Image preview - the first page of the document
>> Download Daewoo chassis CP185L, CP185G documenatation <<
Text preview - extract from the document
7
ELECTRICAL PARTS LIST
Caution In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Prats Price List) in Service information Center (http://svc.dwe.co.kr)
Caution is a recommendable part for stock.
is safety component, so it must be used the same component.
LOC PART CODE PART NAME DESCRIPTION REMARK
ZZ100 48B3740A01 TRANSMITTER REMOCON R-40A01 R
ZZ110 PTACPWD434 ACCESSORY AS DTA-20V1MZ
00100 4850Q00910 BATTERY R03/NN
00200 48586002E2 MANUAL INSTRUCTION ENGLISH,ARABIC
M821 4858213801 BAG INSTRUCTION L.D.P.E T0.05X250X400
ZZ120 PTBCSHD753 COVER BACK AS DTB-21D4T
M211 4852156721 COVER BACK HIPS(CORE A2,B1)
M541 4855415800 SPEC PLATE 150ART P/E FILM (C/TV)
M781 4857817610 CLOTH BLACK FELT 300X20X0.7
ZZ130 PTPKCPD753 PACKING AS DTB-21D4T
10 6520010100 STAPLE PIN AUTO W65
M801 4858057500 BOX CARTON DW-3
M811 4858194100 PAD EPS
M821 4858211801 BAG P.E L.D.P.E T0.03X1300X1100
ZZ131 48519A5310 CRT GROUND NET 2101S-1015-1P
ZZ132 58G0000147 COIL DEGAUSSING DC-21SF !
ZZ140 PTCACAD753 CABINET AS DTB-21D4T
M201A 4856013300 SCREW CRT FIXING 30X80 BK
M201B 4856215402 WASHER RUBBER CR T2.0
M201C 4856013302 SCREW CRT FIXING 30X190 BK
M211A 7172401412 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK
M211B 4855930901 DECO TERM PVC CL T0.2
M211D 7172401412 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK
M591 4855933901 DECO WOOFER HIPS GY
M591A 7172401212 SCREW TAPPTITE TT2 TRS 4X12 MFZNBK
M681 4856812001 TIE CABLE NYLON66 DA100
SP01A 7172401212 SCREW TAPPTITE TT2 TRS 4X12 MFZNBK
SP02A 7172401212 SCREW TAPPTITE TT2 TRS 4X12 MFZNBK
V901 PSRTPWD002 CRT AS A51EHW135X01(PHILIPS) R !
ZRT10 4859637160 CRT A51EHW135X01
ZZ200 PTFMSJD753 MASK FRONT AS DTB-21D4T
M191 4854946301 BUTTON ABS BK
M191A 7178301011 SCREW TAPPTITE TT2 WAS 3X10 MFZN
M201 4852074601 MASK FRONT HIPS BK
M231 4851114411 PANEL CONTROL ASSY 2326711+4857101+6717900
M251 4852540801 GRILL R EGI T0.8
M252 4852540701 GRILL L EGI T0.8
M531 4855313201 DECO COVER HIPS GY
M531A 7178300811 SCREW TAPPTITE TT2 WAS 3X8 MFZN
M561 4855617500 MARK BRAND CU AU+ABS BK
ZZ210 PTSPPWD753 SPEAKER AS DTB-21D4T
12
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRIPTION REMARK
P602A 4850704S31 CONNECTOR YH025-04+YRT205+ULW800400
SP01 4858310810 SPEAKER SP-58126F01 R
SP02 4858310810 SPEAKER SP-58126F01 R
ZZ290 PTMPMSD753 PCB MAIN MANUAL AS DTB-21D4T
10 2193102005 SOLDER BAR SN:PB=63:47 S63S-1320
30 2291050616 FLUX SOLDER JS-64T3
40 2291050301 FLUX SOLVENT IM-1000
C404 CMYH3C822J C MYLAR 1.6KV BUP 8200PF J
C408 CMYE2D624J C MYLAR 200V PU 0.62MF J
C801 CL1UC3474M C LINE ACROSS 0.47MF 1J(UCVSNDF/SV)+Q/O
C804 CEYN2W151P C ELECTRO 450V LHS 150MF (25X40) R
C808 CH1BFE222M C CERA AC U/C/V AC400V 2200PF R !
C824 CH1HFE102M C CERA AC 4.0KV 1000PF E DG R !
D707 4858900002 HOLDER LED ASSY LH-3P
D807 DRGP30J - DIODE RGP30J
I301 PTD2SW7100 HEAT SINK ASS`Y 1LA78041 + 7174300811
00001 1LA78041 IC VERTICAL LA78041
0000A 4857027100 HEAT SINK SPCC T1.0+SN
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I501 1DW3613EB6 IC MICOM DW9361/N2/3-EB6 R
I601 1TDA7267A- IC AMP TDA7267A R
I602 1TDA7267A- IC AMP TDA7267A R
I702 1AT24C08PC IC AT24C08-10PC R
I703 1TS0P1238W IC PREAMP TS0P1238WI1
I801 PTM2SW4600 HEAT SINK ASS`Y 1STRW6753- + 7174300811
00001 1STRW6753- IC POWER STR-W6753 R
0000A 4857024600 HEAT SINK AL EX B/K
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I802 1LTV817C IC PHOTO COUPLER LTV-817C
I805 1KA7805 - IC REGULATOR KA7805
I901 PTC3SW1100 HEAT SINK ASS`Y 1TDA6107Q- + 7174300811
00001 1TDA6107Q- IC VIDEO AMP TDA6107Q R
0000A 4857031100 HEAT SINK A1050P-H24 T2.0
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
JPA01 4859200401 SOCKET RGB YRS21-R1
JPA02 4859109950 JACK PIN BOARD PH-JB-9710A
L401 58H0000020 COIL H-LINEARITY L-76(76.5UH)
LF801 5PLF24A1 FILTER LINE LF-24A1 R !
M682 4856812001 TIE CABLE NYLON66 DA100
P401 4859240120 CONN WAFER YFW500-06
P501 4850708N08 CONNECTOR BIC-08T-25T+C-20T+ULW=400
P801 4859903110 CORD POWER AS KKP-419J-H03VVH2+H0U=2200
A000 4859903511 CORD POWER CW4232 H03VVH2-F=2250
Q401 PTJ2SW7200 HEAT SINK ASS`Y TST1803DH- + 7174301011
00001 TST1803DH- TR HORI ST1803DHI R
13
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRIPTION REMARK
0000A 4857027200 HEAT SINK AL T1.0
0000B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
R801 DDC7R0M290 POSISTOR ECPCD7R0M290 R !
R802 RX07B339JP R CEMENT 7W 3.3 OHM J BEN 15MM 4P
SCT1 4859303530 SOCKET CRT PCS629-03C R !
SF01 5PK2960M FILTER SAW K2960M
SW801 5S40101143 SW POWER PUSH PS3-22SP (P.C.B)
T401 50D10A3 - TRANS DRIVE TD-10A3
T402 50H0000256 FBT FFA69023M R !
T801 50M3541B6- TRANS SMPS TSM-3541B6 R !
U100 4859721530 TUNER VARACTOR DT5-BF18D N
ZZ200 PTMPJ0D753 PCB MAIN (RHU) AS DTB-21D4T
C305 CEXF1E471V C ELECTRO 25V RSS 470MF (10X16) TP
C315 CEXF1E471V C ELECTRO 25V RSS 470MF (10X16) TP
C415 CEXF2E100V C ELECTRO 250V RSS 10MF (10X20) TP
C600 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP
C805 CBXB3D471K C CERA SEMI 2KV BL(N) 470PF K (T)
C810 CEXF2C101V C ELECTRO 160V RSS 100MF (16X25) TP
C811 CEXF2C101V C ELECTRO 160V RSS 100MF (16X25) TP
C813 CEXF1C222V C ELECTRO 16V RSS 2200MF (16X31.5) TP
C814 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP
C817 CEXF1C471V C ELECTRO 16V RSS 470MF (8X12)TP
C818 CEXF1C471V C ELECTRO 16V RSS 470MF (8X12)TP
C820 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C903 CCXB3D102K C CERA 2KV B 1000PF K (TAPPING)
F802 5FWML4022L FUSE WIDE TL 250V 4A CASE R !
ZZ200 PTMPJBD753 PCB MAIN M-10 AS DTB-21D4T
10 2TM18006BE TAPE MASKING 6.2X500
E001 4856310300 EYE LET BSR T0.2 (R1.6)
E002 4856310300 EYE LET BSR T0.2 (R1.6)
E003 4856310300 EYE LET BSR T0.2 (R1.6)
E004 4856310300 EYE LET BSR T0.2 (R1.6)
E005 4856310300 EYE LET BSR T0.2 (R1.6)
E006 4856310300 EYE LET BSR T0.2 (R1.6)
E007 4856310300 EYE LET BSR T0.2 (R1.6)
E008 4856310300 EYE LET BSR T0.2 (R1.6)
E009 4856310300 EYE LET BSR T0.2 (R1.6)
E010 4856310300 EYE LET BSR T0.2 (R1.6)
E011 4856310300 EYE LET BSR T0.2 (R1.6)
E012 4856310300 EYE LET BSR T0.2 (R1.6)
E013 4856310300 EYE LET BSR T0.2 (R1.6)
E014 4856310300 EYE LET BSR T0.2 (R1.6)
E015 4856310300 EYE LET BSR T0.2 (R1.6)
E016 4856310300 EYE LET BSR T0.2 (R1.6)
E017 4856310300 EYE LET BSR T0.2 (R1.6)
14
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRIPTION REMARK
E018 4856310300 EYE LET BSR T0.2 (R1.6)
E019 4856310300 EYE LET BSR T0.2 (R1.6)
E020 4856310300 EYE LET BSR T0.2 (R1.6)
E100 4856310600 EYE LET BSR T0.2 (R2.3)
E101 4856310600 EYE LET BSR T0.2 (R2.3)
E104 4856310600 EYE LET BSR T0.2 (R2.3)
E105 4856310600 EYE LET BSR T0.2 (R2.3)
E106 4856310600 EYE LET BSR T0.2 (R2.3)
E107 4856310600 EYE LET BSR T0.2 (R2.3)
E108 4856310600 EYE LET BSR T0.2 (R2.3)
E109 4856310600 EYE LET BSR T0.2 (R2.3)
N001 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N002 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N003 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
N004 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
P602 485923172S CONN WAFER YW025-04 (STICK)
R304 RS01Z109J- R M-OXIDE FILM 1W 1 OHM J (TAPPING)
R306 RS01Z109J- R M-OXIDE FILM 1W 1 OHM J (TAPPING)
R402 RS01Z249J- R M-OXIDE FILM 1W 2.4 OHM J (TAPPING)
R415 RS02Z102JS R M-OXIDE FILM 2W 1K OHM J SMALL
R804 RS02Z278JS R M-OXIDE FILM 2W 0.27 OHM J SMALL
R821 RS02Z100JS R M-OXIDE FILM 2W 10 OHM J SMALL
R822 RS02Z151JS R M-OXIDE FILM 2W 150 0HM J SMALL
R824 RS02Z101JS R M-OXIDE FILM 2W 100 OHM J SMALL
R835 RS02Z151JS R M-OXIDE FILM 2W 150 0HM J SMALL
ZZ200 PTMPJRD753 PCB MAIN RADIAL AS DTB-21D4T
C102 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C106 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C121 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C320 CEXF1H101V C ELECTRO 50V RSS 100MF (8X11.5) TP
C355 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C412 CEXF2C229V C ELECTRO 160V RSS 2.2MF (8X11.5)TP
C414 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C417 CXSL2H470J C CERA 500V SL 47PF J (TAPPING)
C418 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C420 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C423 CCXB2H561K C CERA 500V B 560PF K (TAPPING)
C502 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C504 CMXM2A332J C MYLAR 100V 3300PF J (TP)
C509 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C511 CMXL1J104J C MYLAR 63V MEU 0.1MF J
C512 CMXL1J104J C MYLAR 63V MEU 0.1MF J
C514 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C517 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C519 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
15
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRIPTION REMARK
C522 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C523 CCXF1H103Z C CERA 50V F 0.01MF Z (TAPPING)
C524 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C525 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C526 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C528 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C530 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C532 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C551 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C555 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C564 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C570 CCXB1H472K C CERA 50V B 4700PF K (TAPPING)
C593 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C599 CEXF1H229V C ELECTRO 50V RSS 2.2MF (5X11) TP
C601 CEXF1H108V C ELECTRO 50V RSS 0.1MF (5X11) TP
C602 CCXF1H103Z C CERA 50V F 0.01MF Z (TAPPING)
C603 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C604 CEXF1H108V C ELECTRO 50V RSS 0.1MF (5X11) TP
C605 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11) TP
C650 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C770 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C802 CCXF3A472Z C CERA 1KV F 4700PF Z (T)
C803 CCXF3A472Z C CERA 1KV F 4700PF Z (T)
C806 CCXB1H821K C CERA 50V B 820PF K (TAPPING)
C809 CCXB3A271K C CERA 1KV B 270PF K (TAPPING)
C812 CEXF2A100V C ELECTRO 100V RSS 10MF (6.3X11) TP
C815 CMXL2E104K C MYLAR 250V MEU 0.1MF K
C816 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C819 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C822 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C832 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C833 CMXM2A473J C MYLAR 100V 0.047MF J (TP)
C834 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C835 CCXB2H471K C CERA 500V B 470PF K (TAPPING)
C901 CMXL2E104K C MYLAR 250V MEU 0.1MF K
C902 CCXB1H561K C CERA 50V B 560PF K (TAPPING)
CA04 CEXD1H229F C ELECTRO 50V RND 2.2MF (5X11) TP
CA10 CCXF1H103Z C CERA 50V F 0.01MF Z (TAPPING)
G901 4SG0DX0001 SPARK GAP SSG-102-A1(1.0KV) TAP
G902 4SG0DX0001 SPARK GAP SSG-102-A1(1.0KV) TAP
G903 4SG0DX0001 SPARK GAP SSG-102-A1(1.0KV) TAP
G904 4SG0DX0001 SPARK GAP SSG-102-A1(1.0KV) TAP
I803 1KA431L - IC KA431L
L802 58CX430599 COIL CHOKE AZ-9004Y 940K TP
Q101 TKTC3198Y- TR KTC3198Y
16
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRIPTION REMARK
Q402 TKTC3207 TR KTC3207 (TP)
Q403 TKTC3198Y- TR KTC3198Y
Q501 TKTA1266Y- TR KTA1266Y (TP)
Q502 TKTC3198Y- TR KTC3198Y
Q503 TKTC3198Y- TR KTC3198Y
Q520 TKTC3198Y- TR KTC3198Y
Q531 TKTA1266Y- TR KTA1266Y (TP)
Q805 TKTC3205Y- TR KTC3205Y (TP)
Q807 TKTA1281Y- TR KTA1281Y
Q808 TKTC3198Y- TR KTC3198Y
Q809 TKTC3198Y- TR KTC3198Y
Q810 TKTC3198Y- TR KTC3198Y
Q811 TKTA1266Y- TR KTA1266Y (TP)
Q812 TKTC3198Y- TR KTC3198Y
Q851 TKTC3198Y- TR KTC3198Y
Q852 TKTC3198Y- TR KTC3198Y
R907 RN01B102JS R METAL FILM 1W 1K OHM J SMALL
SW701 5S50101090 SW TACT THVH472GCA
SW702 5S50101090 SW TACT THVH472GCA
SW703 5S50101090 SW TACT THVH472GCA
SW704 5S50101090 SW TACT THVH472GCA
SW705 5S50101090 SW TACT THVH472GCA
SW706 5S50101090 SW TACT THVH472GCA
X502 5XEX12R00E CRYSTAL QUARTZ HC-49/U 12.000MHZ 30PPM TP
Z501 5PXXT5R5MB FILTER CERA XT 5.5MB-TP
Z502 5PXXT6R5MB FILTER CERA XT 6.5MB-TP
Z503 5PXXT6R0MB FILTER CERA XT 6.0MB-TP
ZZ200 PTMPJAD753 PCB MAIN AXIAL AS DTB-21D4T
10 2TM14006LB TAPE MASKING 3M #232 6.0X2000M
20 2TM10006LB TAPE MASKING 3M #232-MAP-C 6.2X2000M
A001 4859807793 PCB MAIN 246X330
C353 CZCH1H100J C CERA 50V CH 10PF J
C403 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C501 CCZF1H103Z C CERA 50V F 0.01MF Z
C515 CBZR1C222M C CERA 16V Y5R 2200PF M (AXIAL)
C516 CBZR1C472M C CERA 16V Y5R 4700PF M (AXIAL)
C518 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C520 CCZB1H221K C CERA 50V B 220PF K (AXIAL)
C521 CCZB1H221K C CERA 50V B 220PF K (AXIAL)
C527 CCZF1H473Z C CERA 50V F 0.047MF Z
C531 CCZF1H473Z C CERA 50V F 0.047MF Z
C533 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C534 CCZF1H223Z C CERA 50V F 0.022MF Z
C535 CCZF1H223Z C CERA 50V F 0.022MF Z
C536 CCZF1H223Z C CERA 50V F 0.022MF Z
17
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRIPTION REMARK
C571 CCZB1H821K C CERA 50V B 820PF K AXIAL
C585 CBZR1C222M C CERA 16V Y5R 2200PF M (AXIAL)
C590 CZCH1H270J C CERA CH 50V 27PF J AXL 52MM
C591 CZCH1H270J C CERA CH 50V 27PF J AXL 52MM
C606 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
CA01 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
CA02 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
CA03 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
CA05 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CA06 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CA07 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CA08 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
D101 D1N4148 - DIODE 1N4148 (TAPPING)
D120 DUZ33B DIODE ZENER UZ-33B
D313 D1N4004S DIODE 1N4004S
D405 D1N4937G DIODE 1N4937G (TAPPING)
D407 D1N4937G DIODE 1N4937G (TAPPING)
D408 D1N4937G DIODE 1N4937G (TAPPING)
D450 D1N4937G DIODE 1N4937G (TAPPING)
D520 D1N4148 - DIODE 1N4148 (TAPPING)
D521 D1N4148 - DIODE 1N4148 (TAPPING)
D531 D1N4148 - DIODE 1N4148 (TAPPING)
D532 D1N4148 - DIODE 1N4148 (TAPPING)
D533 D1N4148 - DIODE 1N4148 (TAPPING)
D534 D1N4148 - DIODE 1N4148 (TAPPING)
D701 DUZ5R6BM DIODE ZENER UZ-5.6BM
D702 DUZ5R6BM DIODE ZENER UZ-5.6BM
D710 DUZ5R1B - DIODE ZENER UZ-5.1B
D711 DUZ5R6BM DIODE ZENER UZ-5.6BM
D801 DLT2A05G DIODE LT2A05G (TP)
D802 DLT2A05G DIODE LT2A05G (TP)
D803 DLT2A05G DIODE LT2A05G (TP)
D804 DLT2A05G DIODE LT2A05G (TP)
D805 D1N4937G DIODE 1N4937G (TAPPING)
D806 DUZ5R6BM DIODE ZENER UZ-5.6BM
D808 D1N4937G DIODE 1N4937G (TAPPING)
D809 DRGP15J - DIODE RGP15J
D810 D1N4937G DIODE 1N4937G (TAPPING)
D812 DUZ8R2BM DIODE ZENER UZ-8.2BM
D813 D1N4148 - DIODE 1N4148 (TAPPING)
D814 D1N4937G DIODE 1N4937G (TAPPING)
D815 D1N4937G DIODE 1N4937G (TAPPING)
D817 DUZ6R2BM DIODE ZENER UZ-6.2BM
D820 DUZ2R7B - DIODE ZENER UZ-2.7B
DA02 DUZ5R6BM DIODE ZENER UZ-5.6BM
18
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRIPTION REMARK
DA03 DUZ5R1B - DIODE ZENER UZ-5.1B
DA04 CCZB1H271K C CERA 50V B 270PF K
DA05 DUZ5R6BM DIODE ZENER UZ-5.6BM
DA06 DUZ5R6BM DIODE ZENER UZ-5.6BM
DA08 DUZ5R6BM DIODE ZENER UZ-5.6BM
DA09 DUZ5R6BM DIODE ZENER UZ-5.6BM
DA10 DUZ5R6BM DIODE ZENER UZ-5.6BM
DA11 DUZ5R6BM DIODE ZENER UZ-5.6BM
DA13 CCZB1H271K C CERA 50V B 270PF K
DA27 DUZ5R6BM DIODE ZENER UZ-5.6BM
J001 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J002 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J003 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J004 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J005 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J006 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J008 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J010 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J012 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J013 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J014 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J016 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J017 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J018 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J019 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J020 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J021 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J022 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J023 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J024 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J026 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J027 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J028 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J029 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J030 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J034 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J035 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J036 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J037 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J038 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J040 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J041 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J042 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J043 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J044 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
19
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRIPTION REMARK
J045 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J050 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J052 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J053 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J054 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J055 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J056 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J057 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J059 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J060 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J061 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J062 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J065 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J067 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J068 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J069 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J070 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J071 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J072 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J073 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J074 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J075 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J076 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J077 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J078 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J079 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J080 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J081 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J082 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J083 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J084 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J085 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J086 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J087 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J088 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J089 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J090 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J092 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J094 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J095 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J096 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J097 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J098 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J099 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J100 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
20
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRIPTION REMARK
J101 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J102 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J103 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J104 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J105 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J106 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J107 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J108 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J109 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J110 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J111 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J116 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J117 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J118 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
L101 5CPZ569K02 COIL PEAKING 5.6UH K (AXIAL 3.5MM)
L303 5MC0000100 COIL BEAD HC-3550
L500 5CPZ829K02 COIL PEAKING 8.2UH K (AXIAL 3.5MM)
L501 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
L502 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
L510 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
L511 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
L601 5MC0000100 COIL BEAD HC-3550
L602 5CPZ109M04 COIL PEAKING 1UH 10.5MM M (LAL04TB)
L603 5CPZ109M04 COIL PEAKING 1UH 10.5MM M (LAL04TB)
L604 5CPZ109M04 COIL PEAKING 1UH 10.5MM M (LAL04TB)
L605 5CPZ109M04 COIL PEAKING 1UH 10.5MM M (LAL04TB)
L801 5MC0000100 COIL BEAD HC-3550
L901 5MC0000100 COIL BEAD HC-3550
R101 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R102 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R103 RD-AZ123J- R CARBON FILM 1/6 12K OHM J
R104 RD-AZ104J- R CARBON FILM 1/6 100K OHM J
R105 RD-AZ392J- R CARBON FILM 1/6 3.9K OHM J
R106 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R107 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R121 RD-2Z332J- R CARBON FILM 1/2 3.3K OHM J
R302 RD-2Z129J- R CARBON FILM 1/2 1.2 OHM J
R303 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
R305 RD-2Z331J- R CARBON FILM 1/2 330 OHM J
R310 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R311 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R351 RN-4Z1501F R METAL FILM 1/4 1.50K OHM F
R352 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R401 RD-4Z472J- R CARBON FILM 1/4 4.7K OHM J
R404 RD-2Z751J- R CARBON FILM 1/2 750 OHM J
21
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRIPTION REMARK
R405 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R420 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R430 RD-4Z223J- R CARBON FILM 1/4 22K OHM J
R431 RD-4Z303J- R CARBON FILM 1/4 30K OHM J
R450 RD-2Z103J- R CARBON FILM 1/2 10K OHM J
R505 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R506 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
R507 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R508 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
R509 RD-AZ681J- R CARBON FILM 1/6 680 OHM J
R512 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R513 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R514 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R515 RD-AZ153J- R CARBON FILM 1/6 15K OHM J
R516 RD-AZ393J- R CARBON FILM 1/6 39K OHM J
R517 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R518 RD-AZ273J- R CARBON FILM 1/6 27K OHM J
R520 RD-AZ183J- R CARBON FILM 1/6 18K OHM J
R521 RD-AZ391J- R CARBON FILM 1/6 390 OHM J
R522 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
R523 RD-AZ331J- R CARBON FILM 1/6 330 OHM J
R524 RD-AZ561J- R CARBON FILM 1/6 560 OHM J
R525 RD-AZ104J- R CARBON FILM 1/6 100K OHM J
R526 RD-4Z479J- R CARBON FILM 1/4 4.7 OHM J
R527 RD-AZ431J- R CARBON FILM 1/6 430 OHM J
R528 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
R530 RD-AZ470J- R CARBON FILM 1/6 47 OHM J
R531 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R533 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R534 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R535 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R537 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R538 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R539 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R549 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R550 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R551 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
R555 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R556 RD-AZ562J- R CARBON FILM 1/6 5.6K OHM J
R560 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R561 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
R567 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
R571 RD-AZ432J- R CARBON FILM 1/6 4.3K OHM J
R572 RD-AZ122J- R CARBON FILM 1/6 1.2K OHM J
R573 RD-AZ272J- R CARBON FILM 1/6 2.7K OHM J
22
ELECTRICAL PARTS LIST
LOC PART CODE PART NAME DESCRIPTION REMARK
R575 RD-AZ511J- R CARBON FILM 1/6 510 OHM J
R580 RD-AZ561J- R CARBON FILM 1/6 560 OHM J
R585 RD-4Z224J- R CARBON FILM 1/4 220K OHM J
R586 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
R587 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
R595 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
R596 RD-AZ122J- R CARBON FILM 1/6 1.2K OHM J
R597 RD-AZ153J- R CARBON FILM 1/6 15K OHM J
R598 RD-AZ153J- R CARBON FILM 1/6 15K OHM J
R601 RD-AZ822J- R CARBON FILM 1/6 8.2K OHM J
R602 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
R603 RD-4Z100J- R CARBON FILM 1/4 10 OHM J
R607 RD-AZ470J- R CARBON FILM 1/6 47 OHM J
R610 RD-AZ162J- R CARBON FILM 1/6 1.6K OHM J
R710 RD-AZ431J- R CARBON FILM 1/6 430 OHM J
R711 RD-AZ431J- R CARBON FILM 1/6 430 OHM J
R712 5MC0000100 COIL BEAD HC-3550
R713 RD-AZ100J- R CARBON FILM 1/6 10 OHM J
R720 RD-AZ122J- R CARBON FILM 1/6 1.2K OHM J
R721 RD-AZ181J- R CARBON FILM 1/6 180 OHM J
R722 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
R723 RD-AZ331J- R CARBON FILM 1/6 330 OHM J
R724 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R725 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
R803 RD-4Z104J- R CARBON FILM 1/4 100K OHM J
R805 RD-4Z225J- R CARBON FILM 1/4 2.2M OHM J
R806 RD-4Z152J- R CARBON FILM 1/4 1.5K OHM J
R807 RD-4Z221J- R CARBON FILM 1/4 220 OHM J
R808 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R809 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R810 RD-4Z479J- R CARBON FILM 1/4 4.7 OHM J
R811 RD-AZ152J- R CARBON FILM 1/6 1.5K OHM J
R813 RC-2Z565KP R CARBON COMP 1/2 5.6M OHM K
R814 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
R815 RD-AZ682J- R CARBON FILM 1/6 6.8K OHM J
R816 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R817 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R818 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R823 RD-AZ561J- R CARBON FILM 1/6 560 OHM J
R825 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
R826 RD-AZ751J- R CARBON FILM 1/6 750 OHM J
R827 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
R828 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R829 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R830 RD-AZ221J- R CARBON FILM 1/6 220 OHM J
23
R831
LOC RD-AZ473J-
PART CODE R CARBON FILM NAME
PART 1/6 47K OHM JDESCRIPTION REMARK
R832 RD-AZ561J- R CARBON FILM 1/6 560 OHM J
R833 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
R834 RD-AZ561J- R CARBON FILM 1/6 560 OHM J
R840 RN-4Z6801F R METAL FILM 1/4 6.8K OHM F
R841 RN-4Z1003F R METAL FILM 1/4 100K OHM F
R842 RN-4Z2201F R METAL FILM 1/4 2.20K OHM F
R843 RD-AZ333J- R CARBON FILM 1/6 33K OHM J
R901 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R902 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R903 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R904 RD-2Z152J- R CARBON FILM 1/2 1.5K OHM J
R905 RD-2Z152J- R CARBON FILM 1/2 1.5K OHM J
R906 RD-2Z152J- R CARBON FILM 1/2 1.5K OHM J
R954 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RA01 RD-AZ680J- R CARBON FILM 1/6 68 OHM J
RA02 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RA03 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RA04 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RA06 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
RA07 RD-AZ390J- R CARBON FILM 1/6 39 OHM J
RA08 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
RA09 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
RA10 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RA11 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RA12 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RA16 RD-AZ680J- R CARBON FILM 1/6 68 OHM J
RA19 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
RA20 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
RA30 RD-AZ512J- R CARBON FILM 1/6 5.1K OHM J
RA44 RD-AZ682J- R CARBON FILM 1/6 6.8K OHM J
24
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
