                                                    S/M No. : TCP185MEF0



Service Manual
Color Television
   CHASSIS : CP-185
      Model : DTA-14C4TFF
              DTA-20C4TF
              DTA-14V1TF
              DTA-21C6TFF




               14 V1                14/20 C4                               21 C6



    SPECIFICATIONS
Version                  TF                TK                  TU               TA
TV standard            PAL B/G      PAL-SECAM B/G-D/K        PAL I/I     PAL B/G-SECAM L/L
Sound system           mono

Power consumption      14";39W;     20";42W;    21";45W.

Sound Output Power     2.5W (at 60% mod, 10% THD)

Speaker                3W 8 ohm

                       10 pages memory FASTEXT (FLOF or TOP)
Teletext system
                         version with teletext only
Aerial input           75 ohm unbalanced
Channel coverage       off-air cannels, S-cable channels and hyperband
Tuning system          frequency synthesiser tuning system
                       14": 34 cm
Visual screen size     20": 48 cm
                       21": 51 cm

Channel indication     On Screen Display

Program Selection      100 programmes

                       EURO-SCART : Audio / Video in and Out,
Aux. terminal
                       R/G/B in, Slow and Fast swtching, SVHS in.
                       Audio-Video jack on front of cabinet in common
                       connection with EURO-SCART.
                       Headphone jack (3.5mm) on fromt of cabinet

Remote Control Unit    R - 40A01




    DAEWOO ELECTRONICS CO., LTD.
    http : //svc.dwe.co.kr Oct. 2000
TABLE OF CONTENTS
SAFETY INSTRUCTION .................................................................................................................. 2

SPECIFICATIONS ............................................................................................................................ 3
  1. 21 Pin EURO-SCART ................................................................................................................... 3
  2. Channel table ............................................................................................................................... 4
  3. ATTS sorting method .................................................................................................................... 6

CIRCUIT BLOCK DIAGRAM ........................................................................................................... 8

ALIGNMENT INSTRUCTION ........................................................................................................... 9
  1. Service mode ................................................................................................................................ 9
  2. Microcontroller configuration ........................................................................................................ 9
  3. TV set Alignment .......................................................................................................................... 9

SCHEMATIC DIAGRAM .................................................................................................................. 11

EXPLODED VIEW ............................................................................................................................ 11

PRINTED CIRCUIT BOARD ............................................................................................................ 12

SERVICE PARTS LIST .................................................................................................................... 13
  1. The Different Parts List ................................................................................................................. 18

APPENDIX (" Appendix is provided only by internet [http://svc.dwe.co.kr] ")

FUNCTIONAL DESCRIPTION ......................................................................................................... 1

IC DESCRIPTION ............................................................................................................................. 16


                                                                              1
 SAFETY INSTRUCTION

  WARNING : Only competent service personnel may carry out work involving the testing or repair of this equipment


   X-RAY RADIATION PRECAUTION
1. Excessive high voltage can produce potentially hazardous X-RAY RADIATION. To avoid such hazards, the high
   voltage must not exceed the specified limit. The nominal value of the high voltage of this receiver is 22-23 kV (14" or
                                                                                                                       )
   24-26 kV (20"- 21" at max beam current. The high voltage must not, under any circumstances, exceed 27.5 kV (14"
                      )                                                                                                  ,
   20" 29KV (21" Each time a receiver requires servicing, the high voltage should be checked. It is important to use an
       ),         ).
   accurate and reliable high voltage meter.

2. The only source of X-RAY Radiation in this TV receiver is the picture tube. For continued X-RAY RADIATION
   protection, the replacement tube must be exactly the same type tube as specified in the parts list.




   SAFETY PRECAUTION
1. Potentials of high voltage are present when this receiver is operating. Operation of the receiver outside the cabinet or
   with the back cover removed involves a shock hazard from the receiver.
   1)Servicing should not be attempted by anyone who is not thoroughly familiar with the precautions necessary when
      working on high voltage equipment.
   2)Discharge the high potential of the picture tube before handling the tube. The picture tube is highly evacuated and if
      broken, glass fragments will be violently expelled.
2. If any Fuse in this TV receiver is blown, replace it with the FUSE specified in the Replacement Parts List.
3. When replacing a high wattage resistor (oxide metal film resistor) in circuit board, keep the resistor body 10 mm away
   from the circuit board.
4. Keep wires away from high voltage or high temperature components.
5. This receiver must operate under AC 230 volts, 5O Hz. NEVER connect to a DC supply of any other voltage or
   frequency.




   PRODUCT SAFETY NOTICE
Many electrical and mechanical parts in this equipment have special safety-related characteristics. These characteristics are
often passed unnoticed by a visual inspection and the X-RAY RADIATION protection afforded by them cannot necessarily be
obtained by using replacement components rated for higher voltage, wattage, etc. Replacement parts which have these spe-
cial safety characteristics are identified in this manual and its supplements, electrical components having such features are
identified by designated symbol on the parts list. Before replacing any of these components, read the parts list in this manual
carefully. The use of substitutes replacement parts which do not have the same safety characteristics as specified in the parts
list may create X-RAY Radiation.




                                                                2
SPECIFICATIONS

Pin EURO-SCART :




                   3
SPECIFICATIONS




Channel table

   FREQUENCY TABLE CP185

        EUROP                   GB(IRE-   EAST               EUROP             GB(IRE-   EAST
 CH               FRANCE                               CH             FRANCE
        E CCIR                  LAND)      OIRT              E CCIR            LAND)      OIRT
 C01     46.25         -         45.75     49.75       C40   623.25   623.25   623.25    623.25
 C02     48.25     55.75 (L')    53.75     59.25       C41   631.25   631.25   631.25    631.25
 C03     55.25     60.5 (L')     61.75     77.25       C42   639.25   639.25   639.25    639.25
 C04     62.25     63.75 (L')   175.25     85.25       C43   647.25   647.25   647.25    647.25
 C05    175.25      176.00      183.25     93.25       C44   655.25   655.25   655.25    655.25
 C06    182.25      184.00      191.25    175.25       C45   663.25   663.25   663.25    663.25
 C07    189.25      192.00      199.25    183.25       C46   671.25   671.25   671.25    671.25
 C08    196.25      200.00      207.25    191.25       C47   679.25   679.25   679.25    679.25
 C09    203.25      208.00      215.25    199.25       C48   687.25   687.25   687.25    687.25
 C10    210.25      216.00      223.25    207.25       C49   695.25   695.25   695.25    695.25
 C11    217.25   189.25 (LUX)   231.25    215.25       C50   703.25   703.25   703.25    703.25
 C12    224.25     69.25 (L')   239.25    223.25       C51   711.25   711.25   711.25    711.25
 C13     53.75     76.25 (L')   247.25       -         C52   719.25   719.25   719.25    719.25
 C14       -       83.25 (L')    49.75       -         C53   727.25   727.25   727.25    727.25
 C15     82.25       90.25       57.75       -         C54   735.25   735.25   735.25    735.25
 C16       -         97.25       65.75       -         C55   743.25   743.25   743.25    743.25
 C17    183.75         -         77.75       -         C56   751.25   751.25   751.25    751.25
 C18    192.25         -         85.75       -         C57   759.25   759.25   759.25    759.25
 C19    201.25         -           -         -         C58   767.25   767.25   767.25    767.25
 C20       -           -           -         -         C59   775.25   775.25   775.25    775.25
 C21    471.25      471.25      471.25    471.25       C60   783.25   783.25   783.25    783.25
 C22    479.25      479.25      479.25    479.25       C61   791.25   791.25   791.25    791.25
 C23    487.25      487.25      487.25    487.25       C62   799.25   799.25   799.25    799.25
 C24    495.25      495.25      495.25    495.25       C63   807.25   807.25   807.25    807.25
 C25    503.25      503.25      503.25    503.25       C64   815.25   815.25   815.25    815.25
 C26    511.25      511.25      511.25    511.25       C65   823.25   823.25   823.25    823.25
 C27    519.25      519.25      519.25    519.25       C66   831.25   831.25   831.25    831.25
 C28    527.25      527.25      527.25    527.25       C67   839.25   839.25   839.25    839.25
 C29    535.25      535.25      535.25    535.25       C68   847.25   847.25   847.25    847.25
 C30    543.25      543.25      543.25    543.25       C69   855.25   855.25   855.25    855.25
 C31    551.25      551.25      551.25    551.25       C70   863.25   863.25   863.25    863.25
 C32    559.25      559.25      559.25    559.25       C71    69.25     -         -         -
 C33    567.25      567.25      567.25    567.25       C72    76.25     -         -         -
 C34    575.25      575.25      575.25    575.25       C73    83.25     -         -         -
 C35    583.25      583.25      583.25    583.25       C74    90.25     -         -         -
 C36    591.25      591.25      591.25    591.25       C75    97.25     -         -         -
 C37    599.25      599.25      599.25    599.25       C76    59.25     -         -         -
 C38    607.25      607.25      607.25    607.25       C77    93.25     -         -         -
 C39    615.25      615.25      615.25    615.25       S01   105.25   104.75   103.25    105.25


                                                   4
                                                                       SPECIFICATIONS




      EUROP             GB(IRE-   EAST               EUROP              GB(IRE-   EAST
CH             FRANCE                          CH             FRANCE
      E CCIR            LAND)      OIRT              E CCIR             LAND)      OIRT
S02   112.25   116.75   111.25    112.25       S22   311.25   311.25     311.25   311.25
S03   119.25   128.75   119.25    119.25       S23   319.25   319.25     319.25   319.25
S04   126.25   140.75   127.25    126.25       S24   327.25   327.25     327.25   327.25
S05   133.25   152.75   135.25    133.25       S25   335.25   335.25     335.25   335.25
S06   140.25   164.75   143.25    140.25       S26   343.25   343.25     343.25   343.25
S07   147.25   176.75   151.25    147.25       S27   351.25   351.25     351.25   351.25
S08   154.25   188.75   159.25    154.25       S28   359.25   359.25     359.25   359.25
S09   161.25   200.75   167.25    161.25       S29   367.25   367.25     367.25   367.25
S10   168.25   212.75      -      168.25       S30   375.25   375.25     375.25   375.25
S11   231.25   224.75      -      231.25       S31   383.25   383.25     383.25   383.25
S12   238.25   236.75      -      238.25       S32   391.25   391.25     391.25   391.25
S13   245.25   248.75   255.25    245.25       S33   399.25   399.25     399.25   399.25
S14   252.25   260.75   263.25    252.25       S34   407.25   407.25     407.25   407.25
S15   259.25   272.75   271.25    259.25       S35   415.25   415.25     415.25   415.25
S16   266.25   284.75   279.25    266.25       S36   423.25   423.25     423.25   423.25
S17   273.25   296.75   287.25    273.25       S37   431.25   431.25     431.25   431.25
S18   280.25   136.00   295.25    280.25       S38   439.25   439.25     439.25   439.25
S19   287.25   160.00   303.25    287.25       S39   447.25   447.25     447.25   447.25
S20   294.25     -         -      294.25       S40   455.25   455.25     455.25   455.25
S21   303.25   303.25      -      303.25       S41   463.25   463.25     463.25   463.25




                                           5
 SPECIFICATIONS




ATSS sorting method

The TV set sweeps all the TV bands from beginning of VHF to the end of UHF. The TV controlling software for each program
checks if a VPS CNI code is transmitted. If no VPS CNI code is found, the system checks if a CNI code is transmitted in the tele-
text lines ( Packet 8/30 format 1 ). If such a code ( VPS or teletext ) is found and if this code is in the ATSS list, the program is
automatically named.
The programs found are then sorted into 4 groups :

Group I : Contains all the programs from the selected country and named by the TV controlling software. Within this group the
sorting order is fixed by the ATSS list.
Group II : Contains all the programs with a strong signal strength which are not listed in group I.
Group III : Contains all the programs with a weak signal strength which are not listed in group I.
Group IV : If two or more programs with the same code are found, only the strongest (or if they have the same level the one
with the lowest frequency) is listed in group I, II or III. The others are listed in group IV.

Note : If two programs with the same name but a different code are found these two programs are listed in group I, II or III (e.g.
Regional program SW3 in Germany).

The sorting order within group II, III, and IV is based on the channel frequency. The program with the lowest frequency is allo-
cated the first rank in its group, and so forth until the last program of the group which has the highest frequency.



   Program number                 Group            Skip            Program number                   Group            Skip
          1                                                               1
          2                       Group I                                 ...                      Group II
          ...                                                             m
          n                                                              m+1
         n+1                                                              ...                      Group III
          ...                    Group II                                 p
          m                                                              p+1
         m+1                                                              ...                     Group IV
          ...                    Group III                                q
          p                                                              q+1
         p+1                                                              ...                      not used            4
          ...                    Group IV                                 99
          q                                                               0
         q+1
          ...                    not used            4         Special case : Country selection = Others
          99
          0


   Note
       For TV versions without teletext, and if the controlling software is unable to catch the station name,
       Group I will remain empty.




                                                                  6
                                                                                                        SPECIFICATIONS



Special case : France
If France is selected the TV controlling software firstly sweeps all the TV bands with France system selected (positive video
modulation) and secondly with Europe system selected (negative video modulation).

Special case : Switzerland
If Switzerland is selected the TV controlling software firstly sweeps all the TV bands with Europe system selected (negative
video modulation) and secondly with France system selected (positive video modulation).

Special case : GB
Note for satellite receiver users : Before starting ATSS turn On your satellite receiver and tune "SKY NEWS ".
If GB is selected the TV controlling software seeks for programs only in UHF ( C21 to C70 ). The sorting order is :
1 - BBC1
2 - BBC2
3 - ITV
4 - CH4
5 - CH5
6 - NEWS

If two or more "identical " programs ( same name but different code e.g. BBC1 and BBC1 Scotland ) are found the following pro-
grams in the list will be shifted up. (1 - BBC1, 2 - BBC1, 3 - BBC2, 4 - ITV, 5 - CH4, 6 - CH5, 7 - NEWS, ..)

If one of the program above is not found, the associated program number remains empty ( freq.=467.25 MHz - Skip selected -
no name



◦ Jabse Service Manual Search 2020 ◦ Jabse Pravopis ◦ Other service manual resources online : FixyaeServiceinfo
