       NO                    NO
               Vertical Angle              -769 (const.)           -769 (const.)
               Vertical Bow                -769 (const.)           -769 (const.)


                  * Tuner is
       DW       DAEWOO/PARTSNIC/SAMSUNG
       PHI                  PHILIPS
       SIE                     SIEL



                                              6
ALIGNMENT INSTRUCTIONS



AFT
Standard B/G, D/K, Iand L
1) Set a Signal Generator with
  - RF FREQUENCY = 38.9 MHz,
  - RF OUTPUT LEVEL = 80 + 5dBuV
                         -
  - Pattern = Color Bar
  - System = PAL-B/G
2) Connect the Signal Generator RF Output to TP2 (Tuner IF Output).
  There must be no signal input to the tuner.
3) Set the L103 to TP1(I101, #22) with DC Voltage to 2.5V +0.1V
                                                          -

RF AGC
1) Set a TV Signal Generator(e.g. PM5418)with
    - RF FREQUENCY : 503.25 MHz, CH 25
    - RF OUTPUT LEVEL : 1 60 dBuV(TECC2949PG35W:Samsung/DT5-BF18D:Partsnic)
                             2 60 dBuV(UV1316/A:Philips/EL2782/105-B-Siel)
    - Pattern = Color Bar(or Philips patten)
2) Connect the Signal Generator RF output to Tuner input terminal.
   Connect a Oscilloscope probe(or Digital Multi-meter) to P101(Tuner AGC input).
3) Set the voltage level to 1 3.0V + 0.1Vdc, 2 2.5V + 0.1Vdc by adjusting the RB02
                                    -                -
   (Variable Resistor).

SCREEN (G2)
1) Set a Pattern Generator with - RF Frequency : 210.25MHz (10CH)
                                  - Pattern : RETMA
2) Select the "G2" in Menu
3) And a Horizontal Line will appear on the screen.
4) Adjust the SCREEN VOLUME on FBT barely to see the Horizontal Line.
5) Press the PR UP/DOWN keys to finish the SCREEN adjustment.

FOCUS
1) Apply a RETMA PATTERN signal.
2) Adjust the FOCUS VOLUME on FBT to obtain optimal resolution.

GEOMETRY
1. VERTICAL SLOPE ( Fixed : Adjust if need be )
1) Apply a RETMA PATTERN Signal.
2) Set the TV to Normal I mode.
3) Adjust the higher semicircle and the lower semicircle to be the same, with the V.Slope
  by volume Up/Down keys.

2. VERTICAL CENTER
1) Apply a RETMA PATTERN Signal.
2) Set the TV to Normal I mode.
3) Adjust the center of the picture with the V.Center by volume Up/Down keys.

                                                           7
                                                                                  ALIGNMENT INSTRUCTIONS



3. VERTICAL SIZE
* The VERTICAL CENTER adjustment has to be done in advance.
1) Apply a RETMA PATTERN Signal.
2) Set the TV to Normal I mode.
3) Adjust the VERTICAL SIZE of the picture with the select V.size by
  volume UP/DOWN keys.


4. VERTICAL S-CORRECTION ( Fixed : Adjust if need be )
1) Apply a CROSSHATCH PATTERN Signal.
2) Adjust the S-CORRECTION to obtain the same distance between
  horizontal lines with the S.Curve by volume UP/DOWN keys.


5. HORIZONTAL CENTER
1) Apply a RETMA PATTERN Signal.
2) Adjust picture centering with the select H.Center by volume UP/DOWN keys.


EW
1. WIDTH
1) Apply a RETMA PATTERN Signal.
2) Adjust the horizontal width to make a perfect circle with the select H.Width
  by volume UP/DOWN keys.


2. PARA
1) Apply a CROSSHATCH PATTERN Signal.
2) Adjust the vertical line to straight with the select E.W Para by volume
  UP/DOWN keys.


3. CORNER ( Fixed : Adjust if need be )
1) Apply a CROSSHATCH PATTERN Signal.
2) Adjust the vertical line to straight with the select EW.Cor T by volume
  UP/DOWN keys.


4. SYMMETRY ( Fixed : Adjust if need be )
1) Apply a CROSSHATCH PATTERN Signal.
2) Adjust the symmetrical balance to be suitable with the select EW Sym by
  volume UP/DOWN keys.




                                                            8
ALIGNMENT INSTRUCTIONS



WHITE BALANCE
1. RGB Reference R
                                              2
2. Beam Reference LOW ( 288, 301 : 10Cd/ m )
                                             2
                  HIGH ( 288, 301 : 100Cd/ m )
3. Adjust G, B Gain with select Menu G,B of BIAS, DRIVE of select Menu so that R, G, B Bars
   are on the center position of the analog meter. If R Analog meter is not on center, control
   the Brightness +/- of user Remocon so as R Analog meter to be on the center position.

SUB BRIGHT
1. Pattern : Retma
2. Adjust the SUB BRIGHT with the select Sub Bri by volume UP/DOWN keys.
   so that only H-Center parts of picture can be seen.

DOUBLE TEXT CENTER
1. Pattern : Pattern RED
2. Select Menu

3. Select DT in SVC menu time to see the Double Text Picture.
   ( Left : RF Picture, Right : Text Picture )

4. Change the Double Text control keys volume UP/DOWN keys so that the left edge of text
   picture concur with the right edge of RF picture.

WIDE MODE
1. Locate the cursor on `Wide' in SVC Menu.
2. `Yes' changes the display to 16:9 mode.

3. `No' change the display to 4:3 mode.

TUNER SELECTION
1. DWE : Partsnic Tuner or Samsung Tuner
2. PHI   : Philips Tuner

3. SIE   : Siel Tuner

FLAT MODE
1. Locate the cursor on `FLAT' in SVC Menu.
2. `Yes' changes the display to FLAT CRT mode.

3. `No' change the display to Normal CRT mode.




                                                    9
ALIGNMENT INSTRUCTIONS



SVM (Scan Velocity Modulation)
1. SVM SVG    : SVM Gain
2. SVM SVD     : SVM Differentiator delay (0 = filter off)
3. SVM SVDEL : Delay of SVMOUT in steps of 12.5nS
2. SVM SVCOR : SVM coring value



BCL (Beam Current Limit)
1. BCL Thres : BCL threshold current
2. BCL TC      : BCL time constant
3. BCL Gain    : BCL loop Gain




                                                      10
SCHEMATIC DIAGRAM




                    11
EXPLODED VIEW
DTA-3220ZZ/DTA-3220ZL




                        12
EXPLODED VIEW
DTA-32W9ZZ/DTA-3220ZL




                        13
PRINTED CIRCUIT BOARD
PRINTED CIRCUIT BOARD




                        15
PRINTED CIRCUIT BOARD




                        16
Part List

Caution In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need
              the latest parts information, please refer to PPL(Prats Price List) in Service information Center (http://svc.dwe.co.kr)

Caution              is a recommendable part for stock.
                     is safety component, so it must be used the same component.




 LOC      PART CODE                 PART NAME                  DESCRIPTION    REMARK        LOC     PART CODE            PART NAME               DESCRIPTION       REMARK
ZZ100   48B3822D06        TRANSMITTER REMOCON     R-22D06 (AAA)                         10        2193102005    SOLDER BAR           SN:PB=63:47 S63S-1320
ZZ110   PTACPWD546        ACCESSORY AS            DTL-29U8ZLF                           CF11      CMYH3D752J    C MYLAR              2KV BUP 7500PF J
M821    4858213801        BAG INSTRUCTION         L.D.P.E T0.05X250X400                 I101      1TDA4470M-    IC IF                TDA4470-M
ZZ120   PTBCSHD764        COVER BACK AS           DTA-3220ZZF                           I606      1MSP3410V3    IC SOUND PROCESSOR   MSP3410G-PP-B8-V3
M211    4952102201        COVER BACK              HIPS                                  I901      PTC2SW5403    HEAT SINK ASS`Y      1STV5109 + 7174300811
M781    4857817610        CLOTH BLACK             FELT 300X20X0.7                       00001     1STV5109      IC VIDEO AMP         STV5109
ZZ130   PTPKCPD764        PACKING AS              DTA-3220ZZF                           0000A     4857025403    HEAT SINK            AL050P-H24 T=2
10      6520010100        STAPLE PIN              AUTO W65                              0000B     7174300811    SCREW TAPPTITE       TT2 RND 3X8 MFZN
M681    4856812400        BAND PP AUTO            T1.1XW17mmXL770M                      IC01      1KSM9HP -     IC PREAMP            KSM-9HP
M801    4958002200        BOX CARTON              DW-4                                  IF01      1MC7812 -     IC REGULATOR         MC7812 12V 1A (KA7812)
M811    4958102500        PAD                     EPS                                   IF02      1KA4558 -     IC AMP               KA4558
M821    4958200701        BAG P.E                 FOAM T0.5X1880X1380                   IT01      1LA6515 -     IC OP AMP            LA6515
ZZ131   58GD000003        COIL DEGAUSSING         DC-3200(E)                            JZ01      4859105240    JACK PHONE           LGT1516-0100
ZZ132   49519A0110        CRT GROUND NET          DSC-3210E                             JZ02      4859105340    JACK S-VHS           YKF51-5359
ZZ140   PTCACAD764        CABINET AS              DTA-3220ZZF                           JZ03      4859105450    JACK PIN BOARD       YSC03P-4120-9S
M201A 4956000100          SCREW CRT FIX           SWRM10A L=35                          L103      58E0000041    COIL AFT             TRF-A005
M201B 4856215401          WASHER RUBBER           CR T1.0                               LED1      DSLR342MC3    LED                  SLR-342MC3
M201C 7178301212          SCREW TAPPTITE          TT2 WAS 3X12 MFZN BK                  LED2      DSLR342VC3    LED                  SLR-342VC3
M201D 7178301212          SCREW TAPPTITE          TT2 WAS 3X12 MFZN BK                  LF01      58CD000009    COIL CHOKE           920UH
M211A 7172401612          SCREW TAPPTITE          TT2 TRS 4X16 MFZN BK                  M232      4952300701    PANEL AV             HIPS PAINT
M211B 7178301212          SCREW TAPPTITE          TT2 WAS 3X12 MFZN BK                  M232A 7178301212        SCREW TAPPTITE       TT2 WAS 3X12 MFZN BK
M211C 7172401612          SCREW TAPPTITE          TT2 TRS 4X16 MFZN BK                  M321      4953200600    BRKT POWER           EGI T1.2
M211D 7172401612          SCREW TAPPTITE          TT2 TRS 4X16 MFZN BK                  M321A 7063300612        SCREW MACHINE        M/C BIN 3X6 MFZN BK
M231    4952301301        PANEL CTRL              HIPS PAINT                            M491      4954901601    BUTT0N CH            ABS PAINT
M353    4853535600        HOLDER CORD             NYLON 66                              M551      4955501000    DECO SENSOR          GPPS
M481    4954801001        BUTTON POWER            ABS PAINT                             M684      4856812001    TIE CABLE            NYLON66 DA100
M481A 4856716000          SPRING                  SWPA PIE0.5                           P106      4853946000    BRKT JUMPER A        SECC T1.0 (VCR-63DB)
M491A 7178301212          SCREW TAPPTITE          TT2 WAS 3X12 MFZN BK                  P107      4853946000    BRKT JUMPER A        SECC T1.0 (VCR-63DB)
M541    4955400100        SPEC PLATE              P.E FILM 91.5X63                      P108      4859279520    CONN WAFER           TAC-L15P-A3 (ANGLE)
M681    4856812001        TIE CABLE               NYLON66 DA100                         P109      4859279820    CONN WAFER           TAC-L18P-A3 (ANGLE)
M682    4856816300        CLAMP WIRE              NYLON 6 (V0)                          P603A     4850704S04    CONNECTOR            YH025-04+YST025+ULW=400
P405    4850706N14        CONNECTOR               YFSH500-06+YH396V+ULW=600             P701A     4850708S02    CONNECTOR            YH025-08+YST025+ULW=300
P601A   4850704S30        CONNECTOR               YH025-04+YRT205+ULW700600             P803      4850702S09    CONNECTOR            BL102NG+MXH40058-02=300
SP01    4858315610        SPEAKER                 SP-5090F13                            P901      4859238620    CONN WAFER           YPW500-02
SP01A   7178301212        SCREW TAPPTITE          TT2 WAS 3X12 MFZN BK                  P902      4850703N24    CONNECTOR            EHR-03+YBNH250-03+ULW=200
SP02    4858315610        SPEAKER                 SP-5090F13                            PA01A     4850709N07    CONNECTOR            YH025-09+YBNH250-09+USW=600
SP02A   7178301212        SCREW TAPPTITE          TT2 WAS 3X12 MFZN BK                  PD06A 4850712N02        CONNECTOR            YH025-12+YBNH250+USW=500
V901    4959601270        CPT                     W76ERF042X044                         PF02      4859238620    CONN WAFER           YPW500-02
ZZ200   PTFMSJD764        MASK FRONT AS           DTA-3220ZZF                           PF3       4850702N06    CONNECTOR            YPH500-02+YLT500+ULW=200
M201    4952002401        MASK FRONT              HIPS PAINT                            PT02      4850703S21    CONNECTOR            YH025-03+YBNH250+ULW=600
M201D 7178301212          SCREW TAPPTITE          TT2 WAS 3X12 MFZN BK                  Q908      PTF2SW6900    HEAT SINK ASS`Y      TKTA1659AY + 7178301011
M201E 4857817610          CLOTH BLACK             FELT 300X20X0.7                       00001     TKTA1659AY    TR                   KTA1659AY
M561    4855617400        MARK BRAND              CU AU+ABS BK                          0000A     4857026900    HEAT SINK            AL EX
ZZ202   PTU1MSD764        PCB UNION-1 MANUAL AS   DTA-3220ZZF                           0000B     7174300811    SCREW TAPPTITE       TT2 RND 3X8 MFZN




                                                                                       17
                                                                                                                                Part List



LOC       PART CODE            PART NAME                 DESCRIPTION    REMARK        LOC     PART CODE            PART NAME              DESCRIPTION      REMARK
Q909    PT62SW6900    HEAT SINK ASS Y       TKTC4370AY + 7178301011               C639      CEXF1H109V    C ELECTRO            50V RSS 1MF (5X11) TP
00001   TKTC4370AY    TR                    KTC4370AY                             C640      CEXF1H109V    C ELECTRO            50V RSS 1MF (5X11) TP
0000A   4857026900    HEAT SINK             AL EX                                 C641      CEXF1H109V    C ELECTRO            50V RSS 1MF (5X11) TP
0000B   7174300811    SCREW TAPPTITE        TT2 RND 3X8 MFZN                      C643      CEXF1H339V    C ELECTRO            50V RSS 3.3MF (5X11) TP
QF04    T4636LSRB-    TR                    2SC4636LS-RB                          C644      CEXF1H100V    C ELECTRO            50V RSS 10MF (5X11) TP
SCT1    4859303730    SOCKET CRT            ISD-07S                               C645      CEXF1E470V    C ELECTRO            25V RSS 47MF (5X11) TP
SF01    5PK3953M      FILTER SAW            K3953M                                C646      CEXF1H100V    C ELECTRO            50V RSS 10MF (5X11) TP
SF02    5PK9650M      FILTER SAW            K9650M                                C647      CEXF1H100V    C ELECTRO            50V RSS 10MF (5X11) TP
SW801 5S40000003      SW POWER PUSH         SS-160-7-G                            C648      CEXF1H479V    C ELECTRO            50V RSS 4.7MF (5X11) TP
TF01    50D28A1 -     TRANS DRIVE           TD-28A1                               C649      CEXF1H479V    C ELECTRO            50V RSS 4.7MF (5X11) TP
ZZ200   PTU1J0D764    PCB UNION RHU AS      DTA-3220ZZF                           C650      CEXF1H479V    C ELECTRO            50V RSS 4.7MF (5X11) TP
C908    CEXF2E100V    C ELECTRO             250V RSS 10MF (10X20) TP              C651      CEXF1H479V    C ELECTRO            50V RSS 4.7MF (5X11) TP
C909    CCXB3D102K    C CERA                2KV B 1000PF K (TAPPING)              C652      CCXB1H102K    C CERA               50V B 1000PF K (TAPPING)
C913    CEXF2E100V    C ELECTRO             250V RSS 10MF (10X20) TP              C653      CCXB1H102K    C CERA               50V B 1000PF K (TAPPING)
C922    CCXB2H472K    C CERA                500V B 4700PF K (TAPPING)             C654      CCXB1H102K    C CERA               50V B 1000PF K (TAPPING)
C923    CCXB2H472K    C CERA                500V B 4700PF K (TAPPING)             C658      CEXF1H100V    C ELECTRO            50V RSS 10MF (5X11) TP
C925    CEXF2E100V    C ELECTRO             250V RSS 10MF (10X20) TP              C901      CEXF1H100V    C ELECTRO            50V RSS 10MF (5X11) TP
C941    CEXF2C470V    C ELECTRO             160V RSS 47MF (13X25) TP              C902      CMXM2A104K    C MYLAR              100V 0.1MF K (TP)
C942    CEXF2E100V    C ELECTRO             250V RSS 10MF (10X20) TP              C904      CXSL2H471J    C CERA               500V SL 470PF J (TAPPING)
C943    CEXF2C470V    C ELECTRO             160V RSS 47MF (13X25) TP              C905      CXSL2H471J    C CERA               500V SL 470PF J (TAPPING)
C945    CEXF2E100V    C ELECTRO             250V RSS 10MF (10X20) TP              C906      CXSL2H471J    C CERA               500V SL 470PF J (TAPPING)
CF02    CMXE2J333J    C MYLAR               630V PU 0.033MF J (TP)                C912      CMXL2E104J    C MYLAR              MEU 250V 0.1MF J
CF05    CMXE2J333J    C MYLAR               630V PU 0.033MF J (TP)                C915      CMXM2A822J    C MYLAR              100V 8200PF J (TP)
CF07    CMXE2J333J    C MYLAR               630V PU 0.033MF J (TP)                C916      CEXF1E470V    C ELECTRO            25V RSS 47MF (5X11) TP
CF10    CMXE2J333J    C MYLAR               630V PU 0.033MF J (TP)                C920      CEXF1E470V    C ELECTRO            25V RSS 47MF (5X11) TP
ZZ200   PTU1JBD764    PCB UNION M-10 AS     DTA-3220ZZF                           C921      CCXB1H101K    C CERA               50V B 100PF K (TAPPING)
P401    485923172S    CONN WAFER            YW025-04 (STICK)                      C924      CCXB1H101K    C CERA               50V B 100PF K (TAPPING)
P402    485923162S    CONN WAFER            YW025-03 (STICK)                      C944      CXSL2H560J    C CERA               500V SL 56PF J (TAPPING)
PF01    485923202S    CONN WAFER            YW025-07 (STICK)                      CF01      CEXF1C221V    C ELECTRO            16V RSS 220MF (8X11.5) TP
PT01    485923162S    CONN WAFER            YW025-03 (STICK)                      CF04      CEXF1E101V    C ELECTRO            25V RSS 100MF (6.3X11) TP
R904    RS02Z563JS    R M-OXIDE FILM        2W 56K OHM J SMALL                    CF06      CEXF1E101V    C ELECTRO            25V RSS 100MF (6.3X11) TP
R907    RS02Z563JS    R M-OXIDE FILM        2W 56K OHM J SMALL                    CF08      CEXF1E101V    C ELECTRO            25V RSS 100MF (6.3X11) TP
R910    RS02Z563JS    R M-OXIDE FILM        2W 56K OHM J SMALL                    CF09      CEXF1E101V    C ELECTRO            25V RSS 100MF (6.3X11) TP
R954    RF02Z249J-    R FUSIBLE             2W 2.4 OHM J (TAPPING)                CF12      CEXF1E470V    C ELECTRO            25V RSS 47MF (5X11) TP
RF19    RF02Z479J-    R FUSIBLE             2W 4.7 OHM J (TAPPING)                CF13      CEXF1C221V    C ELECTRO            16V RSS 220MF (8X11.5) TP
RF20    RS01Z472J-    R M-OXIDE FILM        1W 4.7K OHM J (TAPPING)               CF14      CEXF1E101V    C ELECTRO            25V RSS 100MF (6.3X11) TP
RF21    RS01Z228J-    R M-OXIDE FILM        1W 0.22 OHM J                         CT01      CMXL1J474J    C MYLAR              63V MEU 0.47MF J
ZZ200   PTU1JRD764    PCB UNION RADIAL AS   DTA-3220ZZF                           CT02      CMXL1J474J    C MYLAR              63V MEU 0.47MF J
C100    CXRH1H150J    C CERA                RH 50V 15PF J (TAPPING)               CT03      CEXF1E470V    C ELECTRO            25V RSS 47MF (5X11) TP
C108    CXCH1H220J    C CERA                50V CH 22PF J (TAPPING)               CT11      CEXF1H100V    C ELECTRO            50V RSS 10MF (5X11) TP
C111    CXCH1H220J    C CERA                50V CH 22PF J (TAPPING)               G901      4SG0DX0001    SPARK GAP            SSG-102-A1(1.0KV) TAP
C114    CEXF1E470C    C ELECTRO             25V RUS 47MF (5X11) TP                G902      4SG0DX0001    SPARK GAP            SSG-102-A1(1.0KV) TAP
C116    CEXF1H478V    C ELECTRO             50V RSS 0.47MF (5X11) TP              G903      4SG0DX0001    SPARK GAP            SSG-102-A1(1.0KV) TAP
C118    CEXF1H229V    C ELECTRO             50V RSS 2.2MF (5X11) TP               G904      4SG0DX0001    SPARK GAP            SSG-102-A1(1.0KV) TAP
C122    CEXF1H229V    C ELECTRO             50V RSS 2.2MF (5X11) TP               JZ05      5PXF1B471M    FILTER EMI           CFI 06 B 1H 470PF
C123    CEXF1H100V    C ELECTRO             50V RSS 10MF (5X11) TP                JZ06      5PXF1B471M    FILTER EMI           CFI 06 B 1H 470PF
C630    CXCH1H309C    C CERA                50V CH 3PF C                          L904      58C0000116    COIL BEAD            HC-3550R
C631    CXCH1H309C    C CERA                50V CH 3PF C                          Q104      TKTC3197      TR                   KTC3197 (TP)
C632    CCXF1H223Z    C CERA                50V F 0.022MF Z (TAPPING)             Q105      TKTC3198Y-    TR                   KTC3198Y
C634    CEXF1H100V    C ELECTRO             50V RSS 10MF (5X11) TP                Q106      TKTC3198Y-    TR                   KTC3198Y
C636    CEXF1H109V    C ELECTRO             50V RSS 1MF (5X11) TP                 Q107      TKTC3198Y-    TR                   KTC3198Y
C637    CEXF1H109V    C ELECTRO             50V RSS 1MF (5X11) TP                 Q901      TKTC3198Y-    TR                   KTC3198Y
C638    CEXF1H109V    C ELECTRO             50V RSS 1MF (5X11) TP                 Q902      TKTC3198Y-    TR                   KTC3198Y




                                                                                 18
Part List



LOC       PART CODE            PART NAME              DESCRIPTION       REMARK        LOC     PART CODE           PART NAME            DESCRIPTION       REMARK
Q903    TKTC3198Y-    TR                   KTC3198Y                               D909      D1N4148 -     DIODE               1N4148 (TAPPING)
Q904    TKTC3198Y-    TR                   KTC3198Y                               D910      D1N4148 -     DIODE               1N4148 (TAPPING)
Q905    TKTC3198Y-    TR                   KTC3198Y                               D911      DEU1Z -       DIODE               EU1Z (HIGH SPEED)
Q906    TKTC3198Y-    TR                   KTC3198Y                               D912      DEU1Z -       DIODE               EU1Z (HIGH SPEED)
Q907    TKTA1266Y-    TR                   KTA1266Y (TP)                          D920      D1N4937G      DIODE               1N4937G (TAPPING)
QF01    TKTA1266Y-    TR                   KTA1266Y (TP)                          D921      D1N4937G      DIODE               1N4937G (TAPPING)
QF02    TKTA1266Y-    TR                   KTA1266Y (TP)                          D922      D1N4937G      DIODE               1N4937G (TAPPING)
QF03    TKTC3198Y-    TR                   KTC3198Y                               DF01      D1N4937G      DIODE               1N4937G (TAPPING)
QT01    TKTC3198Y-    TR                   KTC3198Y                               DF02      D1N4937G      DIODE               1N4937G (TAPPING)
R951    RN01B102JS    R METAL FILM         1W 1K OHM J SMALL                      DF03      D1N4937G      DIODE               1N4937G (TAPPING)
R953    RN02B331JS    R METAL FILM         2W 330 OHM J SMALL                     DF04      D1N4937G      DIODE               1N4937G (TAPPING)
R956    RN02B100JS    R METAL FILM         2W 10 OHM J SMALL                      DT02      D1N4148 -     DIODE               1N4148 (TAPPING)
RB02    RV5426103P    R SEMI FIXED         ENV-DJAA03B14 10K OHM B                J151      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
RF24    RN02B683JS    R METAL FILM         2W 68K OHM J SMALL                     J152      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
RF25    RN02B333JS    R METAL FILM         2W 33K OHM J SMALL                     J153      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
RF26    RN02B683JS    R METAL FILM         2W 68K OHM J SMALL                     J154      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
SW701 5S50101Z90      SW TACT              THVV502GDA                             J155      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
SW702 5S50101Z90      SW TACT              THVV502GDA                             J156      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
SW703 5S50101Z90      SW TACT              THVV502GDA                             J157      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
SW704 5S50101Z90      SW TACT              THVV502GDA                             J159      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
SW705 5S50101Z90      SW TACT              THVV502GDA                             J160      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
X601    5XEX18R43E    CRYSTAL QUARTZ       HC-49/U 18.432MHZ 30PPM TP             J161      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
ZZ200   PTU1JAD764    PCB UNION AXIAL AS   DTA-3220ZZF                            J165      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
10      2TM14006LB    TAPE MASKING         3M #232 6.0X2000M                      J167      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
20      2TM10006LB    TAPE MASKING         3M #232-MAP-C 6.2X2000M                J169      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
A001    4859809660    PCB UNION            330X246 D1B                            J170      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
C109    CCZB1H102K    C CERA               50V B 1000PF K (AXIAL)                 J171      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
C110    CCZF1H103Z    C CERA               50V F 0.01MF Z                         J172      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
C112    CZSL1H470J    C CERA               50V SL 47PF J (AXIAL)                  J651      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
C113    CCZF1H103Z    C CERA               50V F 0.01MF Z                         J652      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
C115    CCZF1H103Z    C CERA               50V F 0.01MF Z                         J653      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
C117    CCZF1H103Z    C CERA               50V F 0.01MF Z                         J654      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
C119    CBZF1H104Z    C CERA SEMI          50V F 0.1MF Z                          J655      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
C120    CBZF1H104Z    C CERA SEMI          50V F 0.1MF Z                          J656      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
C121    CCZF1H103Z    C CERA               50V F 0.01MF Z                         J657      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
C124    CCZF1H103Z    C CERA               50V F 0.01MF Z                         J658      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
C633    CCZB1H102K    C CERA               50V B 1000PF K (AXIAL)                 J659      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
C635    CBZF1H104Z    C CERA SEMI          50V F 0.1MF Z                          J660      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
C642    CBZF1H104Z    C CERA SEMI          50V F 0.1MF Z                          J661      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
C656    CCZB1H102K    C CERA               50V B 1000PF K (AXIAL)                 J662      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
C657    CCZB1H102K    C CERA               50V B 1000PF K (AXIAL)                 J663      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
C917    CCZB1H391K    C CERA               50V B 390PF K (AXIAL)                  J664      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
C918    CCZF1H103Z    C CERA               50V F 0.01MF Z                         J665      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
C919    CCZB1H102K    C CERA               50V B 1000PF K (AXIAL)                 J666      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
CC01    CBZF1H104Z    C CERA SEMI          50V F 0.1MF Z                          J667      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
CT05    CBZF1H104Z    C CERA SEMI          50V F 0.1MF Z                          J668      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
CZ01    CCZB1H561K    C CERA               50V B 560PF K                          J669      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
CZ02    CCZB1H561K    C CERA               50V B 560PF K                          J670      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
D102    DBA282        DIODE                BA282                                  J672      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
D904    DLT2A05G      DIODE                LT2A05G (TP)                           J901      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
D906    D1N4148 -     DIODE                1N4148 (TAPPING)                       J902      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
D907    D1N4148 -     DIODE                1N4148 (TAPPING)                       J904      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING
D908    D1N4148 -     DIODE                1N4148 (TAPPING)                       J906      85801065GY    WIRE COPPER         AWG22 1/0.65 TIN COATING




                                                                                 19
                                                                                                                         Part List



LOC      PART CODE          PART NAME             DESCRIPTION      REMARK        LOC     PART CODE          PART NAME              DESCRIPTION   REMARK
J907   85801065GY    WIRE COPPER        AWG22 1/0.65 TIN COATING             R909      RD-AZ392J-    R CARBON FILM      1/6 3.9K OHM J
J908   85801065GY    WIRE COPPER        AWG22 1/0.65 TIN COATING             R911      RD-AZ271J-    R CARBON FILM      1/6 270 OHM J
J909   85801065GY    WIRE COPPER        AWG22 1/0.65 TIN COATING             R912      RD-AZ392J-    R CARBON FILM      1/6 3.9K OHM J
J910   85801065GY    WIRE COPPER        AWG22 1/0.65 TIN COATING             R913      RD-AZ221J-    R CARBON FILM      1/6 220 OHM J
J913   85801065GY    WIRE COPPER        AWG22 1/0.65 TIN COATING             R914      RD-AZ101J-    R CARBON FILM      1/6 100 OHM J
J914   85801065GY    WIRE COPPER        AWG22 1/0.65 TIN COATING             R915      RD-AZ221J-    R CARBON FILM      1/6 220 OHM J
J915   85801065GY    WIRE COPPER        AWG22 1/0.65 TIN COATING             R916      RD-AZ101J-    R CARBON FILM      1/6 100 OHM J
J916   85801065GY    WIRE COPPER        AWG22 1/0.65 TIN COATING             R917      RD-AZ221J-    R CARBON FILM      1/6 220 OHM J
J918   85801065GY    WIRE COPPER        AWG22 1/0.65 TIN COATING             R918      RD-AZ101J-    R CARBON FILM      1/6 100 OHM J
J919   85801065GY    WIRE COPPER        AWG22 1/0.65 TIN COATING             R919      RC-2Z102K-    R CARBON COMP      1/2 1K OHM K
J920   85801065GY    WIRE COPPER        AWG22 1/0.65 TIN COATING             R920      RC-2Z102K-    R CARBON COMP      1/2 1K OHM K
J930   85801065GY    WIRE COPPER        AWG22 1/0.65 TIN COATING             R921      RC-2Z102K-    R CARBON COMP      1/2 1K OHM K
JC01   85801065GY    WIRE COPPER        AWG22 1/0.65 TIN COATING             R922      RD-2Z100J-    R CARBON FILM      1/2 10 OHM J
JF01   85801065GY    WIRE COPPER        AWG22 1/0.65 TIN COATING             R923      RD-AZ222J-    R CARBON FILM      1/6 2.2K OHM J
JF03   85801065GY    WIRE COPPER        AWG22 1/0.65 TIN COATING             R924      RD-AZ102J-    R CARBON FILM      1/6 1K OHM J
JF04   85801065GY    WIRE COPPER        AWG22 1/0.65 TIN COATING             R925      RD-AZ471J-    R CARBON FILM      1/6 470 OHM J
JF05   85801065GY    WIRE COPPER        AWG22 1/0.65 TIN COATING             R926      RD-2Z471J-    R CARBON FILM      1/2 470 OHM J
JF06   85801065GY    WIRE COPPER        AWG22 1/0.65 TIN COATING             R927      RD-AZ121J-    R CARBON FILM      1/6 120 OHM J
JZ04   85801065GY    WIRE COPPER        AWG22 1/0.65 TIN COATING             R928      RD-AZ223J-    R CARBON FILM      1/6 22K OHM J
L110   5CPZ479K02    COIL PEAKING       4.7UH K (AXIAL 3.5MM)                R929      RD-AZ273J-    R CARBON FILM      1/6 27K OHM J
L630   5CPZ109M02    COIL PEAKING       1UH M (AXIAL 3.5MM)                  R930      RD-AZ333J-    R CARBON FILM      1/6 33K OHM J
L631   5CPZ109M02    COIL PEAKING       1UH M (AXIAL 3.5MM)                  R932      RD-AZ392J-    R CARBON FILM      1/6 3.9K OHM J
L632   5CPZ479K02    COIL PEAKING       4.7UH K (AXIAL 3.5MM)                R933      RD-AZ392J-    R CARBON FILM      1/6 3.9K OHM J
L901   5MC0000100    COIL BEAD          HC-3550                              R934      RD-AZ393J-    R CARBON FILM      1/6 39K OHM J
L902   5MC0000100    COIL BEAD          HC-3550                              R935      RD-AZ563J-    R CARBON FILM      1/6 56K OHM J
L903   5MC0000100    COIL BEAD          HC-3550                              R936      RD-AZ103J-    R CARBON FILM      1/6 10K OHM J
LT01   5CPZ569K02    COIL PEAKING       5.6UH K (AXIAL 3.5MM)                R937      RD-AZ820J-    R CARBON FILM      1/6 82 OHM J
R112   RD-AZ153J-    R CARBON FILM      1/6 15K OHM J                        R938      RD-2Z100J-    R CARBON FILM      1/2 10 OHM J
R113   RD-AZ222J-    R CARBON FILM      1/6 2.2K OHM J                       R939      RD-AZ820J-    R CARBON FILM      1/6 82 OHM J
R114   RD-AZ751J-    R CARBON FILM      1/6 750 OHM J                        R940      RD-AZ122J-    R CARBON FILM      1/6 1.2K OHM J
R115   RD-AZ101J-    R CARBON FILM      1/6 100 OHM J                        R941      RD-AZ152J-    R CARBON FILM      1/6 1.5K OHM J
R116   RD-AZ682J-    R CARBON FILM      1/6 6.8K OHM J                       R942      RD-AZ683J-    R CARBON FILM      1/6 68K OHM J
R117   RD-AZ222J-    R CARBON FILM      1/6 2.2K OHM J                       R943      RD-AZ683J-    R CARBON FILM      1/6 68K OHM J
R118   RD-AZ103J-    R CARBON FILM      1/6 10K OHM J                        R944      RD-AZ123J-    R CARBON FILM      1/6 12K OHM J
R119   RD-AZ563J-    R CARBON FILM      1/6 56K OHM J                        R945      RD-AZ122J-    R CARBON FILM      1/6 1.2K OHM J
R120   RD-AZ562J-    R CARBON FILM      1/6 5.6K OHM J                       R946      RD-AZ152J-    R CARBON FILM      1/6 1.5K OHM J
R121   RD-AZ223J-    R CARBON FILM      1/6 22K OHM J                        R947      RD-2Z620J-    R CARBON FILM      1/2 62 OHM J
R122   RD-AZ472J-    R CARBON FILM      1/6 4.7K OHM J                       R948      RD-2Z279J-    R CARBON FILM      1/2 2.7 OHM J
R123   RD-AZ102J-    R CARBON FILM      1/6 1K OHM J                         R950      RD-2Z279J-    R CARBON FILM      1/2 2.7 OHM J
R124   RD-AZ153J-    R CARBON FILM      1/6 15K OHM J                        R952      RD-2Z620J-    R CARBON FILM      1/2 62 OHM J
R125   RD-AZ153J-    R CARBON FILM      1/6 15K OHM J                        R955      RD-AZ182J-    R CARBON FILM      1/6 1.8K OHM J
R126   RD-AZ472J-    R CARBON FILM      1/6 4.7K OHM J                       R957      RD-4Z105J-    R CARBON FILM      1/4 1M OHM J
R127   RD-AZ151J-    R CARBON FILM      1/6 150 OHM J                        R958      RD-2Z102J-    R CARBON FILM      1/2 1K OHM J
R128   RD-AZ472J-    R CARBON FILM      1/6 4.7K OHM J                       RC01      RD-AZ153J-    R CARBON FILM      1/6 15K OHM J
R129   RD-AZ472J-    R CARBON FILM      1/6 4.7K OHM J                       RC02      RD-AZ392J-    R CARBON FILM      1/6 3.9K OHM J
R130   RN-AZ1502F    R METAL FILM       1/6 15K OHM F                        RC03      RD-AZ182J-    R CARBON FILM      1/6 1.8K OHM J
R131   RN-AZ5101F    R METAL FILM       1/6 5.1K OHM F                       RC04      RD-AZ132J-    R CARBON FILM      1/6 1.3K OHM J
R630   RD-AZ101J-    R CARBON FILM      1/6 100 OHM J                        RF01      RD-4Z431J-    R CARBON FILM      1/4 430 OHM J
R631   RD-AZ101J-    R CARBON FILM      1/6 100 OHM J                        RF02      RD-4Z561J-    R CARBON FILM      1/4 560 OHM J
R901   RD-AZ431J-    R CARBON FILM      1/6 430 OHM J                        RF03      RD-4Z332J-    R CARBON FILM      1/4 3.3K OHM J
R905   RD-AZ271J-    R CARBON FILM      1/6 270 OHM J                        RF04      RD-4Z682J-    R CARBON FILM      1/4 6.8K OHM J
R906   RD-AZ392J-    R CARBON FILM      1/6 3.9K OHM J                       RF05      RD-4Z911J-    R CARBON FILM      1/4 910 OHM J
R908   RD-AZ271J-    R CARBON FILM      1/6 270 OHM J                        RF06      RD-4Z221J-    R CARBON FILM      1/4 220 OHM J




                                                                            20
Part List



LOC       PART CODE           PART NAME               DESCRIPTION      REMARK        LOC     PART CODE            PART NAME               DESCRIPTION   REMARK
RF07    RD-4Z182J-    R CARBON FILM        1/4 1.8K OHM J                        D828      D1N4937G      DIODE                1N4937G (TAPPING)
RF08    RD-4Z123J-    R CARBON FILM        1/4 12K OHM J                         F801      5FSCB4022R    FUSE CERA            SEMKO F4AH 4A 250V MF51
RF09    RD-4Z103J-    R CARBON FILM        1/4 10K OHM J                         I301      PTC2SW8218    HEAT SINK ASS`Y      1TDA8172 + 7174300811
RF10    RD-4Z103J-    R CARBON FILM        1/4 10K OHM J                         00001     1TDA8172      IC V-OUT             TDA8172
RF11    RD-4Z911J-    R CARBON FILM        1/4 910 OHM J                         0000A     4857028218    HEAT SINK            AL EX BK
RF12    RD-4Z513J-    R CARBON FILM        1/4 51K OHM J                         0000B     7174300811    SCREW TAPPTITE       TT2 RND 3X8 MFZN
RF13    RD-4Z103J-    R CARBON FILM        1/4 10K OHM J                         I601      PTA2SW8224    HEAT SINK ASS`Y      1TDA7269 7174300811
RF14    RD-4Z820J-    R CARBON FILM        1/4 82 OHM J                          00001     1TDA7269      IC AUDIO             TDA7269
RF15    RD-4Z103J-    R CARBON FILM        1/4 10K OHM J                         0000A     4857028224    HEAT SINK            AL EX
RF16    RD-4Z153J-    R CARBON FILM        1/4 15K OHM J                         0000B     7174300811    SCREW TAPPTITE       TT2 RND 3X8 MFZN
RF17    RD-4Z272J-    R CARBON FILM        1/4 2.7K OHM J                        I605      1KA4558 -     IC AMP               KA4558
RF18    RD-4Z132J-    R CARBON FILM        1/4 1.3K OHM J                        I701      1ST195EPM-    IC MICOM OTP         ST92T195B1/EPM
RF27    RD-4Z221J-    R CARBON FILM        1/4 220 OHM J                         I702      1AT24C16PC    IC                   AT24C16-10PC
RT01    RD-2Z100J-    R CARBON FILM        1/2 10 OHM J                          I801      PTG2SW8200    HEAT SINK ASS`Y      1STRF6656- + 7174301011
RT02    RD-AZ683J-    R CARBON FILM        1/6 68K OHM J                         00001     1STRF6656-    IC POWER             STR-F6656
RT03    RD-AZ334J-    R CARBON FILM        1/6 330K OHM J                        0000A     4857028200    HEAT SINK            AL EX BK
RT04    RD-AZ392J-    R CARBON FILM        1/6 3.9K OHM J                        0000B     7174301011    SCREW TAPPTITE       TT2 RND 3X10 MFZN
RT05    RD-2Z100J-    R CARBON FILM        1/2 10 OHM J                          I802      1KP1010C      IC PHOTO COUPLER     KP-1010C
RT06    RD-AZ683J-    R CARBON FILM        1/6 68K OHM J                         I803      1SE140N -     IC AMP               SE140N
RT07    RD-AZ563J-    R CARBON FILM        1/6 56K OHM J                         I804      PSH2SW6900    HEAT SINK ASS Y      1KA7805 - + 7174301011
RT08    RD-AZ103J-    R CARBON FILM        1/6 10K OHM J                         00001     1KA7805 -     IC REGULATOR         KA7805
RT09    RD-AZ222J-    R CARBON FILM        1/6 2.2K OHM J                        0000A     4857026900    HEAT SINK            AL EX
RT10    RD-AZ472J-    R CARBON FILM        1/6 4.7K OHM J                        0000B     7174301011    SCREW TAPPTITE       TT2 RND 3X10 MFZN
RT14    RD-AZ222J-    R CARBON FILM        1/6 2.2K OHM J                        I805      PTA2SW7720    HEAT SINK ASS`Y      1K78R05 - + 7174300811
ZZ290   PTMPMSD764    PCB MAIN MANUAL AS   DTA-3220ZZF                           00001     1K78R05 -     IC REGULATOR         KIA78R05API
10      2193102005    SOLDER BAR           SN:PB=63:47 S63S-1320                 0000A     4857027720    HEAT SINK            AL EX
30      2291050616    FLUX SOLDER          JS-64T3                               0000B     7174300811    SCREW TAPPTITE       TT2 RND 3X8 MFZN
40      2291050301    FLUX SOLVENT         IM-1000                               I807      1MC7812 -     IC REGULATOR         MC7812 12V 1A (KA7812)
C405    CMYH3C432J    C MYLAR              1.6KV BUP 4300PF J                    I808      1KA7808 -     IC REGULATOR         KA7808
C406    CMYH3C702J    C MYLAR              1.6KV BUP 7000PF J                    I810      TX0202DA      THYRISTOR            X0202DA1BA2
C407    CMYE2J223J    C MYLAR              630V PU 0.022MF J                     IA01      1MM1118 -     IC A/V SWITCH        MM1118
C408    CMYE2G184J    C MYLAR              400V PU 0.18MF J                      JPA01     4959103680    JACK SCART           DSAM-0266
C410    CEYD1H689W    C ELECTRO            50V RHD 6.8MF (16X35.5)               JPA02     4959103680    JACK SCART           DSAM-0266
C441    CMYL2G104J    C MYLAR              400V MEU 0.1MF J                      L401      58H0000085    COIL H-LINEARITY     TRL-5R0D
C443    CMXF2G124J    C MYLAR              400V MPP 0.12MF J                     L403      58C0000130    COIL CHOKE           CH-161A
C801    CL1UC3474M    C LINE ACROSS        0.47MF 1J(UCVSNDF/SV)+Q/O             LF100     5PLF24A3      FILTER LINE          LF-24A3
C802    CL1UC3474M    C LINE ACROSS        0.47MF 1J(UCVSNDF/SV)+Q/O             LF200     58C0000129    COIL CHOKE PFC       CPC-201B
C807    CMYF2J154J    C MYLAR              630V MPP 0.15MF J                     M207      4853535500    HOLDER AC CORD       NYLON 66
C809    CEYN2W221P    C ELECTRO            450V LHS 220MF (30X40)                M351      4953500100    HOLDER CORD          FR HIPS
C817    CH1BFE472M    C CERA AC            AC400V 4700PF M U/C/V                 M351A 7172401612        SCREW TAPPTITE       TT2 TRS 4X16 MFZN BK
C820    CEYF1E332V    C ELECTRO            25V RSS 3300MF (16X31.5)              M381      4953802800    FRAME MAIN PCB       FR HIPS BK
C828    CEYE2D221E    C ELECTRO            200V RM 220MF (18X35.5)               M381A 7178301212        SCREW TAPPTITE       TT2 WAS 3X12 MFZN BK
C829    CEYE2D331E    C ELECTRO            200V RM 330MF                         M381B 7178301212        SCREW TAPPTITE       TT2 WAS 3X12 MFZN BK
D401    DDTV32D -     DIODE                DTV32D                                M683      4856812001    TIE CABLE            NYLON66 DA100
D805    DRL4A015      DIODE                RL4A-015-308                          P103      4859281020    CONN WAFER           TAC-L15X-A3
D806    DRL4A015      DIODE                RL4A-015-308                          P104      4859281320    CONN WAFER           TAC-L18X-A3
D820    DFMLG12S      DIODE                FML-G12S                              P401A     4850704S03    CONNECTOR            YH025-04+YST025+ULW=300
D821    DFMLG12S      DIODE                FML-G12S                              P402A     4850703S29    CONNECTOR            YH025-03+YST025+USW=300
D824    PTP2SW6900    HEAT SINK ASS`Y      DFMLG12S + 7174300811                 P405      4859240120    CONN WAFER           YFW500-06
00001   DFMLG12S      DIODE                FML-G12S                              P503      4859281320    CONN WAFER           TAC-L18X-A3
0000A   4857026900    HEAT SINK            AL EX                                 P504      4859281020    CONN WAFER           TAC-L15X-A3
0000B   7174300811    SCREW TAPPTITE       TT2 RND 3X8 MFZN                      P801      4859242220    CONN WAFER           YFW800-02
D827    DRGP30J -     DIODE                RGP30J DO-201AD 600V 3A               P802      4859242220    CONN WAFER           YFW800-02




                                                                                21
                                                                                                                                Part List



LOC       PART CODE            PART NAME               DESCRIPTION     REMARK        LOC     PART CODE             PART NAME              DESCRIPTION     REMARK
P803    4859242220    CONN WAFER           YFW800-02                             C842      CEXF1C471V    C ELECTRO             16V RSS 470MF (8X12)TP
PD03A 4850703S29      CONNECTOR            YH025-03+YST025+USW=300               C843      CEXF1H331V    C ELECTRO             50V RSS 330MF (10X20) TP
PF01    4850707S02    CONNECTOR            YH025-07+YST025+ULW=400               C846      CEXF1E471V    C ELECTRO             25V RSS 470MF (10X16) TP
PF03    4859238620    CONN WAFER           YPW500-02                             ZZ200     PTMPJBD764    PCB MAIN M-10 AS      DTA-3220ZZF
PW000 4859903110      CORD POWER AS        KKP-419J-H03VVH2+H0U=2200             10        2TM18006BE    TAPE MASKING          6.2X500
A000    4859903511    CORD POWER           CW4232 H03VVH2-F=2250                 E101      4856310300    EYE LET               BSR T0.2 (R1.6)
Q401    PTD3SW1600    HEAT SINK ASS Y      DFMP3FU - + 7174300811                E102      4856310300    EYE LET               BSR T0.2 (R1.6)
00001   DFMP3FU -     DIODE                FMP3FU                                E103      4856310300    EYE LET               BSR T0.2 (R1.6)
0000A   4857031600    HEAT SINK            AL EX                                 E104      4856310300    EYE LET               BSR T0.2 (R1.6)
0000B   7174300811    SCREW TAPPTITE       TT2 RND 3X8 MFZN                      E105      4856310300    EYE LET               BSR T0.2 (R1.6)
0000C   TST2310DH1    TR                   ST2310DHI                             E106      4856310300    EYE LET               BSR T0.2 (R1.6)
0000D   7174301211    SCREW TAPPTITE       TT2 RND 3X12 MFZN                     E107      4856310300    EYE LET               BSR T0.2 (R1.6)
Q402    T2SC4793      TR                   2SC4793                               E108      4856310300    EYE LET               BSR T0.2 (R1.6)
Q403    PTB2SW7603    HEAT SINK ASS`Y      T2SC4793 + 7174300811                 E109      4856310300    EYE LET               BSR T0.2 (R1.6)
00001   T2SC4793      TR                   2SC4793                               E110      4856310300    EYE LET               BSR T0.2 (R1.6)
0000A   4857027603    HEAT SINK            AL EX                                 E111      4856310300    EYE LET               BSR T0.2 (R1.6)
0000B   7174300811    SCREW TAPPTITE       TT2 RND 3X8 MFZN                      E112      4856310300    EYE LET               BSR T0.2 (R1.6)
0000C   4856815900    CLAMP WIRE           EGI T0.4+PVC COATING                  E113      4856310300    EYE LET               BSR T0.2 (R1.6)
0000D   7174300811    SCREW TAPPTITE       TT2 RND 3X8 MFZN                      E114      4856310300    EYE LET               BSR T0.2 (R1.6)
Q441    TKTC3209Y-    TR                   KTC3209Y                              E115      4856310300    EYE LET               BSR T0.2 (R1.6)
Q442    PTC2SW7603    HEAT SINK ASS`Y      T1RF830 - + 7174300811                E116      4856310300    EYE LET               BSR T0.2 (R1.6)
00001   T1RF830 -     FET                  IRF830                                E117      4856310300    EYE LET               BSR T0.2 (R1.6)
0000A   4857027603    HEAT SINK            AL EX                                 E118      4856310300    EYE LET               BSR T0.2 (R1.6)
0000B   7174300811    SCREW TAPPTITE       TT2 RND 3X8 MFZN                      E119      4856310300    EYE LET               BSR T0.2 (R1.6)
R305    RN02B121JS    R METAL FILM         2W 120 OHM J SMALL                    E120      4856310300    EYE LET               BSR T0.2 (R1.6)
R306    RW01Y228F-    R WIRE WOUND         1W 0.22 OHM F                         E121      4856310300    EYE LET               BSR T0.2 (R1.6)
R401    RX05V301J-    R CEMENT             5W 300 OHM J VERTICAL                 E122      4856310300    EYE LET               BSR T0.2 (R1.6)
R407    RX05V561J-    R CEMENT             5W 560 OHM J VERTICAL                 E123      4856310300    EYE LET               BSR T0.2 (R1.6)
R424    RD-4Z682J-    R CARBON FILM        1/4 6.8K OHM J                        E124      4856310300    EYE LET               BSR T0.2 (R1.6)
R505    RM02Y338J-    R METAL FLAT         2W 0.33 OHM J                         E125      4856310300    EYE LET               BSR T0.2 (R1.6)
R801    DPC7R0M290    POSISTOR             2322 662 96709                        E126      4856310300    EYE LET               BSR T0.2 (R1.6)
R813    RX10T229J-    R CEMENT             10W 2.2 OHM J TRIPOD                  E127      4856310300    EYE LET               BSR T0.2 (R1.6)
T401    50D25A3 -     TRANS DRIVE          TD-25A3                               E128      4856310300    EYE LET               BSR T0.2 (R1.6)
T402    50H0000258    FBT                  BSC29-0125D                           E201      4856310600    EYE LET               BSR T0.2 (R2.3)
T402A   7178301212    SCREW TAPPTITE       TT2 WAS 3X12 MFZN BK                  E202      4856310600    EYE LET               BSR T0.2 (R2.3)
T801    50M5345B8-    TRANS SMPS           TSM-5345B8                            E206      4856310600    EYE LET               BSR T0.2 (R2.3)
TU01    4859722630    TUNER VARACTOR       TECC2949PG35W                         E208      4856310600    EYE LET               BSR T0.2 (R2.3)
Y801    5SC0101003    SW RELAY             DG12D1-0(M)-II 1C-1P                  E210      4856310600    EYE LET               BSR T0.2 (R2.3)
ZZ200   PTMPJ0D764    PCB MAIN (RHU) AS    DTA-3220ZZF                           E211      4856310600    EYE LET               BSR T0.2 (R2.3)
C320    CEXF1E102V    C ELECTRO            25V RSS 1000MF (13X20) TP             E212      4856310600    EYE LET               BSR T0.2 (R2.3)
C321    CEXF1E102V    C ELECTRO            25V RSS 1000MF (13X20) TP             E213      4856310600    EYE LET               BSR T0.2 (R2.3)
C402    CEXF1H471V    C ELECTRO            50V RSS 470MF (13X20) TP              E214      4856310600    EYE LET               BSR T0.2 (R2.3)
C416    CCXB3D471K    C CERA               2KV B 470PF K (TAPPING)               E215      4856310600    EYE LET               BSR T0.2 (R2.3)
C420    CEXF2E100V    C ELECTRO            250V RSS 10MF (10X20) TP              E216      4856310600    EYE LET               BSR T0.2 (R2.3)
C442    CEXF2E100V    C ELECTRO            250V RSS 10MF (10X20) TP              E217      4856310600    EYE LET               BSR T0.2 (R2.3)
C610    CEXF1E471V    C ELECTRO            25V RSS 470MF (10X16) TP              E218      4856310600    EYE LET               BSR T0.2 (R2.3)
C611    CEXF1E471V    C ELECTRO            25V RSS 470MF (10X16) TP              E219      4856310600    EYE LET               BSR T0.2 (R2.3)
C813    CCXB3D471K    C CERA               2KV B 470PF K (TAPPING)               E220      4856310600    EYE LET               BSR T0.2 (R2.3)
C821    CCXB3D102K    C CERA               2KV B 1000PF K (TAPPING)              E221      4856310600    EYE LET               BSR T0.2 (R2.3)
C827    CEXF1E471V    C ELECTRO            25V RSS 470MF (10X16) TP              E222      4856310600    EYE LET               BSR T0.2 (R2.3)
C831    CEXF1E222V    C ELECTRO            25V RSS 2200MF (16X25) TP             E223      4856310600    EYE LET               BSR T0.2 (R2.3)
C832    CEXF1E222V    C ELECTRO            25V RSS 2200MF (16X25) TP             E224      4856310600    EYE LET               BSR T0.2 (R2.3)
C836    CEXF1C471V    C ELECTRO            16V RSS 470MF (8X12)TP                E225      4856310600    EYE LET               BSR T0.2 (R2.3)




                                                                                22
Part List



LOC       PART CODE             PART NAME              DESCRIPTION      REMARK        LOC     PART CODE            PART NAME               DESCRIPTION     REMARK
E226    4856310600    EYE LET               BSR T0.2 (R2.3)                       C620      CEXF1H470V    C ELECTRO            50V RSS 47MF (6.3X11) TP
E227    4856310600    EYE LET               BSR T0.2 (R2.3)                       C622      CEXF1H470V    C ELECTRO            50V RSS 47MF (6.3X11) TP
E228    4856310600    EYE LET               BSR T0.2 (R2.3)                       C624      CEXF1H479V    C ELECTRO            50V RSS 4.7MF (5X11) TP
E229    4856310600    EYE LET               BSR T0.2 (R2.3)                       C626      CEXF1H479V    C ELECTRO            50V RSS 4.7MF (5X11) TP
E230    4856310600    EYE LET               BSR T0.2 (R2.3)                       C627      CEXF1H100V    C ELECTRO            50V RSS 10MF (5X11) TP
E231    4856310600    EYE LET



◦ Jabse Service Manual Search 2020 ◦ Jabse Pravopis ◦ Other service manual resources online : FixyaeServiceinfo
